Harbor Freight Tools 42977 Assembly & Operating Instructions

Stand for drill / mill machine

Download this manual

Stand for

Drill / Mill

Machine

Model 42977

A s s e m b l y & O p e r a t i n g

I n s t r u c t i o n s

No portion of this manual or any artwork contained herein may be reproduced in any

manner, shape or form without the express written consent of Harbor Freight Tools.

For technical questions and replacement parts, please call 1-800-444-3353.

42977

3491 Mission Oaks Blvd. / Camarillo, CA 93011

www.harborfreight.com

2000 by Harbor Freight Tools

REVISED 08/05

Stand shown with Drill / Mill machine (not included)

Page 1 © No portion of this manual or any artwork contained herein may be reproduced in any manner, shape or form without the express written consent of Harbor Freight Tools. For technical questions and replacement parts, please call 1-800-444-3353. REVISED 08/05...
Page 2: Specifications
#42977 DRILL / MILL MACHINE STAND SPECIFICATIONS Construction: 6 Gauge Steel, painted Overall Dimensions: 17.4” L x 12. 09” W x 37.8” H (4) flanges with bolt-down holes Net Weight: 38.58 Lbs. FEATURES This sturdy steel cabinet provides a strong, vibration resistand stand for drill / mill machines.
Page 3 Check to be sure the machine is securely mounted before connecting the power cord, or turning it on. NOTE: Some parts are listed and shown for illustration purposes only and are not available individually as replacement parts. Page 3 SKU # 42977...
Page 4 #42977 DRILL / MILL MACHINE STAND PARTS DIAGRAM DESCRIPTION Body Door Hinge Door Handle Assembly A B C D E F DOOR HANDLE ASSEMBLY DESCRIPTION Bolt Spring Handle Sleeve Door Holder Spring Washer MAINTENANCE Keep the stand wiped down and clean.
