S_ST551 ST558_UM_EU_V01_H
1506-0B86000
138,7cm (54.6")
Liquid Crystal Display Television
Flüssigkristallbildschirm
Téléviseur à Écran à Cristaux Liquides
TV de Pantalla de Cristal Líquido
TV LCD
TV Ecrã de Cristais Líquidos
ЖКД ТВ
LCD-tv
Telewizor ciekłokrystaliczny
LCD TV
LCD TV
LCD TV
LCD TV
Folyadékkristályos TV
РК-телевізор
Televizoru LDC
LCD телевизор
TV cu LCD
LCD TV
Televizora s ekranom od tekućih kristala
Advertisement
Table of Contents
Related Manuals for HANNspree S_ST551 ST558_UM_EU_V01_H
Summary of Contents for HANNspree S_ST551 ST558_UM_EU_V01_H
- Page 1 TV LCD TV Ecrã de Cristais Líquidos ЖКД ТВ LCD-tv Telewizor ciekłokrystaliczny LCD TV LCD TV LCD TV LCD TV Folyadékkristályos TV РК-телевізор Televizoru LDC LCD телевизор TV cu LCD LCD TV Televizora s ekranom od tekućih kristala S_ST551 ST558_UM_EU_V01_H 1506-0B86000...
-
Page 2: Table Of Contents
Table of Contents Regulatory Information ..............3 Description of Warning Symbols ..........3 Safety Notices ................4 Preface ..................6 Warranty and Service ..............6 1. Getting Started ................ 8 1.1 Package Contents ............. 8 1.2 Introducing the TV ............. 9 1.3 Features ................ - Page 3 Table of Contents 3.2 Adjusting Picture Settings ..........27 3.3 Adjusting Sound Settings ..........28 3.4 Adjusting Channel Settings for ATV (Analogue TV) ... 28 3.5 Adjusting DTV Settings ............ 30 3.6 Adjusting PC Settings ............33 3.7 Adjusting Setup Settings ..........34 4.
-
Page 4: Regulatory Information
Directive 2006/95/EC on the harmonization of the laws of Member States relating to electrical equipment for use within certain voltage limits. Hannspree cannot accept responsibility for any failure to satisfy the requirements resulting from a non-recommended modification of the device. -
Page 5: Safety Notices
Safety Notices Installation Safety Notes Location Avoid allowing the TV to get prolonged exposure to sunlight or other strong sources of heat. Leave sufficient distance between the TV and the wall to provide enough space for the emission of heat. WARNING To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. - Page 6 Personal Safety 1. To avoid overloading the power supply, never plug too many electrical devices into an outlet, power strip, or extension cable. 2. Dangerous high-voltage electric power components are located inside the TV. To avoid electric shock, do not disassemble the casing. 3.
-
Page 7: Preface
The information in this manual is subject to change without notice. To the extent allowed by applicable law, Hannspree, Inc. (“Hannspree”) shall not be liable for direct, indirect, special, exemplary, incidental or consequential damages arising from any defect or omission in this manual, even if advised of the possibility of such damages in advance. - Page 8 Hannspree. The TV described in this manual may include copyrighted software of Hannspree (or other third parties). Hannspree (or other third parties) preserves the exclusive rights for copyrighted software, such as the right to distribute or reproduce the copyrighted software.
-
Page 9: Getting Started
Getting Started Package Contents Make sure the following components are included in the box. Please contact Hannspree Customer Service immediately if anything is missing or damaged. • • User’s manual • Quick start guide • Warranty card • Power cord •... -
Page 10: Introducing The Tv
Introducing the TV You can watch SECAM/ PAL/ DVB-T broadcast, cable, or digital television channels, Component and easily connect a VCR, STB or DVD player to the SCART, HDTV ( AV(Composite), and HDMI input ports (locations of these ports depend on the model). -
Page 11: Control Panel
Control Panel Description Button Function Power Press to turn the TV on or off. Input source INPUT Press to select the proper input source. Menu MENU Press to open the OSD menu. Press to increase the program number or Program select move upward to the previous item on the OSD menu. - Page 12 Description Connector Function SERVICE Service Service only. Not available for users. Connect to an external device, such as a S-VIDEO S-Video Input VCR, STB, or a DVD player. Composite Input Connect to an external device, such as a VIDEO (Video) VCR, STB, or a DVD player.
-
Page 13: Remote Control
Description Connector Function VGA (PC) Input Connect to a PC’s VGA port. AUDIO IN PC Audio Input Connect to a PC’s line/audio port. Connect a HDMI equipment or a HDMI- HDMI IN HDMI 1 Input DVI adapter cable to devices such as a DVD player or set-top box. - Page 14 Description Icon Function Use to select a program directly. Press 0-9 to Keypad enter the program numbers (press 1 and 0 for program 10). Press to display the features contained (only Pro.List Pro.LIST for DTV). LAST Last Press to return to the last channel selected. 1.
- Page 15 Description Icon Function Press to change the multi sound selection of Dual sound the TV channel. Select Press P to increase the program number. program Press P to decrease the program number. Red, Green, Press the colored buttons to perform specific Yellow, Blue tasks in the OSD menu or teletext mode.
- Page 16 Description Icon Function Press continuously to toggle through all the Picture Mode picture settings: Vivid, Soft, User, Standard. In ATV, press to select favorite channels and press to go to favorite channels. Favorite FAV. In DTV, press to open favorite list menu and channel press to select channels and press...
-
Page 17: Inserting The Remote Control Batteries
Inserting the Remote Control Batteries 1 Open the battery compartment cover at the back of the remote control. 2 Insert the batteries paying attention to the polarity markings inside the battery compartment. 3 Replace the battery compartment cover. - Page 18 CAUTION • If the remote control is not used for a long period, remove the batteries and store them properly. • Handle damaged or leaking batteries carefully, and wash hands with soap if they come in contact with leaked chemical fluids. •...
-
Page 19: Setting Up Your Tv
Setting up your TV Basic Connections 2.1.1 Power Connection 1 Connect the power cord to the AC IN input jack on the rear of the TV. 2 Insert the plug at the other end of the power cord into a power outlet. 2.1.2 Connecting an Antenna or Cable TV Connect one end of the VHF/UHF (Antenna) or CATV cable to TV/DTV jack on the... -
Page 20: Connecting External Devices
Connecting External Devices Connect external devices such as VCRs, STBs, DVD players, video game consoles, earphones, or a PC to the TV using the appropriate ports on the rear of the TV. 2.2.1 Connecting External Earphones Headphones Speakers (Built-in Amplifiers) Note: •... -
Page 21: Connecting To Av Devices
2.2.2 Connecting to AV Devices The following diagram illustrates how to connect the AV devices to your TV via HDMI (A), YPbPr/AUDIO (B), SCART (C), AV/SV (D) ports. HDMI IN AUDIO VIDEO HDMI 4 R-AUDIO-L VIDEO S-VIDEO SCART Adapter (Optional) Video Cable SCART Cable... -
Page 22: Connecting A Vcr/ Stb/ Dvd Player
2.2.3 Connecting a VCR/ STB/ DVD Player Using Component Video/Audio, Composite Video/Audio, or S-Video/Audio Connect the TV to a VCR/ STB/ DVD player using three different types of video/audio inputs. Video Cable VIDEO (Optional) AUDIO Audio Cable (Optional) R-AUDIO-L VIDEO Audio Cable (Optional) Video Cable... -
Page 23: Connecting A Pc Using Vga
2.2.4 Connecting a PC using VGA Connect the TV to your PC to use it as the monitor using the VGA port as shown. 1 Connect the VGA port of the TV to the VGA output of the PC. 2 Connect the line out port of the PC to the PC Audio In port of your TV to listen to audio from the PC. -
Page 24: Connecting Hdmi
2.2.6 Connecting HDMI HDMI (High Definition Multimedia Interface) assures that the best video signal is always sent from source to the TV. Refer to the following illustration to connect a HDMI device to the TV. HDMI IN HDMI 4 DVD Player HDMI Cable (Optional) Note:... -
Page 25: Connecting A Vcr/ Stb/ Dvd Player Using Scart
2.2.8 Connecting a VCR/ STB/ DVD Player using SCART Use the SCART ports to connect a TV, VCR, VCD, DVD player or video game console. You can choose to use a SCART cable or adapter for the connection depending on the ports available on your player. SCART 1 SCART 2 SCART Adapter... -
Page 26: Using The Tv
Using the TV 2.3.1 Turning the TV On and Off 1 Press on the control panel or remote control. The power LED indicator on the TV changes from red to green, indicating that the TV is on. 2 Press again. The power LED changes from green to red, indicating that the TV is off. -
Page 27: Adjusting On-Screen Display (Osd) Settings
Adjusting On-Screen Display (OSD) Settings The On-Screen Display (OSD) menu system provides a quick and simple method to adjust the TV settings. The OSD menu can be accessed conveniently through the buttons on the remote control. Before going into details of each OSD option, you may get acquainted with the placement of the OSD system: CURRENT MENU: Displays the title of the... -
Page 28: Osd Setting Menus
OSD Setting Menus Follow the instructions indicated on the down side of the OSD Function Menu. Press P on the control panel or to scroll through the menus, VOL on the control panel or to select an item, or MENU to exit the OSD menu. The following menus can be set by different adjustment methods. -
Page 29: Adjusting Sound Settings
Adjusting Sound Settings Press MENU to enter the OSD Main Sound Menu screen. Sound Mode Standard Press to select the Sound menu. Balance Treble Press to enter the Sound menu. Bass Press to select an item. Press adjust the scales or options Move Select Return... - Page 30 • The Area can be set to Germany, UK, Italy, Spain, Portugal, France, Hungary, Poland, Netherlands, and Other. • The Channel can be used to select channels by pressing • There are a variety of transmission standards of colour and audio signals used in worldwide TV systems.
-
Page 31: Adjusting Dtv Settings
- Just follow the instructions at the bottom of the Channel Editor screen to Skip, Delete, Swap, or Lock a channel. Channel Editor Channel Frequency Name Skip Fav. Lock 223.25 - - - Channel Editor 223.25 - - - 235.30 - - - 241.30 - - -... - Page 32 - The DTV menu can be used to adjust the Channel Management, Area, Auto Search, Manual Search, Preferred Audio, Preferred Subtitle, Parental Lock, Subtitle Type, Time, CI and Parental Rating. • Under the submenu of the Channel Management option, you can organize, sort, group, or delete TV channels.
- Page 33 • The Subtitle Type provides you with Normal and Hearing Impaired options. • The Time selection includes GMT Offset and Summer Time. - Press to adjust the GMT Offset to AUTO or a value ranging from +12 to -12. - Press to adjust Summer Time to On or Off.
-
Page 34: Adjusting Pc Settings
Adjusting PC Settings Press INPUT and select PC as the signal type. Pc Setup Auto Adjust Press MENU to enter the OSD Main H Position Menu screen. V Position Phase Clock Press to select the PC menu. Press to enter the PC menu. Move Select Return... -
Page 35: Adjusting Setup Settings
• The Background can be set to Blue or Off. • Select Initial Setup to do auto Channel Scan. • The Hannspree Light can be set to Low, Middle, High, and Off. • The Vivid Motion can be set to Low, Middle, High, and Off. - Page 36 • The Aspect mode selections include AUTO, Full, Normal, Subtitle, Zoom, and Panorama. The following pictures are settings for HDMI/1080P, please see below for details. Type 16:9 Content AUTO Full Nomal Subtitle Zoom Panorama Note: The options available on the OSD menu may vary depending on the input signal source.
-
Page 37: Troubleshooting
Troubleshooting Situation Solution • Connect the power cord properly. • Check if the power LED is on or not. • Press on the control panel or remote control. No picture and sound. • Press Input to cycle through connected video sources. •... -
Page 38: Support Timing
Support Timing PC Mode Support Timing Mode Resolution Horizontal Vertical Nominal PC (VGA) DVI to HDMI (active dot) Frequency Frequency Pixel Clock (KHz) (Hz) (MHz) 640x480@60Hz 31.469 59.940 25.175 SVGA 800x600@60Hz 37.879 60.317 40.0 1024x768@60Hz 48.363 60.004 65.000 VESA 1280x720@60Hz 44.955 59.94 74.176... -
Page 39: Specifications
Specifications Screen Size 138,7 cm / 55” LCD Panel 1920x1080 Refresh Rate 100Hz Input Function RF in x 1 SCART x 2 AV x 1 Component Video RCA In x 1 Component Audio In x 1 HDMI x 4 VGA x 1 VGA Audio In x 1 CI x 1 S-Video x 1... -
Page 40: Dissembling The Stand Base
Customers should not attempt to do the work themselves. please contact with Hannspree dealers in wall mount bracket. You can ask a qualified service personnel about using an optional bracket to mount the TV to the wall. Please add rubber cover when this TV is mounted on the wall. -
Page 41: Using The Cable Organizer
Using the Cable Organizer Route the cables through the cable clamp as shown:...
