TV). With this product, you will be able to enjoy superior audio and video while enriching your lifestyle with advanced technology. The Hannspree TV is warranted for one year limited service from the date the product is received (as shown on the Warranty and Service Manual);...
No part of this documentation may be reproduced in any form by any means without prior written authorization of Hannspree, Inc., and its licensors, if any.
Description of Warning Symbols Warning Caution This symbol is used to remind This symbol is used to remind users to pay attention to users to pay attention to the important descriptions regard- danger of electric shocks due ing usage and maintenance to dangerous internal non- (repair) or additional impor- insulated components.
Safety Notices Power Supply Safety Notes 1. To avoid electric shocks, do not use an extended power cord or an outlet that does not match this product's plug or leaves the plug exposed. 2. This product has a 3-pin grounded plug. The third pin connects to ground;...
Page 8
Before You Proceed 1. Read the Safety Notices and the User’s Manual carefully before turning the product on. 2. Keep your User’s Manual in a safe place for future reference. Keep the box and packaging in case the product needs to be shipped in the future.
Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with a dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
Page 11
10. Protect the power cord from being walked on or pinched particularly at the plug, conve- nience receptacles, and the point where they exit from the apparatus. 11. Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.
Page 12
Personal Safety To avoid overloading the power supply, do not plug too many electrical devices into an outlet or extension cable. Dangerous high-voltage electric power compo- nents are located inside the TV. To avoid electric shock, do not disassemble the casing. Do not place or drop metals, small objects, or flammable materials in the vent to avoid an elec- tric shock or a fire.
Page 13
Installation To avoid damage to power circuits, do not place the TV in locations where there is excessive steam or dust. Do not place the TV on a bed, sofa, carpet, or in a sealed cabinet to avoid blocking the product's vents.
Page 14
Operation This product is designed for power sources as labeled on the casing. Avoid using any other power accessories to avoid electric shock or other damage. The plug can be inserted into an outlet in only one direction. Notify a qualified service techni- cian if you cannot plug it in correctly.
Regulatory Information FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is sub- ject to the following two conditions: (1) This device may not cause harm- ful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 16
DOC Compliance Notice This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the Radio Interference Regulations of the Canadian Department of Communications.This device complies with Canada ICES-003 Class B. CE Conformity Statement This device complies with the requirements set out in the Council Direc- tive on the approximation of the Laws of the Member States relating to...
Introducing the TV Thank you for purchasing this Liquid Crystal Display TV. Your TV is designed to be safe, versatile, and easy to use. The design with soccer ball TV makes it a fun addition to any room. You can watch standard NTSC television channels, and easily connect a VCR, VCD, or DVD player to the standard CVBS and S-Video input ports located at...
Checking Package Contents Make sure the following components are included in the box. Contact your vendor immediately if anything is missing or damaged. MENU SOURCE User’s Manual Quick Start Guide Warranty and Service Manual Wire Material Package Power Cord Power Adapter 4-IN-1 Cable...
Getting to Know Your TV Front View MENU SOURCE MENU SOURCE Description Function Headphone line out Connects to headphones. Volume up (VOL + ): Increases the vol- Adjust volume ume. Volume down ( VOL –): Decreases the volume. Channel up (CH ): Increases the channel Select channel number.
Page 20
Description Function Turns the on-screen display (OSD) Menu menus on and off. Selects the input source to be displayed Source (TV, AV1, or AV2). Signal sensor Point the remote control at this sensor. Turns the TV on and off. Green LED indi- Power/Power LED cates power on.
Input and Output Ports DC-IN VIDEO DC-IN VIDEO Description Function Connects to the included power DC-IN adapter. Use the AV1 input to connect an exter- nal device, such as a VCR, or a VCD, or DVD player. Audio Input: AV connector white and red audio cables.
Page 22
Description Function Use the included 4-IN-1 Audio/Video cable to connect external devices, such as a VCR, VCD, or DVD player. Audio Input: AV connectors white and red audio cables. Video Input: AV connector video (yellow) or S-Video cables. Antenna/cable TV Connects to an antenna or CATV cable line in television line.
Getting Started Connecting to an Antenna or Cable TV Connect one end of the VHF/UHF (Antenna) or CATV cable to the ANT Jack (VHF/UHF IN Jack) on the back of the TV. Connect the other end of the VHF/UHF (Antenna) or CATV cable to the Antenna or CATV socket.
Connecting to AV Devices Connect external devices such as VCD/DVD players or VCRs to the TV using the AV1 and AV2 ports on the back of the TV. Connecting to a VCR, VCD or DVD Player The illustration presented here shows you how to connect your TV to a VCR, VCD or DVD player.
Connecting to a Video Camera The following illustration shows you how to connect the TV to a cam- corder. Actual connections may vary according to the make and model of the device. Refer to the user’s manual included with the camcorder for more detailed instructions.
Connecting Headphones Headphones may be used to listen to the TV instead of using the built-in speakers. Connect headphones to the headphone line out port as illustrated. Headphones MENU SOURCE MENU SOURCE Headphones line out port Notes • Headphones are not included with the product. •...
Connecting the Power Adapter Connect the power cord to the power adapter as illustrated. Plug the power adapter connector into the DC-IN on the rear panel of the TV. Plug the three-pronged plug at the other end of the power cord into a power outlet.
Using the TV Using the Remote Control For best results, use the remote control within a distance of 5 meters (16 feet) from the front of the TV’s signal sensor. Do not exceed an angle of 30 degrees when pointing at the signal sensor. Refer to the following illustration.
Turning the TV On and Off Press POWER on the remote control or on the TV control panel. The power LED indicator on the front of the TV changes from red to CH 33 green, indicating that the power is Press the POWER button again.
Switching Source Signals Press to select different SOURCE source signals. CH, AV1, and AV2 appear on the CH 33 top right corner of the screen in that order. Note The TV supports S-Video input in addi- MENU SOURCE tion to normal video and audio sig- nals.
Adjusting On-Screen Display (OSD) Settings The On-Screen Display (OSD) menu system provides a quick and simple method to adjust your TV's settings. This chapter describes how to change each of the available settings. Button Descriptions Front Panel Control Menu MENU CH UP ...
Picture Setting MAIN MENU PICTURE AUDIO MENU CUSTOMIZE ENTER ENTER MENU MENU Press MENU to enter the Press the VOL UP button to enter OSD Main Menu screen. the PICTURE Menu. Note You can operate the OSD with either the remote control or the front panel control.
Brightness Press the VOL UP button. The PICTURE MENU BRIGHTNESS BRIGHTNESS brightness slide bar appears. CONTRAST SHARPNESS SATURATION COLOR NEUTRAL PRESET ENTER ENTER MENU MENU Press the VOL UP button to BRIGHTNESS BRIGHTNESS increase the brightness. Press the VOL DOWN button to decrease the brightness.
Contrast Press the CH DOWN button to select PICTURE MENU BRIGHTNESS CONTRAST. CONTRAST SHARPNESS Press the VOL UP button. The con- SATURATION trast slide bar appears. COLOR NEUTRAL PRESET ENTER ENTER ENTER ENTER MENU MENU MENU MENU Press the VOL UP button to CONTRAST CONTRAST increase the contrast.
Sharpness Press the CH DOWN button to PICTURE MENU BRIGHTNESS select SHARPNESS. CONTRAST SHARPNESS Press the VOL UP button. The SATURATION sharpness slide bar appears. COLOR NEUTRAL PRESET ENTER ENTER ENTER ENTER MENU MENU MENU MENU Press the VOL UP button to SHARPNESS SHARPNESS increase the sharpness.
Press the CH DOWN button to select PICTURE MENU BRIGHTNESS HUE. CONTRAST SHARPNESS Press the VOL UP button. The hue SATURATION slide bar appears. COLOR NEUTRAL PRESET ENTER ENTER ENTER ENTER MENU MENU MENU MENU Press the VOL UP button to increase the hue toward the green end of the spectrum.
Saturation Press the CH DOWN button to PICTURE MENU BRIGHTNESS select SATURATION. CONTRAST SHARPNESS Press the VOL UP button. The satu- SATURATION ration slide bar appears. COLOR NEUTRAL PRESET ENTER ENTER ENTER ENTER MENU MENU MENU MENU Press the VOL UP button to SATURATION SATURATION increase the saturation.
Color Press the CH DOWN button to PICTURE MENU BRIGHTNESS select COLOR. CONTRAST SHARPNESS Press the VOL UP button. The cur- SATURATION rent setting appears blinking in the COLOR NEUTRAL PRESET brackets. MENU MENU Neutral Color PICTURE MENU BRIGHTNESS Press the VOL UP button to select CONTRAST SHARPNESS NEUTRAL, then press MENU.
Preset Press the CH DOWN buttonto PICTURE MENU BRIGHTNESS select PRESET. CONTRAST SHARPNESS Press the VOL UP button. “OK” SATURATION appears in the brackets. All picture COLOR NEUTRAL PRESET settings are returned to the factory- ENTER ENTER ENTER ENTER MENU MENU MENU MENU...
Audio Setting MAIN MENU PICTURE AUDIO MENU CUSTOMIZE ENTER ENTER ENTER ENTER MENU MENU MENU MENU Press MENU to enter the OSD Press the CH UP/DOWN Main Menu screen. select AUDIO. Press the VOL UP button to enter the Audio Menu. Note You can operate the OSD with either the remote control or the front panel control.
Treble Press the VOL UP button to select AUDIO MENU TREBLE. TREBLE BASS Press ˜ . The treble slide bar BALANCE ENHANCE appears. PRESET ENTER ENTER ENTER ENTER MENU MENU MENU MENU Press the VOL UP button to TREBLE TREBLE increase the treble.
Bass Press the CH DOWN buttonto select BASS. AUDIO MENU TREBLE BASS Press the VOL UP button. The bass BALANCE ENHANCE slide bar appears. PRESET ENTER ENTER ENTER ENTER MENU MENU MENU MENU Press the VOL UP button to BASS BASS increase the bass.
Balance Press the CH DOWN button to AUDIO MENU select BALANCE. TREBLE BASS Press the VOL UP button. The bal- BALANCE ENHANCE ance slide bar appears. PRESET ENTER ENTER ENTER ENTER MENU MENU MENU MENU Press the VOL DOWN button to shift BALANCE BALANCE the balance to the left speaker.
Enhance Press the CH DOWN button to AUDIO MENU select ENHANCE. TREBLE BASS Press the VOL UP button to enter BALANCE ENHANCE the setting field. PRESET ENTER ENTER ENTER ENTER MENU MENU MENU MENU Press the VOL UP button to turn enhance on or off.
TV Setting MAIN MENU PICTURE AUDIO MENU CUSTOMIZE ENTER ENTER MENU MENU Press MENU to enter the OSD Press the CH UP/DOWN but- Main Menu screen. to select TV. Press the VOL UP button to enter the TV Menu. Note You can operate the OSD with either the remote control or the front panel control.
TV/CATV Press the VOL UP button. The cur- MENU rent setting appears flashing in the TV/CATV CATV ADD/ERASE brackets. AUTO PROGRAM ENTER ENTER MENU MENU Receiving Cable TV MENU Press the VOL UP button to select TV/CATV CATV ADD/ERASE CATV, then press MENU. “CATV” AUTO PROGRAM appears in the brackets.
Channel Add/Erase Press the CH DOWN button to MENU select CH ADD/ERASE. TV/CATV CATV ADD/ERASE Press the VOL UP button. The OSD AUTO PROGRAM ENTER ENTER menu display switches to the fol- MENU MENU lowing screen. Press the CH UP/DOWN button on the front panel to select a channel.
Auto Program Press the CH DOWN button on the MENU front panel to select a channel. to TV/CATV CATV ADD/ERASE select AUTO PROGRAM. AUTO PROGRAM ENTER ENTER MENU MENU Press the VOL UP button on the AUTO PROGRAM front panel to select a channel. to begin auto programming.
Customize Setting MAIN MENU PICTURE AUDIO MENU CUSTOMIZE ENTER ENTER ENTER ENTER MENU MENU MENU MENU Press MENU to enter the OSD Press the CH UP/DOWN but- Main Menu screen. to select CUSTOMIZE. Press the VOL UP button to enter the TV Menu.
Sleep Timer The sleep timer turns the TV off automatically after a set time. Press the VOL UP button to select CUSTOMIZE MENU a value: OFF, 30, 60, 90, or 120 SLEEP TIMER TIMEOUT minutes. LANGUAGE ENGLISH ENTER ENTER MENU MENU Press MENU to confirm your CUSTOMIZE...
OSD Timeout This setting allows you to set the length of time the OSD menus appear on the screen when a button is not pressed. Press the CH DOWN button to CUSTOMIZE MENU select OSD TIMEOUT. SLEEP TIMER TIMEOUT Press the VOL UP button. The cur- LANGUAGE ENGLISH rent setting appears flashing in the...
Taking Care of Your TV Turn the power off before you begin cleaning the For best results, use a clean lens cloth to remove dust and fingerprints from the screen. Do not wipe the shell of the TV with alcohol, methanol, gasoline or oil products to avoid dam- aging the finish.
Troubleshooting Situation Solution • Connect the power cord properly. • Press the POWER button on the con- trol panel or remote control. • Press the SOURCE button to cycle through connected video sources. • Press the CHANNEL UP or CHAN- No picture and sound.
Page 54
Situation Solution • If OSD items are colored light blue, the system is in a state such that Cannot operate menus. those settings are not available. For example, video setting is available in TV mode. • Make sure the video signal cable is No image but have sound.
Specifications ST08-10A1 LCD Panel Size 9.6-inch TFT Aspect Ratio Best Resolution 800 (horizontal) x 600 (vertical) Maximum Display Area 194.4 mm (H) x 145.8 mm (V) TV System NTSC AV1: Composite Video (RCA jack; yellow) Video System AV2: mini-DIN 10-pin (Composite + S-...
Glossary Aspect Ratio The ratio of width to height of a film, image or display screen. Broadcast TV Broadcasting video signals using high-frequency electromagnetic waves to distribute television channels to viewers (standard TV broadcast). CATV Community Antenna Television, the original name for cable TV. A television distribution system that uses coaxial cable instead of the traditional radio broad- casting (over-the-air) method to deliver television, FM radio, and other services to consumers.
