Summary of Contents for Samson AirLine MICRO
-
Page 2: Table Of Contents
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 14 AirLine Micro Channel Plan . . . . . . . . . . . . . . . . 15... -
Page 3: Introduction
. The AirLine Micro Camera system is designed so that it can easily be integrated into your current video system, and comes with all of the necessary components to execute your video shoot or live broadcast . The system is comprised of one AL2 belt pack transmitter and one AR2 micro receiver, which are each housed in a durable aluminum chassis . - Page 4 Introduction In this manual, you’ll find a detailed description of the features of your AirLine Micro Camera system, as well as a guided tour of its components, step-by-step instructions for setting up and using your system, and full specifications . If your AirLine Micro Camera system was purchased in the United States, you’ll also find a warranty card enclosed .
-
Page 5: System Components
Each system is shipped with one plug adaptor specific to the country where the system is purchased. Addional adaptors can be ordered through Samson. Owners Manual Carrying Case Owners Manual AirLine Micro Camera System... -
Page 6: Quick Start
Please follow these basic procedures for setting up and using your AirLine Micro: 1 . For your AirLine Micro system to work properly, both the receiver and transmitter must be on the same channel . Remove all packing materials (save them in case your unit needs to be serviced in the future) and check to make sure that the supplied receiver and transmitter are on the same channel . - Page 7 Indicator is RED, simply move the microphone further from your mouth . If the Status Indicator is lighting GREEN, make sure that the gain structure of your audio system is set correctly (consult the owners manual of your mixer and/or amplifier for details) . Owners Manual AirLine Micro Camera System...
- Page 8 (set to the same channel as the transmitter) should be used . 13 . If you have followed all of the above the steps and are still experiencing difficulties with your system, please call Samson Technical Support (1-800-372-6766) between 9:00 a .m . and 5:00 p .m . EST . If you purchased your system outside of the U .S ., please contact your local distributor .
-
Page 9: Guided Tour - Ar2 Receiver
. YELLOW AR2 Powered On, No Tone-Key Present GREEN AL2 On, Normal Operation Flashing GREEN AL2 Audio Muted Transmitter Input Overloaded Owners Manual AirLine Micro Camera System... - Page 10 NOTE: The USB port can only be used for charging purposes and cannot be used for data exchange between a PC and the AR2 receiver. 7. 1/8” Unbalanced Output - Use this unbalanced (600 Ohm min .) 1/8” (3 .5 mm) mini-phone jack when connecting to audio equip- ment . AirLine Micro Camera System...
-
Page 11: Guided Tour - Al2 Transmitter
> 5 sec Flashing YELLOW Increase Gain Press (Total 5 steps) > 0 .2 sec Flashing YELLOW Decrease Gain Press (Total 5 steps) > 0 .2 sec Flashing YELLOW Set Level Don’t Press 10 sec GREEN Owners Manual AirLine Micro Camera System... - Page 12 Low Battery Indicator will flash BLUE when the unit is on, and the battery is low . When recharging the AL2, the LED will light steady BLUE until the battery is fully charged . Then the indicator will turn off . AirLine Micro Camera System...
- Page 13 NOTE: The Universal AC Adaptor will charge the AL2 & AR2 faster than a computer USB port. NOTE: The USB port can only be used for charging purposes and cannot be used for data exchange between a PC and the AL2 transmitter. Owners Manual AirLine Micro Camera System...
-
Page 14: Ar2Dt Dock
4 . To recharge the AR2 receiver and AL2 transmitter, connect the USB Y-cable to the USB DC input on the back panel of the AR2DT and connect the cable to the included Universal AC adaptor . AirLine Micro Camera System... -
Page 15: Ar2 Camera Mount
Note: The AR2 Camera Mount does not provide power for the AR2 receiver. Note: If your camera does not have a standard hot shoe mounting point, an additional adapter may be necessary. Please refer to your camera’s user guide. Owners Manual AirLine Micro Camera System... -
Page 16: Specifications
Two 1/4 Wavelength Rod 1 .7” L x 0 .51” W x 2 .4” H Selectivity ±150 kHz (AF Out Ratio -60 dB) Weight 42 grams (1 .5 oz .) S/N Ratio (Overall) 90 dB (w/IHF-A Filter) AirLine Micro Camera System... -
Page 17: Airline Micro Channel Plan
645 .750 MHz Airline Micro N-Channel wireless frequencies are within UHF TV frequency bands. Only certain channels may be available in particular areas. The six N-Channels have been selected for optimum multi-channel compatibility and may be used simultaneously, subject to frequency availability in your geographic area. - Page 18 CAUTION! Electrical shock can result from removal of the This device complies with part 15 of the FCC rules . Operation is receiver cover . Refer servicing to qualified service personnel . subject to the condition that this device does not cause harmful No user-serviceable parts inside .
- Page 19 FCC is currently evaluating use of wireless microphone systems, and these rules are subject to change . For more information, call the FCC at 1-888-CALL-FCC (TTY: 1-888-TELL-FCC) or visit the FCC’s wireless microphone website at www . fcc .gov/cgb/wirelessmicrophones . Samson Technologies Corp. 45 Gilpin Avenue Hauppauge, New York 11788-8816...
- Page 20 AirLine Micro Function & Indicator Guide AL2 Belt Pack Transmitter Status Belt Pack Indicator Light Powering On Status Indicator: Steady GREEN . Mute Status Indicator: The indicator flashes GREEN . Volume Adjust Status Indicator: The indicator flashes YELLOW . The indicator flashes faster as the volume is increased .
