Runco DHD4 Specifications

Runco DHD4 Controller Specifi cations:
Aspect Ratios:
Video Standards:
Inputs:
Output:
Display Communication:
Communication Control Ports:
Ethernet Communication:
12V Outputs:
Power Requirements:
Operating Environment:
Dimensions:
Accessory Applications:
Regulatory Approvals:
Limited Warranty:
Specifi cations are subject to change without notice. ©Copyright 2010 Runco International Inc. All rights reserved.
4:3, 16:9, Letterbox, VirtualWide™, Cinema,
Virtual Cinema™, Native
HDMI and DVI with HDCP for digital video, Component and RGB HDTV
(1080p, 1080i, 720p), Component and RGB EDTV (576p, 480p),
Component and Composite SDTV (576i, 480i), RGB SCART with adaptor,
NTSC (M, 4.43), PAL (B, G, H, I, N, M), SECAM (M)
(4) HDMI 1.4 with CEC and Deep Color; (1) Component/SCART (3 x RCA);
(2) Component/RGBHV (5 x BNC); (3) Composite
(1) HDMI 1.4 with CEC and Deep Color to display; (1) HDMI 1.4 with
Deep Color to second display or audio processor
HDMI via RuncoLink™; RJ11 for serial display control
(1) USB (type B female) for fi rmware upgrade; (1) RS-232 (female DB9)
for serial commands; (1) RS-232 (male DB9) for accessories; (1) 3.5mm
wired IR input for Niles/Xantech-compatible IR systems; Discrete infrared
remote; Front panel vacuum fl uorescent display and keypad
(1) RJ45 (female) for web server, e-mail, auto fi rmware upgrade and Telnet
(3) 3.5mm programmable, 250mA max each
100 – 240V AC (auto-sensing), 50/60 Hz, 35 watts (typical)
50°F to 104°F (10°C to 40°C), 0% to 85% humidity (non-condensing),
up to 10,000' altitude
Width = 17.50 inches (444.5 mm); Depth = 11.19 inches (284.1 mm);
Height (with feet) = 3.75 inches (95.3 mm); Height (without feet) = 3.47
inches (88.14 mm); Weight: 15.4 lbs. (7.0 kg)
Runco Firmware Upgrader, Runco BRiC (backup, restore, clone),
CalMAN by SpectraCal for automatic calibration
cTUVus, FCC class B, CE, RoHS, China RoHS, WEEE, C-Tick, CCC,
local conformances as required
(2) Two years parts and labor from the date of shipment from Runco
www.Runco.com
800-23-RUNCO, +1-503-784-1100
