Grizzly G9731 Datasheet

Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G9731 13" X 40" PRECISION TOOL ROOM LATHE, 3
Product Dimensions:
Weight............................................................................................................................................................ 1475 lbs.
Width (side-to-side) x Depth (front-to-back) x Height..................................................................... 70 x 23-1/2 x 50 in.
Footprint (Length x Width)............................................................................................................................ 71 x 22 in.
Shipping Dimensions:
Type.......................................................................................................................................................... Wood Crate
Content........................................................................................................................................................... Machine
Weight............................................................................................................................................................ 1597 lbs.
Length x Width x Height....................................................................................................................... 30 x 73 x 62 in.
Must Ship Upright................................................................................................................................................... Yes
Electrical:
Power Requirement................................................................................................................... 220V, 3-Phase, 60 Hz
Prewired Voltage.................................................................................................................................................. 220V
Full-Load Current Rating....................................................................................................................................... 7.5A
Minimum Circuit Size.............................................................................................................................................. 15A
Plug Included........................................................................................................................................................... No
Switch Type..................................................................................... Magnetic Switch w/Thermal Overload Protection
Recommended Phase Converter....................................................................................................................... G7978
Motors:
Main
Type........................................................................................................................................... TEFC Induction
Horsepower................................................................................................................................................ 3 HP
Phase.................................................................................................................................................... 3-Phase
Amps........................................................................................................................................................... 7.5A
Speed................................................................................................................................................ 1725 RPM
Power Transfer .................................................................................................................................. Belt Drive
Bearings..................................................................................................... Shielded & Permanently Lubricated
Main Specifications:
Operation Info
Swing Over Bed......................................................................................................................................... 13 in.
Distance Between Centers........................................................................................................................ 40 in.
Swing Over Cross Slide......................................................................................................................... 7-1/2 in.
Swing Over Saddle...................................................................................................................................... 8 in.
Swing Over Gap..................................................................................................................................... 19.5 in.
Maximum Tool Bit Size............................................................................................................................. 1/2 in.
Compound Travel.................................................................................................................................. 3-3/4 in.
Carriage Travel.......................................................................................................................................... 35 in.
Cross Slide Travel................................................................................................................................. 5-3/4 in.
The information contained herein is deemed accurate as of 6/21/2013 and represents our most recent product specifications.
Model G9731
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
MACHINE DATA
HP 220V 3-PHASE
SHEET
PAGE 1 OF 3
