Residential & Light Commercial HVAC
Rated in Accordance with ARI Standard 210.
Certification Applies Only When Used with
Proper Components as Listed with ARI.
Additional rating information can be found
at www.aridirectory.org
Model
Size
Nominal
Number
(tons)
BTUH
C18ABD1VF
1
⁄
18,000
1
2
24,000
C24ABD1VF
2
C30ABD1VF
2
1
⁄
30,000
2
C36ACD1VF
3
36,000
C42ACD1VF
3
1
⁄
42,000
2
C48ACD1VF
4
48,000
C60ACD1VF
5
60,000
Split System Air Conditioner
Min. Circuit
Max. Fuse or
Ampacity
Breaker
9.1
15
11.5
15
14.3
20
18.7
30
20.3
35
23.1
40
30.1
50
208/230 Volt, 1-Phase, 60 Hz
Performance:
Efficiency rating of 13 SEER and 14 SEER
Cooling capacities from 1
Refrigerant Circuit:
Factory installed liquid line filter drier
Long life copper tubes, aluminum fins
State-of-the-art compressors
Large, wrap-around coil surface
Quality Built:
Galvanized steel exterior cabinet with
1,000-hour salt spray, powder-coated finish
Powder-coated fan guard
Full louvered panel to protect coil
Formed base with 2
1
⁄
" ground clearance
2
Limited 5-year warranty on parts
Easy To Install:
Factory-charged with R-22 refrigerant
Only three screws to access electrical controls
Easy access to service valves
Operating Dimensions
Min. Mounting
H x W x D (inches)
Pad Size (inches)
26
⁄
X 21
⁄
X 21
⁄
1
1
1
2
2
2
26
1
⁄
X 21
1
⁄
X 21
1
⁄
2
2
2
32
1
⁄
X 21
1
⁄
X 21
1
⁄
2
2
2
32
1
⁄
X 29
1
⁄
X 29
1
⁄
2
2
2
32
1
⁄
X 29
1
⁄
X 29
1
⁄
2
2
2
32
1
⁄
X 29
1
⁄
X 29
1
⁄
2
2
2
39 X 29
1
⁄
X 29
1
⁄
2
2
1
1
⁄
thru 5 Tons
2
1
⁄
to 5 tons
2
Ship / Operating
Weight (lbs)
24 x 24
144 / 138
24 x 24
142 / 136
24 x 24
169 / 163
32 x 32
189 / 180
32 x 32
213 / 204
32 x 32
217 / 208
32 x 32
230 / 220
