Important Safeguards .....2 Service Information ....4 Use ........4-5 Accessories ......5 Maintaining ......6 Dust Bag .........6 Problem Solving .....7 Warranty .........8 Repair Parts List ....9-16 For location of nearest Eureka Warranty Station or service information call 1-800-282-2886. *En Mexico llame al 5670-6169. www.eureka.com...
IMPORTANT SAFEGUARDS When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER. WARNING To reduce the risk of fi re, electric shock, or injury: • Do not use outdoors or on wet surfaces. •...
Page 3
CONSEILS DE SÉCURITÉ Lors de lʼutilisation dʼun appareil électrique, quelques précautions élémentaires doivent être observées, incluant les suivantes: LISEZ TOUTES LES INSTRUCTIONS AVANT DʼUTILISER VOTRE ASPIRATEUR. AVERTISSEMENT Pour réduire le risque de feu, de choc électrique, ou de blessure: • Ne pas utiliser lʼaspirateur à lʼextérieur ou sur une surface mouillée. •...
2. Check the hose, bag and fi lter regularly, as a clogged hose, full bag or dirty fi lter could cause the motor to overheat. 3. Call a Eureka Service Station if the cleaner will not operate af ter cooling for ap prox i mate ly 30 minutes.
HOW TO USE Cleaning Accessories (continued) Slip the circular end of an accessory tool onto the end of the Store Tools hose handle and twist slightly to secure. If ad di tion al reach is needed, place a wand on the hose handle fi rst. Attach wands and cleaning tools Crevice Tool (Wands may vary by model)
fi lters better than our standard bag. The bags are available (three in a package) from your local dealer, or you can call 1-800-282-2886 for How to Install HEPA Filter other locations. Look for the Gen u ine Eureka Fil ter aire dust bag–Style (on some models) MM, PN 60296A.
PROBLEM SOLVING NOTE: Turn OFF the power switch and unplug the electrical cord before ser vic ing. PROBLEM PROBLEM PROBLEM CAUSE CAUSE CAUSE SOLUTION SOLUTION SOLUTION Motor wonʼt start Electric plug Push plug securely into outlet. ✓ ✓ Try another outlet. Check circuit breaker.
WHAT THE EUREKA COMPANY WILL DO The Eureka Company will, at its option, repair or replace a defective cleaner or cleaner part that is covered by this warranty. As a matter of warranty policy, the Eureka Company will not refund the consumerʼs purchase price.
Performance You Expect Quality You Demand REPAIR PARTS LIST Eureka Heavy Duty HD3684A Date: April 7, 2004 THE EUREKA COMPANY BLOOMINGTON, ILLINOIS 61701...
Page 11
HD3684A 60487-33 HOUSING ASSEMBLY* 59046-1 FRONT COVER GASKET 38956-1SV FRONT COVER ASSEMBLY** 38805-1 CASTER ASSEMBLY*** 37409-1 WHEEL & HUB ASSEMBLY 28008B-5 REAR HOUSING ASSEMBLY**** 15409A-119N REAR WHEEL 27964-119N EXTENSION TUBE 38333 FILTER INCLUDES ITEMS 4 & 5 INCLUDES ITEM 2 INCLUDES ITEM 5 **** INCLUDES ITEM 7...
Page 13
HD3684A 28261 MOTOR MOUNTING GASKET 60865-5 MOTOR ASSEMBLY 60610 SCREW - pkg of 10 28050 MOTOR BUSHING 28304A-2 SWITCH ASSEMBLY Not on this model. 39408-2 THERMOSTAT & TERMINAL ASSEMBLY 39585-12 CORD & TERMINAL ASSEMBLY...
