Important Information WARNING TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING To reduce the risk of fire or RISK OF ELECTRIC SHOCK DO NOT OPEN TO QUALIFIED SERVICE PERSONNEL. shock hazard, do not expose this TV to rain or moisture.
"L Table. of Contents Important Information Warning, Product Registration Quick Guide to Your TV Startup Hook up your TV, Plug in the TV, Put Batteries in the Remote, Turn on the TV, Adjust Picture Tilt, Place Channels into Memory, Set the Time Basic Tour of the Remote Button Layout and Functions Menu Basics...
Quick Guide to Your TV Startup The steps below will get your TV connected and ready for watching. For more details, see the page numbers listed. Hook up any antennas, cables or Hook up your other equipment to your TV before Details are in the you follow the steps below.
Quick Guide to Your TV Startup Make sure STRENGTH switch A° Adjust PICTURE TILT. is in the OFF position. BACK OF TV Picture tilt is used to correct a tilted Move STRENGTH switch to the picture from the effect of the Earth's LOW position.
Quick Guide to Your TV Basic. Tour of the Remote Basic information about your remote is shown below. This will give you a general idea of how your remote works. For more details, see pages 6-15. TV Power Button Turns the TV on. Sets the remote to control the TV.
Quick Guide to Your TV Menu Basics, General information about using the on-screen menu system is shown below. Details on using the remote buttons are on pages 6-7. Many menu items are explained in detail in Using the Advanced Features starting on page 20. Yellow Green Light White...
Using Your TV and Remote With Remote Buttons REC (Record) POWER Turns off the TV. Starts recording onto tape. Turns off compatible components. STOP Turns on a component after a Stops tape or laserdisc. component button is pressed. PAUSE AUDIO, VCR1, VCR2oLD, Pauses tape or laserdisc.
Using Your TV and Remote With Remote Buttons Number Buttons (0-9) MENUopROG (Program) Shows menus on the screen and Selectsany channel nuLmber. moves from menu to menu. Two numbers must be pressed Sets VCR clock and programs each channel. Press 0 and 6 for timer on VCR.
Page 11
Using. Your TV and Remote With VCRs: Setting the VCR 1 Channel The VCR 1 Channel works with VCR1 button on the remote. If the VCR 1 Channel is set, pressing VCR1 selects the channel to see the VCR picture. The VCR 1 Channel setting depends on which diagram...
Using Your TV and Remote With VCRs: Basic Operation If the remote operates your VCR, this page will show you how to use it for basic functions. See pages.6-7 for more details on buttons used with your VCR. A. Press channel 00, 03, or 04 on Turn on the VCR the TV to see what the VCR is doing.
Page 13
Satellite Receiver Codes the receiver. Chaparral ......80)31 i Cheyenne .......81 Drake ......... 82,83 | ::::::::::::::::::::::::::::::::::::::::::::::: General Instruments...92,93,94 ProScan........00 _. RCA ......... 00 B Realistic ........84 I Sierra I,II,HI ......81 i STS1.........85 _ srsz ........86 |: STS3......... 87 _ _J4...,o°.,..o.
Using. Your TV and Remote With a Cable Box: Setting the Cable Channel The Cable Channel works with SAT-CABLE button on the remote. If the Cable Channel is set, pressing SATeCABLE selects the channel to see cable channels. The Cable Channel setting depends on which channel your cable box must be on to see cable channels.
D. Use the buttons on the remote that relate to laserdisc player functions. Not all buttons IN PUI"o ANTENNAo highlighted may work with your laserdisc player. E. Press POWER to turn it off. Laserdisc Player Codes "1 Pioneer ......33 ProScan.....:.33 RCA......33...
•With Audio Equipment: Programming and Basic Operation Refer to the Connec.tion Book or your Audio equipment owner's manual to hook up your audio equipment, Your remote controls only RCA audio equipment such as a radio, CD player, tape player, turntable, or amplifier.
Adjusting Your TV Overall Picture Follow the steps below to lighten or darken the overall picture without changing the color levels. Press MENU°PROG to select the Select the Controls Menu Controls menu. This menu is yellow. Alarm Ad Press MOVE • to highlight 2.
Adjusting Your TV Picture Settings Follow the steps below to change the picture on the screen to your personal setting. The chart at the bottom of the page explains your options. Press MENU-PROG repeatedly Select the Adjust Menu select the Adjust menu. This menu is light blue.
Adjusting Your TV Sound Settings: Stereo, Expanded Stereo, SAP and Tone Follow these steps to adjust the Stereo, Expanded Stereo, SAP or Tone of your TV. SAP (Second Audio Program) is sometimes used to offer the program another being watched in language.
Adjusting Your TV Sound Settings: -Speakers Follow the steps below to turn the speakers on or off in your TV, The chart below explains, your options. Press MENU-PROG repeatedly to Select the Setup Menu select the Setup menu. This menu is white.
Using Advanced Features Placing Channels in Memory (Autoprogramming) Only channels 2-13 appear in the TV's memory when you first turn it on. The channels available in your area must be programmed into the TV's memory when you hook up your TV. Using CHANNEL up and down allows you to scan through these channels.
Using, Advanced Features Naming the Channels You can name at least 20 channels with four characters in each name. Full appears beside Label when the memory is used up. Fixed appears when a channel number cannot be named. Below are the characters that can be used in a name.
Using Advanced Features Setting the Sleep Timer You can set your TV to turn itself off. If you're watching TV at night and fall asleep, the TV will turn off for you. A. Press MENU,PROG to select the 1. Set Sleep Timer Controls menu and highlight Sleep Timer.
Using. Advanced Features setting the Alarm Clock The TV can be set to turn on each day like your alarm dock. You can set it to turn on to your favorite channel at a certain time. You can also set it to turn itself off again, The Alarm cannot be used until the clock is set.
Using Advanced Features Selecting a Language The on-screen displays in this TV can be displayed in threelanguages: English, French, and Spanish. When you select a language, most of the displays will be shown on the screen in your preferred language. Press MENU.PROG repeatedly Select the Setup menu select the Setup menu.
Using Advanced Features Setting Your TV for Antenna or Cable Your TV automatically adjusts this feature when the TV places channels in memory (Autoprogram). Follow the steps below to change the setting as needed. Press MENU.PROG repeatedly 1. Select the Setup menu select the Setup menu.
References Front Panel Buttons The CHANNEL up and down and VOLUME + and - buttons not only change the channels and volume of the TV, but work like the MOVE buttons when you are in the TV menus. For details on using buttons with menus, see Menu Basics on page 5. MENU Shows menus on screen.
References Displays on the Screen Your TV shows the settings of several features on the screen. To see what features have been set on your TV, press DISPLAY on the remote. 12:00 AM KNBC or Video 00, S-Vid 00 Alarm Sleep Volume -.
References Trouble Checks You may have problems that can be fixed with a few minor adjustments. Look for the type of problem you are having below and then try the suggestions to get your TV going again. For warranty information see page 30. Trouble Checks and Adjustments...
Reference Trouble Checks Trouble Checks and Adjustments Remote Remove batteries and hold down one or more buttons for several seconds Remote lockup to drain the microprocessor inside the remote and reset it. Re-instaU the batteries and try remote again. Buttons don't work when you Press TV to set the remote to control the TV.
References Limited Warranty • Any defect in material or workmanship. What your warranty covers: How long after • 90 days for labor charges. your purchase: • One year for parts. • Two years for picture tube. (The warranty period for rental units begins with the first rental or 45 days from date of shipment to the rental firm, whichever comes first.) What we will do:...
References Order Form for Parts Remote # 221133 Order Form If your TV has the Book No. 1508137A picture-in-picture feature, this is the remote that came '0 _0 '0 packed with your TV. "0 '0 '0 You can use the order '0 '0 '0 "_ '0"6"...
References Order .Form for Parts U.S.and Canadian Orders USE YOUR CREDIT CARD By Phone: Copy complete account number 1 - 800 - 338 - 0376 Call this toll-free number between I I, I IF[-NI I I IF-VT-I 8AM and 8PM Eastern Standard Time and place your order using your Visa _ _ires: VI-1VN or MasterCard.
References Index S-VHS ........7,27 Adjust Menu Displays (On-Screen) ....27 Safety Information :......i Autocolor ........17 Satellite Receiver ......11 Bright ........... 17 Satellite Receiver Codes ..... 11 Color ........... Screen Displays ......27 Picture Reset ......17 Guide •...
Page 36
