- Page 1 IR-113E Quick Installation Guide 02-2012 / v1.0 ...
- Page 2 COPYRIGHT Copyright © Edimax Technology Co., Ltd. all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission from Edimax Technology Co., Ltd. Edimax Technology Co., Ltd. makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically disclaims any warranties, merchantability, or fitness for any particular purpose. Any software described in this manual is sold or licensed as is. Should the programs prove defective following their purchase, the buyer (and not this company, its distributor, or its dealer) assumes the entire cost of all necessary servicing, repair, and any incidental or consequential damages resulting from any defect in the software. Edimax Technology Co., Ltd. reserves the right to revise this publication and to make changes from time to time in the contents hereof without the obligation to notify any person of such revision or changes. The product you have purchased and the setup screen may appear slightly different from those shown in this QIG. For more information about this product, please refer to the user manual on the CD‐ROM. The software and specifications are subject to change without notice. Please visit our website www.edimax.com for updates. All brand and product names mentioned in this manual are trademarks and/or registered trademarks of their respective holders. Notice According to GNU General Public License Version 2 This product includes software that is subject to the GNU General Public License version 2. The program is free software and distributed without any warranty of the author. We offer, valid for at least three years, to give you, for a charge no more than the costs of physically performing source distribution, a complete machine‐readable copy of the corresponding source code. The GNU GPL and GNU LGPL software codes used in Edimax products are distributed without any warranty and are subject to the copyrights of their respective authors. The firmware files for this product can be found under the “Download” page at the Edimax website (www.edimax.com). 1 ...
-
Page 3: Product Introduction
PRODUCT INTRODUCTION Package Contents Before you start using this product, please check if there is anything missing from the package: 1 x Network camera 1 x Power adapter 1 x Sun shield 2 x Screw 1 x CD (with utility software, user manual & multi‐language QIG) 1 x Quick installation guide 1 x Bracket Connection Types No. Description 1 Blue, sensor in 1, for alarm input, DV 3.3 volt level allowed 2 Yellow, RS‐485 D‐ 3 Orange, RS‐485 D+ 4 Black, GND 5 Green, alarm out 1, DV 3.3 volt level allowed 6 ... -
Page 4: Installation
Front No. Description 1 IR LEDs for illumination in night mode 2 Day and night mode sensor for IR LED on/off control 3 Fixed focal lens INSTALLATION 1. Before powering on the camera, find the screws in the package and use a screwdriver to fix the sun shield onto the device’s main body. 2. Secure the wall mount bracket onto the wall, and then secure the camera onto the bracket. 3 ... - Page 5 Note: The bracket is an optional accessory. 3. Connect the network camera to a router/switch in the network via the Ethernet port. 4. Connect the power adapter to the network camera’s power connector. 5. Plug the power adapter into a power outlet. 6. You should see the green LED on the RJ‐45 port light up. If not, please recheck every step and try again, or contact your dealer for assistance. Note: The IR‐113E (PoE model) supports the IEEE 802.3af PoE standard. It can be powered via the Ethernet cable when connected to a PoE switch. ACCESSING THE NETWORK CAMERA’S MANAGEMENT INTERFACE By default, the network camera automatically obtains an IP address from the DHCP server on your local network. Check your DHCP server’s IP address lease table to find the network camera’s IP address, or use the EdiView Finder utility included in the CD. 1. Insert the CD into your CD‐ROM drive. When the wizard appears, click “Setup Utility” to install the “EdiView Finder” software. 4 ...
- Page 6 2. After the installation is complete, double‐click the “EdiView_Finder” icon to execute the application. 3. Click “Discover” to search for all the network cameras on your local network (make sure all the network cameras are powered on and connected to the network first). 5 ...
- Page 7 4. When you find a network camera, left click on it once and click “Link” to access it via the web browser. Note: You can also access the network camera’s management interface by entering the network camera’s IP address in the web browser’s URL bar (use Internet Explorer 7 and above for full functionality). 5. Log in the network camera. The default username is “admin” and the default password is “1234”. 6. The browser might ask you to install the ActiveX plug‐in. Allow the browser to install the plug‐in when prompted or you will not be able to see the video from the network camera. 6 ...
- Page 8 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1. Reorient or relocate the receiving antenna. 2. Increase the separation between the equipment and receiver. 3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 4. Consult the dealer or an experienced radio technician for help. FCC Caution This device and its antenna must not be co‐located or operating in conjunction with any other antenna or transmitter. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the authority to operate equipment. Federal Communications Commission (FCC) Radiation Exposure Statement This equipment complies with FCC radiation exposure set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than 2.5cm (1 inch) during normal operation. Federal Communications Commission (FCC) RF Exposure Requirements SAR compliance has been established in the laptop computer(s) configurations with PCMCIA slot on the side near the center, as tested in the application for certification, and can be used in laptop computer(s) with substantially similar physical dimensions, construction, and electrical and RF characteristics. Use in other devices such as PDAs or lap pads is not authorized. This transmitter is restricted for use with the specific antenna tested in the application for certification. The antenna(s) used for this transmitter must not be co‐located or operating in conjunction with any other antenna or transmitter. R&TTE Compliance Statement This equipment complies with all the requirements of DIRECTIVE 1999/5/EC OF THE EUROPEAN PARLIAMENT AND THE COUNCIL of March 9, 1999 on radio equipment and telecommunication terminal equipment and the mutual recognition of their conformity (R&TTE). The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal Equipment and Satellite Earth Station Equipment) As of April 8, 2000. ...
-
Page 9: Eu Declaration Of Conformity
EU Declaration of Conformity English: This equipment is in compliance with the essential requirements and other relevant provisions of Directive 2004/108/EC. French: Cet équipement est conforme aux exigences essentielles et autres dispositions de la directive 2004/108/EC. Czechian: Toto zařízení je v souladu se základními požadavky a ostatními příslušnými ustanoveními směrnic 2004/108/EC. Polish: Urządzenie jest zgodne z ogólnymi wymaganiami oraz szczególnymi warunkami określonymi Dyrektywą UE 2004/108/EC. Romanian: Acest echipament este în conformitate cu cerințele esențiale şi alte prevederi relevante ale Directivei 2004/108/EC. Russian: Это оборудование соответствует основным требованиям и положениям Директивы 2004/108/EC. Magyar: Ez a berendezés megfelel az alapvető követelményeknek és más vonatkozó irányelveknek 2004/108/EC. Türkçe: Bu cihaz 2004/108/EC direktifleri zorunlu istekler ve diğer hükümlerle ile uyumludur. Ukrainian: Обладнання відповідає вимогам і умовам директиви 2004/108/EC. Slovakian: Toto zariadenie spĺňa základné požiadavky a ďalšie príslušné ustanovenia smerníc 2004/108/EC. German: Dieses Gerät erfüllt die Voraussetzungen gemäß den Richtlinien 2004/108/EC. Spanish: El presente equipo cumple los requisitos esenciales de la Directiva 2004/108/EC. Italian: Questo apparecchio è conforme ai requisiti essenziali e alle altre disposizioni applicabili ... -
Page 10: Declaration Of Conformity
Declaration of Conformity We, Edimax Technology Co., Ltd., declare under our sole responsibility, that the equipment described below complies with the requirements of the European EMC directive (2004/108/EC). Equipment: 3Mpx Outdoor PoE True Day & Night Network Camera Model No.: IR‐113E Report No.: T120302D06‐E The following European standards for essential requirements have been followed: European Standard EN 55022:2006+A1: 2007, Class A CISPR 22: 2008 (Ed 6.0) EN61000‐3‐3:2008, EN61000‐3‐3:2008 EN 55024:1998+A1:2001+A2:2003 (IEC61000‐4‐2:2008 IEC 61000‐4‐3:2006 +A1:2007 IEC 61000‐4‐4:2004 IEC 61000‐4‐5:2005 IEC 61000‐4‐6:2008 IEC 61000‐4‐8:2009 IEC 61000‐4‐11: 2004) Edimax Technology Co., Ltd. ... - Page 11 Notice According to GNU General Public License Version 2 This product includes software that is subject to the GNU General Public License version 2. The program is free software and distributed without any warranty of the author. We offer, valid for at least three years, to give you, for a charge no more than the costs of physically performing source distribution, a complete machine‐readable copy of the corresponding source code. Das Produkt beinhaltet Software, die den Bedingungen der GNU/GPL‐Version 2 unterliegt. Das Programm ist eine sog. „Free Software“, der Autor stellt das Programm ohne irgendeine Gewährleistungen zur Verfügung. Wir bieten Ihnen für einen Zeitraum von drei Jahren an, eine vollständige maschinenlesbare Kopie des Quelltextes der Programme zur Verfügung zu stellen – zu nicht höheren Kosten als denen, die durch den physikalischen Kopiervorgang anfallen. GNU GENERAL PUBLIC LICENSE Version 2, June 1991 Copyright (C) 1989, 1991 Free Software Foundation, Inc. 51 Franklin Street, Fifth Floor, Boston, MA 02110‐1301, USA Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed. Preamble The licenses for most software are designed to take away your freedom to share and change it. By contrast, the GNU General Public License is intended to guarantee your freedom to share and change free software‐‐to make sure the software is free for all its users. This General Public License applies to most of the Free Software Foundation’s software and to any other program whose authors commit to using it. (Some other Free Software Foundation software is covered by the GNU Lesser General Public License instead.) You can apply it to your programs, too. When we speak of free software, we are referring to freedom, not price. Our General Public Licenses are designed to make sure that you have the freedom to distribute copies of free software (and charge for this service if you wish), that you receive source code or can get it if you want it, that you can change the software or use pieces of it in new free programs; and that you know you can do these things. To protect your rights, we need to make restrictions that forbid anyone to deny you these rights or to ask you to surrender the rights. These restrictions translate to certain responsibilities for you if you distribute copies of the software, or if you modify it. For example, if you distribute copies of such a program, whether gratis or for a fee, you must give the recipients all the rights that you have. You must make sure that they, too, receive or can get the source code. And you must show them these terms so they know their rights. We protect your rights with two steps: (1) copyright the software, and (2) offer you this license which gives you legal permission to copy, distribute and/or modify the software. ...
