DieHard 200.713151 Owner's Manual

15/2/125 amp fully automatic battery charger engine starter
Hide thumbs

Advertisement

Table of Contents

OWNER'S MANUAL
DieHard °
15/2/125 AMP
FULLY AUTOMATIC
BATTERY CHARGER
ENGINE STARTER
Model No.
200.713151
CAUTION:
Before first use of charger,
read this manual, and
follow
all its Safety and Operating
Instructions
with
every charger
use.
Save
these
instructions.
Made in U.S.A. of U.S. and imported parts.
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
599-198

Advertisement

Table of Contents
loading

Related Manuals for DieHard 200.713151

Summary of Contents for DieHard 200.713151

  • Page 1 OWNER'S MANUAL DieHard ° 15/2/125 AMP FULLY AUTOMATIC BATTERY CHARGER ENGINE STARTER Model No. 200.713151 CAUTION: Before first use of charger, read this manual, and follow all its Safety and Operating Instructions with every charger use. Save these instructions. Made in U.S.A. of U.S. and imported parts.
  • Page 2 .................... PARTS ........................Wiring Diagram ....................Please read this Owner's Manual before using your Battery Charger The DieHard model 200.713151, Fully Automatic Battery Charger/Engine Starter, offers a wide range of features for home or light commercial use. This manual will show you how to use your charger safely and effectively.

  • Page 3: Help Us Help You

    HELP US HELP YOU -- WARNING: To reduce the risk of explosion, explosive gases, or injury Remember: while using your battery charger, follow • Place charger as far away from battery the precautions listed below: being charged as the charger cables •...

  • Page 4: Personal Safety Precautions

    Personal Safety Precautions For your own personal safety, please follow the following precautions: • Remove all personal metal items • Wear complete eye and clothing protection when working with lead- from your body, such as rings, acid batteries. bracelets, necklaces, and watches while working with a lead-acid battery.

  • Page 5: Using An Extension

    It is important to understand your charger's requirements. This section will tell you about your charger's electrical requirements and how to prepare a battery for charging. USING AN EXTENSION CORD PLUGGING IT IN The use of an extension cord is not WARNING: Electrical Shock Hazard.

  • Page 6: Selector Switches

    It is important that you road and follow these guidelines while you are preparing to charge yourbattery. cell caps while charging, and Make sure that you have a 12 volt or recommended rates of charge. 6 volt lead-acid battery. Set the selector switch to match the voltage •...

  • Page 7: Led Indicators

    AMMETER: Charge Type: The ammeter indicates the measured • Use the MANUAL setting only ifyou check the charging progress frequently. amount of amperes being drawn by the The charger will not stop charging when battery. When you first start charging a the battery reaches full charge, possibly battery, the reading will be high, with damaging the battery if left on too long.

  • Page 8: Charging Your Battery

    Identify which battery post is ground GREEN, STEADY GLOW: or connected to the chassis. THE • In AUTOMATIC, the green LED NEGATIVE POST IS NORMALLY indicator will glow steadily and the THE ONE THAT IS GROUNDED, meter needle will be at zero when the charger has completed the charging To charge a negative grounded cycle.

  • Page 9: Using Your Battery Charger

    sparking occur, it will be at a distance from the battery. NOTE: The battery cable is not provided with the charger, but may be purchased at most automotive stores. Take the other end of the 6-gauge (AWG) or a 4-gauge (SAE) insulated 24-inch cable and, standing as far away from the battery as possible, NEGATIVE...
  • Page 10 NEGATIVE post first. Then remove the lead from the POSITIVE post. POSITIVE NEGATIVE 12. Clean and store the battery charger BATTERY a dry location. 24", 6 GAUGE CABLE GROUNDED POWER Figure OUTLET Your battery charger can be used to jump start your car if the battery is low. Follow these instructions on how to use the ENGINE START feature.
  • Page 11 Battery Rating Method Use the following chart to determine the approximate time it will take to fully charge a battery that is initially at 50% State-of-Charge. Identify your battery type and its associated Charge Time in the table. Common battery types are: •...
  • Page 12 Charge Time Needed if Amp-Hours is Known • Find the Charge Factor for your battery in the table on page 11. • Multiply by the Amp-Hour rating of the battery. • Divide by the Charger Setting (either 2 Amp or 15 Amp). •...
  • Page 13 Performance problems often result from little things that you can fix yourself. Please read through this chart for a possible solution if a problem occurs. No ammeter Clamps not making good The red LED should be glowing steadily. connection. reading Check for poor connection at battery.
  • Page 14 This section shows an illustration of your battery charger. Use it to become familiar with where all the parts are located, and what they look like. Item Description Part Number Item Description Part Number Transformer 93026454 AC Powercord 90026112 HeatsinkControl Module 2299000995 Handle 3599000270...
  • Page 15 MOV18 3n78...

  • Page 16: Troubleshooting

    For information about troubleshooting Call toll-free from anywhere in the U.S.A. 7 am to 4:30 pm CST Monday through Friday 1-800-732-7764 For the repair or replacement parts you need Call 7 am - 7 pro, 7 days a week 1-800-366-PART (1-800-366-7278) For the location of an authorized Sears Service Center in your area...
