1. Mode / Menu: Press to select PHOTO or VIDEO
mode. For PHOTO or VIDEO setting, press and
hold it for 2~3 seconds.
2. LEFT: For LEFT selection in menu mode.
3. UP: For UP selection in menu mode. Digital
zoom in.
Digital Video Camera
4. RIGHT: For RIGHT selection in menu mode. To
change exposure value, set up in photo or video
Model: DV-80005
mode.
5. DELETE / Power on or off button: Press and
hold it for 2 seconds to turn ON/OFF the unit.
USER MANUAL
Press it to delete file in PLAYBACK mode.
6. REC: Press this button to take photographs.
To start or stop a video clip recording. Use to
confirm changes in menu mode.
OVERVIEW
7. DOWN: For DOWN selection in menu mode.
Digital zoom out.
FRONT VIEW
8. Playback: Press to enter Playback mode.
EXPLANATION OF THE STATUS ICONS
1
2
1
2
3
3
10
4
5
6
7
1. LCD screen: Display photographs, video clips,
7
8
9
camera settings and menu.
2. Macro switch:
1. Recording mode:
Macro mode: Select this mode to take close
Photograph mode.
-up photographs (distance 11cm - 18cm).
Video mode.
Normal mode: Select this mode to take
2. Counting indicator:
photographs from 0.5m - infinity.
Show time left in Video mode.
3. Speaker: Speaker hole.
Show picture left in Photo mode.
4. Battery door: Door for battery & SD card.
Show recording time during recording.
5. Strap hook: Hook for attaching the wrist strap to
3. Digital zoom: Show digital zoom value.
the camera.
4. Battery indicator:
6. SD card slot: SD card storage location.
Battery at full charge.
7. Battery: 3.7V Li-ion battery.
No charge left in battery.
5. White balance: White balance selection.
6. Date stamp: Date/ Time/ Date and Time / Off
REAR VIEW
7. Selected resolution:
Photo-3M,5M,8M.
Video-QVGA,WVGA,720P30.
8. Normal / Macro mode indicator:
4
Normal mode (0.5m – infinity).
1
Macro mode (11cm –18cm).
2
9. SD card indication:
The SD card is inserted and will be used as
3
storage for PHOTO and VIDEO.
5
10. Self-timer: On/Off.
DETAILS FOR CAMERA SETTING
6
PHOTO SETTING
7
In photo mode, press the MODE/MENU button
and hold for 2 to 3 sec to enter photo set up mode.
8
Quality
Super Fine (Default)
Picture quality setting
/Fine /Normal
1.
LED
indicator: Illuminates while battery is
Size
recharging.
3.0M pixel resolution
2048 x 1536
2. Lens: Records the image .
5.0M pixel resolution
2592 x 1944
Note Keep the lens clean. Dirt and fingerprints
8.0M pixel resolution
3200 x 2400
will affect the quality of the picture.
3. Microphone: For voice input.
Self-timer
4:
USB
interface: Download photographs and
On
Self-timer selected,
video clips to a computer.
10 sec delay
5.
USB
switch: Slide it to pop-up the USB
Off
Turn off the self-timer,
interface.
disable
6.
DC in
only: Recharge the battery via
transformer provided.
7.
Video
out: Connect to output content to TV.
VIDEO SETTING
Audio
out: Connect to output audio to TV.
8.
In video mode, press the MODE/MENU button
and hold for 2 to 3 sec to enter video set up mode.
BUTON VIEW
Resolution
1
2
3
4
5
720P30
HD (1280x720),
up to 30fps
WVGA
WVGA (848x480),
up to 60fps
QVGA
QVGA (320x240),
up to 30fps
Quality
Super Fine(Default)
Quality setting
/Fine /Normal
6
7
8
Front Side
Flicker
• To completely disconnect from power, the
60Hz
Main American
adaptor should be disconnected from the mains.
• The main unit and adaptor should not be
electricity frequency
exposed to wet conditions. No objects filled with
50Hz
Main European
liquid, such as vases, should be placed on the
electricity frequency
main unit and adaptor.
White Balance
Auto (Default)
Automatic white balance
Sunny
White balance selected
for Sunny surrounding
Cloudy
White balance selected
for cloudy surrounding
Fluorescent
White balance selected
for fluorescent
surrounding
Incandescent
White balance selected
for Incandescent lighting
Contrast
Standard /
Hard / Soft
Contrast setting
4
Sharpness
Standard /
Hard / Soft
Sharpness setting
AE meter
Center / Average /
5
Spot
AE meter setting
INSERTING A MEMORY CARD
AE ISO
(NOT INCLUDED)
Auto/100/200/400
AE ISO setting
6
Follow the instructions given below to insert an
SETUP
SD memory card into the camera.
1. Turn off the camera.
In photo/video set up mode, select SETUP icon
2. Open the battery door.
3. Insert the SD card into the camera by clicking
by pressing ( ) button to enter basic set up mode.
it in.
Language
English/T-Chinese/
Note There is only one right direction to insert
S-Chinese/French/
the SD memory card into the slot. Do not force the
German/Italian/
Select display language
card into the slot, or it may damage both the
Spanish/Portuguese/
camera and the SD memory card.
Dutch
Note The SD memory card must be formatted
before taking photographs. See the following
TV standard
section for more information.
NTSC
American and Japanese
video format
PAL
European video format
Date / Time
Year / Month / Day /
Hour / Minute
Date and Time setting
Display
Off
No display
Date
Display the Date
Time
Display the time
Date / Time
Display the Date and
Time
Format
Yes / No
Format the SD card
Default
Yes / No
Refresh the default
FORMATTING THE MEMORY OR
setting
SD CARD
Auto Power-Off
Off
Auto Power-Off off
1. In photo/video set up mode, select SETUP icon
3 min
Auto power off after
by pressing ( ) button to enter basic set up
3 mins if no operation
mode.
5 min
Auto power off after
2. Select FORMAT icon by pressing the ( ) button
5 mins if no operation
and press(
)button to confirm, select YES
by pressing the ( ) button.
Version
3. Press the(
)button to confirm formatting the
SD card.
Note: The camera will remain the last setting
when it is turned off.
SETTING THE RESOLUTION
The HD DV camera can be set to different
USING THE CAMERA
resolutions.
INSTALLING THE BATTERY
VIDEO
The battery is partially charged at shipment and
1. Press and hold the (MODE/MENU) button in
must be fully charged before being used.
video mode to enter the video set up menu.
1. Open the battery cover.
2. Select the RESOLUTION by pressing the (▼)
2. Insert the 3.7V Li-ion rechargeable battery into
button. Press the (
the camera.
resolution selection.
3. Replace the battery cover.
3. Different resolutions will be displayed. Select
the desired resolution by using the (▲) or (▼)
button. Press the REC button to confirm the
ADAPTOR
selection.
1. Plug adaptor into socket.
720P30 (1280 x 720),
WVGA (848 x 480),
Note
QVGA (320 x 240).
• Make sure the adaptor is not obstructed and is
easily accessible to the unit.
Size: 280x350mm
1. Press and hold the (MODE/MENU) button in
photo mode to enter the photo set up menu.
2. Select the SIZE icon by pressing the (▼) button
and press the (
) button to confirm.
3. Different resolutions will be displayed. Select
the desired resolution by using the (▲) or (▼)
buttons and press the REC button to confirm
the selection.
3.0M (2048 x 1536),
5M (2592 x 1944),
8M (3200 x 2400).
TAKING VIDEO OR PHOTOGRAPHS
1. Turn on the HD DV camera.
2. Press the
(MODE/MENU)
button to select the
photo mode (
) or video mode (
3. Depending on the distance to the object being
photographed, use the Macro switch to adjust
the distance. Select the flower symbol (
you wish to take a close-up photograph
(11cm –18cm).
If you wish to take a video or photograph of
surroundings or people (0.5m - infinity), set the
Macro switch to the Normal mode (
4. Use the LCD screen as a viewfinder to take
videos or photos.
5. Press the (
) button once for photo taking,
or press the(
) button to start/stop video
recording.
6. The HD DV camera can zoom in up to 3 times.
Zoom in or out by pushing (▲ or ▼).
CAUTION
• Taking photos of fast-moving objects is not
recommended.
• Image may be distorted when taking pictures in
a moving vehicle.
• Max video file size is 4GB.The unit will stop
recording automatically.
ZOOM IN AND OUT
The HD DV camera can zoom in up to 3 times.
Zoom in or out by pushing (▲ or ▼).
PLAYBACK PHOTOGRAPHS/VIDEOS
CLIPS
1. Press the PLAYBACK (
) button once to enter
the photo / video playback mode, press (
again to select either PHOTO / VIDEO
2. Thumbnail views will be displayed. Use
(▲,▼,
or ) to select photo/video.
3. Press REC button to confirm selection.
4. In viewing a photo, push (▲or▼) to zoom in
or out.
5. In viewing different parts of enlarged photo,
press MODE/MENU or REC button to move up
or down, press ( or ) to move left or right.
6. In viewing photo in full screen, press ( or ) to
view previous or next photo.
7. In viewing a video clips, Press the REC button
to start playing the video and press again to
pause.
8. When playing the video, press ( ) to fast
forward or press ( ) to rewind.
DELETE PHOTOGRAPHS/VIDEO CLIPS
Follow the instructions given below to delete a
photo/video clip.
1. Press the PLAYBACK (
) button to enter the
photo/video clip playback mode.
2. Press the PLAYBACK (
) button once to enter
the photo / video playback mode, press (
again to select either PHOTO / VIDEO
3. Press the DELETE button to enter the delete
mode.
4. Press ( or ) to select if delete this file or
delete all then press (
) to confirm.
5. Press (MODE/MENU) to exit.
CONNECTING THE DV CAMERA
CONNECT TO TV
)button to enter the
For high definition TV display, please connect the
component output as shown below:
Back Side
For standard quality TV display, connect as below:
CAUSE
1. Low battery power. Battery not inserted
properly.
2. The memory card hasn't been formatted
properly or memory is full.
3. Connection failure.
4. Use of wrong type of battery.
5.1. The HD DV camera is not held steadily
5.2. The lens of HD DV camera is dirty.
5.3. The HD DV camera is set to the wrong focus
mode.
CONNECT TO COMPUTER
SOLUTION
The camera can be connected to the computer
as a mass storage device to download videos
1. Fully charge or install the battery correctly.
and photos to a PC.
2. Format the memory in SETUP mode of the
camera. Please refer to section (Formatting the
).
memory or SD card).
SPECIFICATIONS
3. Make sure all cable connections are secured
and restart the computer if necessary.
) if
Sensor
4. Replace with new 3.7V Li-ion rechargeable
5.0 Mega pixel CMOS sensor
battery.
5.1. Hold the HD DV camera steadily until it
Image resolution
beeps when taking video/photo.
DV
720P30 (1280x720), up to 30fps
5.2. Clean the lens with soft dry cloth.
).
WVGA (848x480), up to 60fps
5.3. Set the macro/normal mode according to the
QVGA (320x240), up to 30fps
distances of subject.
DC
8.0 Mega pixels: (3200x2400)
(Hardware Interpolation)
5.0 Mega pixels: (2592x1944)
PRECAUTIONS
3.0 Mega pixels: (2048x1536)
1. Do not subject the unit to excessive force,
Lens
shock, dust, temperature or humidity.
F/2.8 f=8.5mm
2. Do not cover the ventilation holes with any
items such as newspapers, curtains etc.
Focus range
3. Do not immerse the unit in water. If you
0.5m. ~ Infinity
spill liquid over it, dry it immediately with
a soft, lint-free cloth.
Macro mode
4. Do not clean the unit with abrasive or
11cm – 18cm
corrosive materials.
5. Do not tamper with the unit's internal
Digital zoom
components. This invalidates the warranty.
3x
6. Images shown in this manual may differ
from the actual display.
LCD display
7. When disposing of this product, ensure it
2.4" true color LTPS TFT LCD
is collected separately for special
treatment and not as normal household
White balance
waste.
Auto / Sunny / Cloudy / Fluorescent /
8. Placement of this product on certain types
Incandescent
of wood may result in damage to its finish
for which Oregon Scientific will not be
DV mode
)
responsible. Consult the furniture
Up to 30fps@HD (1280x720)
manufacturer's care instructions for
information.
External memory card
9. The contents of this manual may not be
SD card supports up to 32G
reproduced without the permission of the
manufacturer.
File format
10. Do not dispose old batteries as unsorted
Picture: JPEG, Video: MOV,
municipal waste. Collection of such
waste separately for special treatment is
PC interface
necessary.
USB 2.0
11. Should there be any discrepancy
between the English and other language
TV-out
versions, the English version shall apply
Component output / TV output
and prevail.
Power source
NOTE The technical specifications for this product
3.7V Li-ion rechargeable battery.
and the contents of the user manual are subject to
change without notice.
SYSTEM REQUIREMENT
NOTE Features and accessories will not be
available in all countries. For more information,
Operating System
please contact your local retailer.
Windows XP/Vista or above Win 7
Mac 10.4.9 or above
ABOUT OREGON SCIENTIFIC
CPU
Pentium 4 / 3.0Ghz or above
)
Visit our website (www.oregonscientific.com) to
learn more about Oregon Scientific products.
RAM
At least 1GB
If you're in the US and would like to contact our
Customer Care department directly, please visit:
Interface
https://us.oregonscientific.com/service/support.asp
USB port
For international inquiries, please visit: https://us.
oregonscientific.com/about/international.asp
Display Card
nVidia Geforce 7600 or ATI X 1600 or above
EU-DECLARATION OF CONFORMITY
TROUBLESHOOTONG
Hereby, Oregon Scientific, declares that this
PROBLEM
Digital Video Camera (Model: DV-80005) is in
compliance with the essential requirements and
1. Cannot turn on the unit.
other relevant provisions of Directive 1999/5/EC.
2. Photos cannot be saved when taking pictures.
A copy of the signed and dated Declaration of
3. Cannot find removable disk after connecting
Conformity is available on request via our Oregon
the camera to the computer.
Scientific Customer Service.
4. The battery life is very short.
5. The photos are blurry.
FCC STATEMENT
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any
interference received, including interference that
may cause undesired operation.
WARNING Changes or modifications not
expressly approved by the party responsible for
compliance could void the user's authority to
operate the equipment.
NOTE This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses and can radiate radio frequency energy and,
if not installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is encouraged
to try to correct the interference by one or more of
the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment
and receiver.
3. Connect the equipment into an outlet on a
circuit.
4. Consult the dealer or an experienced radio /
TV technician for help.
DECLARATION OF CONFORMITY
The following information is not to be used as
contact for support or sales. Please call our
customer service number (listed on our website at
www.oregonscientific.com), or on the warranty
card for this product) for all inquiries instead.
We
Name:
Oregon Scientific, Inc.
Address:
19861 SW 95th Ave.,Tualatin,
Oregon 97062 USA
Telephone No.: 1-800-853-8883
Declare that the product
Product No.:
DV-80005
Product Name:
Digital Video Camera
Manufacturer:
IDT Technology Limited
Address:
Block C, 9/F, Kaiser Estate,
Phase 1, 41 Man Yue St.,
Hung Hom, Kowloon,
Hong Kong
is in conformity with Part 15 of the FCC Rules.
Operation is subject to the following two
conditions:
1) This device may not cause harmful interference,
2) This device must accept any interference
received, including interference that may
cause undesired operation.
Advertisement
