Operating Instructions & Parts Manual
Long Chassis Hydraulic Service Jacks
Model
22040C, 22041C
22050C, 22051C
22100C, 22101C
Models 22040C, 22050C & 22100C
U.S. Patent No's. 5,755,099 • 5,946,912 • 5,341,723
!
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
ADVERTENCIA
!
• Leer, comprender, y seguir las instrucciónes antes
de utilizar el aparato.
• El manual de instrucciónes y la información de
seguridad deben estar comunicado en lengua del
operador antes del uso.
• No seguir estas indicaciónes puede causar daños
personales o materiales.
Read this manual and follow all the Safety Rules and Operating Instructions before using this product.
Capacity
4 Ton
5 Ton
10 Ton
Models 22041C, 22051C & 22101C (Air Options)
WARNING
!
To avoid crushing and related injuries:
NEVER work on, under or around a
load supported only by a hydraulic
jack. ALWAYS use adequately rated
jack stands.
SFA Companies
http://www.omegalift.com
Printed in China
22040C-M1 rev 06/08
Advertisement
Table of Contents
Related Manuals for Omega 22040C
Summary of Contents for Omega 22040C
- Page 1 Operating Instructions & Parts Manual Long Chassis Hydraulic Service Jacks Capacity Model 4 Ton 22040C, 22041C 5 Ton 22050C, 22051C 10 Ton 22100C, 22101C Models 22040C, 22050C & 22100C Models 22041C, 22051C & 22101C (Air Options) U.S. Patent No's. 5,755,099 • 5,946,912 • 5,341,723 This is the safety alert symbol.
-
Page 2: Product Description
PRODUCT DESCRIPTION Omega Long Chassis Hydraulic Service Jacks are designed to lift, but not support, one end of a vehicle. Immediately after lifting, loads must be supported by a pair of appropriately rated jack stands. Air actuated function available for Models 22041C, 22051C &... - Page 3 Before Use 1. Verify that the product and application are compatible, if in doubt call Omega Technical Service (888) 332-6419. 2. Before using this product, read the operator's manual completely and familiarize yourself thoroughly with the product, its components and recognize the hazards associated with its use.
-
Page 4: Operation
WARNING WARNING • Study, understand, and follow all printed materials provided with/on this product before use. • Do not exceed rated capacity. • Use only on hard, level surface. To avoid crushing and related injuries: • This is a lifting device only! •... -
Page 5: Maintenance
Jack will lift, but not maintain • Release valve not tightly closed • Ensure release valve tightly closed pressure • Hydraulic unit malfunction • Discontinue use, contact Omega technical service Jack will not lower after unloading • Reservoir overfilled • Drain fluid to proper level •... - Page 6 Replacement parts illustration for Model 22040C Figure 2 - Replacement Parts Illustration for Model 22040C...
- Page 7 Replacement parts illustration for Model 22041C Figure 3 - Replacement Parts Illustration for Model 22041C...
- Page 8 Replacement Parts List for Models 22040C & 22041C: Item 22040C Part# 22041C Part# Description G251-20008-000 Filter G423-20003-000 Reservoir 5905-00100-100 Filler Plug 5901-00071-000 O-ring, D7.1x2.65 G251-20004-000 G250-20004-000 Release Valve G100-43000-000 Hyd. Cartridge B300-14002-000 Washer G651-31002-000 Pump Cylinder G651-31001-000 Pump Piston G100-44000-000 Hyd.
- Page 9 Replacement parts illustration for Models 22050C & 22051C Figure 4 - Replacement Parts Illustration for Model 22050C & 22051C...
- Page 10 Replacement Parts List for Models 22050C & 22051C: Item 22050C 22051C Description G251-20008-000 Filter G250-20002-000 Reservoir 5905-00100-200 Filler Plug 5901-00071-000 O-ring, D7.1x2.65 G250-20004-000 Release Valve G250-24000-000 Hyd. Cartridge B300-14002-000 Washer G651-31002-000 Pump Cylinder G651-31001-000 Pump Piston G250-23000-000 Hyd. Cartridge G250-30000-000 Universal Joint G251-00005-000 Spring...
- Page 11 Replacement parts illustration for Models 22100C & 22101C Figure 5 - Replacement Parts Illustration for Model 22100C & 22101C...
- Page 12 Replacement Parts List for Models 22100C & 22101C: Item 22100C 22101C Description G251-20008-000 Filter G100-40003-000 Reservoir G62S-03301-000 Filler Screw 5901-00071-000 O-ring, D7.1x2.65 G251-20004-000 Release Valve G100-43000-000 Hyd. Cartridge B300-14002-000 Washer G651-31002-000 Pump Cylinder G651-31001-000 Pump Piston G100-44000-000 Hyd. Cartridge G100-90009-K04 Universal Joint 5405-12039-000 5404-02028-000...
