Operator's
Manual
MORTISING CHISEL KIT
351.264271
CAUTION:
Read and follow all Safety
Rules and Operating
Instructions
before First Use
of this Product.
• Safety
• Assembly
• Operation
• Maintenance
• Parts List
• Espahol
Sears, Roebuck
and Co., Hoffman
Estates,
IL 60179 U.S.A.
www.sears.com/craftsman
17350.01 Draft (11/11/02)
Advertisement
Related Manuals for Craftsman 351.264271
Summary of Contents for Craftsman 351.264271
- Page 1 CAUTION: • Assembly Read and follow all Safety Rules and Operating • Operation Instructions before First Use • Maintenance of this Product. • Parts List • Espahol Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A. www.sears.com/craftsman 17350.01 Draft (11/11/02)
- Page 2 Warranty ....... Operation ....Maintenance ....Safety Rules ....Parts Illustration and List ..Assembly ...... Installation ....EspaSol ..... 8-11 FULL ONE YEAR WARRANTY If this product fails due to a defect in material or workmanship within one year from the date of purchase, Sears will at its option repair or replace it free of charge.
- Page 3 KNOW HOW TO USE TOOL • Use of improper accessories may cause risk of injury to persons. • Use right tool for job. Do not force tool or attachment to do a job for • Handle workpiece correctly. Protect which it was not designed. hands from possible injury.
- Page 4 Raise the chisel frequently during operation to allow free discharge of Refer to Figure 1. chips and prevent clogging the bit. The Craftsman Mortising Chisel Kit con- • To ensure a clean joint, each suc- verts most drill presses into an accurate cessive cut should overlap the previ- mortising machine.
- Page 5 Care should b eexercised when feed- High speed should n ever b e employed, asitwilt c ause o verheat- ingthetool i ntothe work. Inworking with hard woods a nd other woods ingand quickly dull t heedges o fboth chisel and bit.Best r esults are that a remore difficult tomachine, it is advisable touse a slower feed rate.
- Page 6 Model 351.264271 Figure 2 - Replacement Parts Illustration for Mortising Chisel Kit...
- Page 7 PART NO. DESCRIPTION QTY. 07115.00 Housing 08358.00 60mm Split Bushing 08359.00 66mm Split Bushing 17340.00 40mm Two-piece Bushing 17341.00 48mm Two-piece Bushing 17342.00 50mm Two-piece Bushing STD835050 8-1.25 x 50mm Hex Head Bolt* 17343.00 Ratchet Handle 07118.00 Thumb Screw 17344.00 Clamp 17345.00 Ratchet Handle...
- Page 8 Your Home For repair - in your home - of all major brand appliances, lawn and garden equipment, or heating and cooling systems, no matter who made it, no matter who sold it! For the replacement parts, accessories owner's manuals that you need to do-it-yourself. For Sears professional installation of home appliances...
