Network and Storage Planning
Table 3: Capacity Table VA7100/VA7110 for RAID 1+0
Drive Size
2
Hot Spares
No. of Drives
VA7100 min - 4 32.2
5 48.6
6 68.0
7 85.9
8 103.8
9 157.6
VA7110 min - 10 175.5
11 193.4
12 211.3
13 229.3
14 247.2
max VA7100 - 15 265.1
VA7110 - 15 258.6
VA7110 - 30 527.4
max VA7110 - 45 796.1
Table 4: Capacity Table VA7100/VA7110 for AutoRAID
Drive Size
2
Hot Spares
No. of Drives
VA7100 min - 4 32.2
5 48.6
6 68.0
7 101.2
8 134.2
9 165.4
VA7110 min - 10 198.4
11 231.3
12 264.1
13 296.9
14 329.6
max VA7100 - 15 362.4
VA7110 - 15 350.2
VA7110 - 30 840.0
max VA7110 - 45 1329.0
22
36 GB
1 0
48.6 68.0
68.0 85.9
85.9 103.8
121.7 121.7
139.7 139.7
157.6 157.6
175.5 175.5
193.4 193.4
211.3 211.3
229.3 229.3
247.2 247.2
265.1 265.1
258.6 258.6
527.4 527.4
796.1 796.1
VA7110 is not currently qualified on dedicated storage configurations.
36 GB
1 0
48.6 68.0
68.0 101.2
101.2 134.2
134.2 165.4
165.4 198.4
198.4 231.3
231.3 264.1
264.1 296.9
296.9 329.6
329.6 362.4
362.4 395.1
395.1 427.7
382.9 415.6
872.6 905.2
1361.5 1394.1
