Frigidaire FPDF4085KF - 40" Dual Fuel Range Product Specifications

40" dual fuel freestanding range
Hide thumbs Also See for FPDF4085KF - 40" Dual Fuel Range:

Advertisement

Freestanding Range
FPDF4085K F
Signature Features
SpaceWise® Side Oven
This range features an extra 1.7 Cu. Ft.
SpaceWise® side oven that gives you
more space to cook multiple dishes at
the same time.
True Convection
1
Multi-rack baking is faster and more
even with True Convection.
Dual-Fuel Technology
Features the power of a gas cooktop
and the precision of an electric oven for
baking, so you get maximum versatility.
Pro-Select® Controls
Precise control at your fingertips.
40" Dual Fuel
Product Dimensions
Height (Max.)
48-1/8"
Width
40-1/8"
Depth (Including Handle)
28-1/2"
More Easy-To-Use Features
One-Touch Keep Warm Setting
Just one touch of a button keeps food
warm until everything — and everyone—
 is ready.
Real Stainless Steel
Real stainless steel with a protective
coating that reduces fingerprints and
smudges so it's easy to clean.
Delay Start
Set your oven to begin cooking on
your schedule. It can be programmed
from 1 to 24 hours.
Heavy-Duty Grates and
Professional-Style Knobs
"My Favorite" Setting
Easily program your most used setting
with the touch of a button.
Continuous Grates
Continuous Grates make it easy to
move heavy pots and pans between
burners without lifting.
Even Baking Technology
Our latest technology ensures even
baking every time.
Auto Shut-Off
As an extra safety measure, the oven
will automatically shut off after 6 hours.
Sabbath Mode (Star-K® Certified)
Available in:
Stainless
(F)
Burners
BTU
Right Front
9,100
Right Rear
5,000
Left Front
13,000
Left Rear
5,000
Center Extra Zone
9,100
1
Main oven only.
frigidaire.com

Advertisement

loading

Summary of Contents for Frigidaire FPDF4085KF - 40" Dual Fuel Range

  • Page 1 Burners Right Front 9,100 Right Rear 5,000 Left Front 13,000 True Convection Pro-Select® Controls Left Rear 5,000 Multi-rack baking is faster and more Precise control at your fingertips. Center Extra Zone 9,100 even with True Convection. Main oven only. frigidaire.com...
  • Page 2 Auxiliary Oven Racks 1 Standard NOTE: For planning purposes only. Always consult local and national electric and gas codes. Certifications Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com. Sabbath Mode (Star-K® Cert.) Specifications Product Dimensions Cutout Dimensions Main Oven Interior ( H x W x D )
  • Page 3 Gas supply piping can be routed through side wall of right cabinet. Note: For planning purposes only. Refer to Product Installation Guide Right side cabinet is ideal location for main shutoff valve. on the web at frigidaire.com for detailed instructions. • Overhead cabinetry should not exceed a 13" maximum depth.
  • Page 4: General Installation Guidelines

    General Installation Guidelines with Side-by-Side Refrigerator Use these dimensions and clearance instructions for planning purposes only. For detailed installation instructions, refer to installation guide, packed with product, or on the web at frigidaire.com. Front Front 10200 David Taylor Drive Charlotte, NC 28262 1-800-FRIGIDAIRE frigidaire.com...
  • Page 5 General Installation Guidelines with Top Mount Refrigerator Use these dimensions and clearance instructions for planning purposes only. For detailed installation instructions, refer to installation guide, packed with product, or on the web at frigidaire.com. Front Front 10200 David Taylor Drive...

This manual is also suitable for:

Fpdf4085kf
