  • Page 1: Setup Guide

    MODEL FO-2150CM SETUP GUIDE SHARP COLOR MFP...

  • Page 2: Unpacking Checklist

    Document tray Rapid key labels Setup Guide Paper cover Quick Reference Guide Paper tray Sharp Color MFP CD-ROM Handset Handset lead Telephone line cord Color and black Adapter Adapter print cartridges (for New Zealand) (for Australia) (one each)
  • Page 3 2. Trays Attach the document tray. Insert the paper tray into the back of the machine as shown. Pull out the original document support and the output tray. Note: When receiving faxes, copying or printing, do not let a large number of pages accumulate in the output tray. This may obstruct the outlet and cause paper jams.
  • Page 4 3. Connections Handset Connect the handset as shown and place it on the handset rest. The ends of the handset lead are identical, so they will go into either socket. Make sure the handset cord goes into the unmarked socket on the side of the machine! Use the handset to make ordinary phone...
  • Page 5 Connections Parallel cable Connect the Sharp Color MFP to your computer with a parallel cable. If you do not have a parallel cable, you can purchase one from your dealer or any computer store. Make sure the cable is IEEE 1284-compliant. We recommend a shielded cable no longer than 2 meters.

  • Page 6: Power Lead

    Connections Power lead Plug the power lead into a 230-240 V, 50 Hz, earthed (3-prong) AC outlet. Caution: When disconnecting the fax, unplug the telephone line cord before unplugging the power lead. Caution: The mains outlet (socket outlet) should be installed near the equipment and be easily accessable.
  • Page 7 Do not insert it into the TEL. SET socket. Note: The Sharp MFP is set for tone dialling. If you are on a pulse dial line, you must set the Sharp MFP for pulse dialling. Press the following keys on the operation panel:...
  • Page 8 Extension phone (optional) If desired, you can connect an extension phone to the TEL. SET socket on the fax. To connect an answering machine to the Sharp Color MFP, see Answering Machine Connection in Chapter 7 of your online Operation Guide.

  • Page 9: Installing A Print Cartridge

    4. Installing a Print Cartridge We recommend that you Your Sharp Color MFP keep a black cartridge uses either a FO-25CC installed for normal use, color print cartridge or a and change to a color FO-21BC black print cartridge only when you cartridge.
  • Page 10 Installing a Print Cartridge Open the front cover of the Sharp Color MFP. Note on changing cartridges: When you need to change a print cartridge, remove the currently installed cartridge after Step 2 above. Remove the cartridge by pulling the knob on the cartridge toward you until you hear a click.
  • Page 11 Installing a Print Cartridge Gently remove the sticker and transparent tape covering the copper printhead. Do not touch the copper-colored area! Insert the print cartridge into the cartridge carrier. Push back on the cartridge until it snaps into place. Note: If the print cartridge moves loosely in the carrier, it is not locked into place.
  • Page 12 NEW COLOR CART. The cartridge will return to its home position. If you pressed 3 or 4 for a new cartridge, the Sharp MFP will print a test page for printhead alignment. If you installed a new print cartridge, look at the test page and locate the line that comes closest to forming a perfectly straight line.
  • Page 13 Installing a Print Cartridge Press these keys on the Sharp MFP: The display will show: ALIGN CARTRIDGE ENTER (00-30) 15 START: PRINT Enter the two-digit number of the straightest line on the test page. (If the number is less than 10, enter a 0 before the number.)

  • Page 14: Loading Printing Paper

    5. Loading Printing Paper You can load A4 size paper in the paper tray. The maximum number of sheets is: 200 for paper from 60 to 80 g/m 150 for paper from 80 to 90 g/m (such as coated paper) Remove the paper cover if it is on the paper tray.
  • Page 15 Loading Printing Paper Insert the stack of paper into the tray, print side up. If paper remains in the tray, take it out and combine it into a single stack with the new paper before adding the new paper. Replace the paper cover on the paper tray. Push the paper release plate back down.

  • Page 16: Paper Size

    Loading Printing Paper The Sharp Color MFP has been set at the factory to scale the size of received faxes to A4 size paper. If you need to change the paper size setting, press these keys: The display will show: PAPER SIZE Press 1 to select LETTER, 2 to select LEGAL, or 3 to select A4.

  • Page 17: Entering Your Name And Fax Number

    6. Entering Your Name and Fax Number To send faxes directly from Once you enter this the Sharp Color MFP, you information, it will must enter your name and automatically appear fax (telephone) number. at the top of each fax You must also set the date page you send.
  • Page 18 Entering Your Name and Number Press the # key twice: The display will show: OWN NUMBER SET Press the START key. The display will show: ENTER FAX # Enter your fax number by pressing the number keys. Up to 20 digits can be entered.
  • Page 19 To enter two letters in succession that require the same key, press the SPEAKER key after entering the first letter to advance the cursor. Example: SHARP = 7 7 7 7 7 4 4 4 2 2 7 7 7 7 SPACE = Press this key to delete the letter highlighted by the cursor.

  • Page 20: Setting The Date And Time

    FUNCTION key * key START key STOP key Press these keys: The display will show: ENTRY MODE Press the * key two times. The display will show: DATE & TIME SET Note: The Sharp Color MFP is Year 2000 compliant.
  • Page 21 Setting the Date and Time Press the START key. The currently set date will appear in the display. Enter a two-digit number for the day ("01" to "31"). To correct a mistake, press the SPEED DIAL key to move the cursor back to the mistake, and then enter the correct number.
  • Page 22 Setting the Date and Time Press the START key to start the clock. The display will show: STORE JUNK FAX # Press the STOP key to return to the date and time display.

  • Page 23: Installing The Multifunction Interface Software

    1. Make sure that the Sharp Color MFP is connected to your computer with a parallel cable as explained in Section 3, Connections. 2. Make sure the Sharp Color MFP is on (the power cord is plugged into an outlet).
  • Page 24 CD into your CD-ROM drive. Click Browse and navigate to your CD-ROM drive. Select Setup.exe and choose OK. A screen will ap- pear telling you to install the Sharp Color MFP printer driver before the Color Multifunction Interface software. Click the Sharp Color MFP Printer Driver button to begin installing the printer driver and follow the instructions on the screen.
  • Page 25 The Online Guide is divided into three parts: Part I: Instructions for using the Sharp Color MFP as a printer, standalone fax machine, and standalone copier. Part II: Instructions for using the Windows 95 version of the Color Multifunction Interface.

  • Page 26: Selecting The Reception Mode

    9. Selecting the Reception Mode The Sharp MFP has four modes for receiving incoming calls and faxes: TEL mode: This is the most convenient mode for receiving phone calls. You can also receive faxes; however, all calls must first be answered by picking up the fax’s handset or an extension phone connected to the same line.
  • Page 27 Press these keys: The display will show: RECEIVE UNIT Press 1 (FAX) to select the Sharp Color MFP, or 2 (PC) to select your computer. FAX (Sharp MFP) If you select reception to your computer and the reception mode is set to TEL, you must answer all calls by picking up the Sharp MFP’s handset.

  • Page 28: Important Safety Information

    Important safety information Do not disassemble this machine or attempt any procedures not described in this manual. Refer all servicing to qualified service personnel. This machine must only be connected to a 230-240 V, 50 Hz, grounded (3-prong) outlet. Connecting it to any other kind of outlet will damage the machine and invalidate the warranty.
  • Page 29 Important Safety Information Use caution when installing or modifying telephone lines. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning. Do not use a telephone to report a gas leak in the vicinity of the leak. The power outlet must be installed near the equipment and must be easily accessible.

  • Page 30: Warranty

    Dealer from which the unit was originally purchased or a Service Centre approved by Sharp to service this type of equipment. These repairs would be carried out at no charge to the owner, subject to the conditions specified herein.
  • Page 31 SHARP CORPORATION OF AUSTRALIA PTY.LTD. A.C.N. 003 039 405 1 Huntingwood Drive, Huntingwood, Blacktown, N.S.W., 2148 SHARP CORPORATION OF NEW ZEALAND LIMITED. Cnr Mahunga Drive & Hastie Ave. Mangere Bridge, Auckland New Zealand SHARP CORPORATION PRINTED IN MALAYSIA (TINSE3908AXZZ)
