Using QuickLoop
The QuickLoop configuration examples are:
Configuration 1
Configuration 2
Configuration 3
Configuration 4
In each of these examples, the dotted line represents the logical QuickLoop or the ports that form
the QuickLoop.
A QuickLoop zone is a subset of a QuickLoop. For examples that illustrate using QuickLoop
zones, see the Zoning User's Guide
2-6
A simple configuration in which a QuickLoop-enabled switch is used as a hub
emulator or concentrator.
A dual-switch configuration in which two switches are cascaded by a local fiber
connection to make up a QuickLoop.
A dual-switch configuration in which two switches up to 10 kilometers apart are
connected to make up a QuickLoop.
A mixed-mode configuration in which only some of the ports of two cascaded
switches are enabled for QuickLoop.
