Using Fabric Watch
Filter
In addition, each class is subdivided into areas, as listed in the following table.
Table 2-1
Class
Fabric
Fabric
Continued
2-4
3 - Monitors CRC errors of prefedined SID-DID pair.
Configurable with either telnet commands or Web Tools at run
time.
The configuration information of the End-to-End class is lost when
the switch is rebooted or fast booted.
Note: The End-to-End class is only available if the optional
Performance Monitoring license has been purchased and
turned on.
Note: The EE filter is preconfigured with either a telnet command
or Web Tools at run time.
Monitors the filter counter for a given port. Provides the following
types of information about the filter hit:
1 - Read command
2 - SCSI or IP traffic
3 - SCSI Read/Write
Note:
The Filter class is only available if the optional
Performance Monitoring license has been purchased and
turned on.
Note: The type of filter is predefined by configuring it with either
a telnet command or Web Tools at run time.
Fabric Watch Classes and Areas
Area
Loss of E_Port
Fabric reconfiguration
Segmentation changes
Domain ID changes
Zoning changes
Fabric to QuickLoop
changes
Fabric logins
GBIC change
Description
Monitors E_Port status.
Monitors fabric configuration
changes.
Monitors segmentation changes.
Monitors forcible DOMAIN ID
changes.
Monitors changes to currently
enabled zoning configuration.
Monitors ports to detect changes from
fabric to QuickLoop or QuickLoop to
fabric.
Monitors number of host device
fabric logins (flogi).
Monitors insertion/removal of GBIC
or SFP.
