test180_Jr.admin> zoneCreate "ql_zone1", "Private_ServerA; Private_StorageA"
<Create QuickLoop zones, using ports>
test180_Jr:admin> zoneCreate "ql_zone1", "Private_ServerA; Private_StorageA"
test180_Jr:admin> zoneCreate "ql_zone2", "Private_ServerB; Private_StorageB"
<Create Fabric Zones, using switch ports or device WWNs>
test180_Jr:admin>zoneCreate "fabric_zone1", "Fabric_ServerA; Fabric_StorageA"
test180_Jr:admin>zoneCreate "fabric_zone2", "Fabric_ServerB; Fabric_StorageB"
<Save and enable the zone configuration>
test180_Jr:admin> cfgSave
Updating flash ...
test180_Jr:admin>cfgEnable "cfg1"
Setting switch to Fabric mode,
Committing configuration...done.
zone config "cfg1" is in effect
<This is an example of the zone configuration>
tesst180_Jr:admin>cfgShow
Defined configuration
cfg: cfg1
zone: fabric_zone1
zone: fabric_zone2
zone: ql_zone1
zone: ql_zone2
alias: Fabric_ServerA
alias: Fabric_ServerB
alias: Fabric_StorageA
alias: Fabric_StorageB
alias: Private_ServerA
Zoning User's Guide
ql_zone1; ql_zone2;
Fabric_ServerA; Fabric_StorageA
Fabric_ServerB; Fabric_StorageB
Private_ServerA; Private_StorageA
Private ServerB; Private StorageB
50:06:0b:00:00:06:9a:d6
50:06:0b:00:00:06:ad:10
50:06:04:82:bc:01:0a:1b
50:06:04:82:bc:01:9a:1c
Detailed Zoning Examples
fabric_zone1; fabric_zone2
