Husqvarna 917.375363 Owner's Manual
  1. Manuals
  2. Brands
  3. Husqvarna Manuals
  4. Lawn Mower
  5. 917.375363
  6. Owner's manual
Husqvarna 917.375363 Owner's Manual

Husqvarna 917.375363 Owner's Manual

6.5 hp, power-propelled, 22" multi-cut rotary lawn mower
Hide thumbs

Advertisement

Available languages

Available languages

Quick Links

Download this manual
Owner's Manual
Husqvarna
ROTARY LAWN MOWER
6.5 Horsepower
Power-Propelled
22" Multi-Cut
Model No.
917.375363
• Espahol, p. 19
CAUTION:
Read and follow all
Safety Rules and Instructions
before operating this equipment
Husqvarna,
Charlotte, NC 28269
Visit our website: www.husqvarna.com
U.S.A.

Advertisement

loading

Related Manuals for Husqvarna 917.375363

Summary of Contents for Husqvarna 917.375363

  • Page 1 Owner's Manual Husqvarna ROTARY LAWN MOWER 6.5 Horsepower Power-Propelled 22" Multi-Cut Model No. 917.375363 • Espahol, p. 19 CAUTION: Read and follow all Safety Rules and Instructions before operating this equipment U.S.A. Husqvarna, Charlotte, NC 28269 Visit our website: www.husqvarna.com...
  • Page 2 Maintenance ........11-14 Warranty ........... Safety Rules .......... Service and Adjustments ....14-16 Product Specifications ......Storage ..........16-17 Assembly / Pre-Operation ......Troubleshooting ......... 17-18 Operation ..........7-11 Repair Parts ........36-43 Maintenance Schedule ......IMPORTANT: Thiscutting machine is capable of amputating hands and feet and throwing jects.
  • Page 3 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on federal lands. A spark arrester for the muffler is available through your nearest Husqvarna other authorized service center (See the REPAIR PARTS section of this manual).
  • Page 4 This warranty shall be inapplicable to defects resulting from the following: authorized Husqvarna dealer in a timely manner, no (1)Accident, abuse, misuse, negligence and neglect, later than thirty (30) days from date of the operational including stale fuel, dirt, abrasives, moisture, rust, problem or failure.

  • Page 5: Lawn Mower Maintenance

    They are not shipped with your mower. They are also available at most Husqvarna retailers service centers. Some of these accessories may not apply to your lawn mower. LAWN MOWER PERFORMANCE CLIPPING DEFLECTORS STABILIZER...

  • Page 6: How To Set Up Your Mower

    Read these instructions and this manual in its entirety before you attempt to assemble operate your new lawn mower. IMPORTANT: This lawn mower is shipped WITHOUT OIL OR GASOLINE in the engine. Your new lawn mower has been assembled at the factory with the exception of those parts left unassembled for shipping...
  • Page 7 KNOW YOUR LAWN MOWER READ THIS OWNER'S MANUAL AND ALL SAFETY RULES BEFORE OPERATING YOUR LAWN MOWER. Compare the illustrations with your lawn mower to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference. These symbols may appear...
  • Page 8 The operation of any lawn 1. Turn unit off and disconnect spark plug SAFE_YGLASSES mower can result in foreign wire from spark plug. Turn nut on underside of drive control objectsthrownintothe eyes, to increase drive speed. which result in severe Operate mower to test drive speed.
  • Page 9 Discharge deflector Mulcher plug SIDE DISCHARGING • Mulcher plug must be installed into rear discharge opening of mower. • Open mulcher door and install dis- charge deflector under door as shown. • Mower is now ready for discharging operation. • To convert to mulching or bagging operation,...
  • Page 10 NOTE: Initialoil fill requiresonly 18 oz. TO START ENGINE dueto residualoil in enginefrom the NOTE: Due to protective coatings on the manufacturers100% qualitytesting.When engine, a small amount of smoke may be changing oil you may need 20 oz. present during the initial use of the prod- 4.

  • Page 11: Mowing Tips

    MULCHING MOWING TIPS cut to reduce pushing effort and to keep from overloading the engine and leaving IMPORTANT: For best performance, clumps of mulched grass. For extremely keep mower housing free of built-up heavy grass, reduce your width of cut grass and trash.

  • Page 12: Lubrication Chart

    Put wheels back in place. • Check for loose fasteners. NOTE: If after cleaning, the drive wheels do not turn freely, contact a Husqvarna LUBRICATION other qualified service center. BLADE CARE Keep unit well lubricated (See "LUBRICATION CHART").
  • Page 13 4. Use block of wood betweenbladeand ENGINE lawn mowerhousingand tighten the LUBRICATION blade bolt, turning clockwise. Use only high quality detergent oil rated with • The recommendedtighteningtorque is API service classification SG-SL. Select the 35-40 ft. Ibs. oil's SAE viscosity grade according to your...

  • Page 14: Air Filter

    7. Continueaddingsmall amountsof oil, Install cartridge, then replace cover. recheckingthe dipstick until oil level Be sure tabs are aligned with slots in settles at FULL. DO NOToverfill,or the back plate. Fasten screw securely. enginewill smoke heavilyfrom the muf- MUFFLER fler on startup. Inspect and replace corroded...
  • Page 15 TO REMOVE DRIVE BELT TO ADJUST HANDLE Remove drive cover and belt keeper. The handle can be mounted in a high or Remove belt from gearcase pulley low position. The mounting holes in the bottom of lower handle are off center pushing down on pulley and rolling...
  • Page 16 ENGINE your lawn mower to a Husqvarna or other ENGINE SPEED qualified service center for repair and/or Your engine speed has been factory set. adjustment. Do not attempt to increase engine speed IMPORTANT: Never tamper with the or it may result in personal injury.

  • Page 17: Engine Oil

    Allow the engine to cool before storing in any enclosure. TROUBLESHOOTING - See appropriate section in manual unless directed to a Husqvarna or other qualified service center. PROBLEM CAUSE CORRECTION Does not start Dirty air filter. Clean/replace air filter.
  • Page 18 TROUBLESHOOTING - See appropriate section in manual unless directed to a Husqvarna or other qualified service center. CORRECTION PROBLEM CAUSE 1. Raise cutting height. Loss of power Rear of mower housing blade dragging in grass. Cutting too much grass. Raise cutting height.
  • Page 19 Garanfia ............Programa de Mantenimiento ......28 Reglas de Seguridad ........ 19-21 Servicio y Adjustes ........31-33 Almacenamiento ........33-34 Especificaciones del Producto ....... Montaje / Pre-Operaci6n ....... Identificaci6n de problemas ...... 34-35 Operaci6n ..........24-28 Partes de repuesto ........36-43 Mantenimiento ..........
  • Page 20 HACER: • Nunca Ilenar contenedores en un vehiculo, en un cami6n o caravana con un forro de pl_.stico. • Puede recortar a trav_s de la superficie de Colocar siempre los contenedores en el suelo la cuesta, nunca hacia arriba y hacia abajo. lejos de su vehiculo antes de Ilenar.
  • Page 21 Husqvarna SECCION 3: ART[CULOS NO CUBIERTOS POR autorizado para la estimaci6n. La prueba de compra,...

  • Page 22: Mantenimiento

    Estos accesorios estaban disponibles cuando se produjo la segadora. No son facilitados junto al cortacesped. Tambien est_.n disponibles en la mayorfa de las tiendas de Husqvarna yen los centros de servicio. Algunos de estos accesorios tal vez no se apliquen a su segadora. RENDIMIENTO...
  • Page 23 Lea estas instrucciones y este manual completamente antes de tratar de montar u operar su sega- dora nueva. IMPORTANTE: Este cortac_sped viene SIN ACEITE O GASOLINA en el motor. Su segadora nueva ha sido montada en la f_.brica con la excepci6n de aquellas partes que se de- jaron sin montar por razones de envio.
  • Page 24 FAMILIARICESE CON SU SEGADORA LEA ESTE MANUAL DEL DUENO Y LAS REGLAS DE SEGURIDAD ANTES DE OPARAR SU SEGADORA. Compare las ilustraciones con su segadora para familiarizarse con la ubicaci6n de los diversos controles y ajustes. Guarde este manual para referencia en el futuro. Estos simbolos pueden apareser sobre su segadora o en la literatura proporcionada con el producto.
  • Page 25 AJUSTE DEL MANDO Laoperaci6n d ecualquier Ocasionalmente, el sistema de mando puede segadora puedehacerque saltenobjetos extra_os d entro de "aflojarse', provocando una disminuci6n de la susojos,Ioquepuedeproducir velocidad. Hay un torniquete en la parte trasera de la sede del mando para apretar la tensi6n da_osgraves en_stos.
  • Page 26 Desviador de la descarga Tap6n SEGADORAS C ONDESCARGA L ATERAL • Latap6nacolchadora d ebeserinstalada ad- entrodela abertura de ladescarga trasera. • Abrala protecci6n c ontrala descarga y instale el desviador de contraladescarga debajo dela protecci6n comose muestra. • Lasegadora estalistaparalaoperaci6n de ladescarga.
  • Page 27 3. Ustedrecibe un envase deaceiteconla sistema del combustible antes de guardarlo unidad. V iertalentamente e l envase entero por un periodo de 30 dias o m_.s. Vacie el deaceiteeneltubode relleno delmotor. estanque del combustible, haga arrancar el AVlSO"Elterrapl_n inicial d elaceiterequiere motor y h_tgalo funcionar hasta que las lineas solamente 1 8onzasdebido al aceiteresidual del combustible y el carburador queden vacios.
  • Page 28 CONSEJOS PARA SEGAR Y ACOL- necesario el elevar la altura del corte para reducir el esfuerzo necesario para empujar la CHAR segadora y para evitar sobrecargar el motor, IMPORTANTE: Para obtener el mejor dejando montones de recortes de cesped. rendimiento mantenga la caja de la segadora Para un cesped muy pesado, reduzca el an- sin acumulacion de cesped y basura.
  • Page 29 Si despu_s de limpiar las ruedas de Mantenga la unidad bien lubricada impulsi6n no giran libremente, p6ngase en (vea la "TABLA DE LUBRICACION"). contacto con su centro de servicio Husqvarna o con un otro centro de servicio cualificado. TABLA DE LUBRICACION...
  • Page 30 PARA CAMBIAR LACUCHILLA solamente por uno que sea aprobado por el fabricante. D_ el nt3mero del modelo de la 1. Ponga eladaptador de lacuchilla enel cigueSal delmotor. A segt3rese quela ranura segadora cuando Io ordene. deladaptador y queel chavetero d elcigue- CAJA DE ENGRANAJES 5alest_nalineados.
  • Page 31 6. ParardeaSadir a ceitecuandosealcanza la _PRECAUCI6N: Los solventes de petrdleo, seSal deIleno (FULL) e nlavarilla.Esperar u n tales como el keroseno, no se deben usar para minuto paradejarqueelaceitesearregle. limpiar el cartucho. Pueden producir el deteri- 7. Contint3e agregando c antidades p equeas oro de este.
  • Page 32 PARA REMOVER LA CORREA DE IMPUL- PARA AJUSTAR EL MANGO SION El mango puede ser montado a una posici6n Remueva la cubierta de la impulsi6n y alta o baja. Los agujeros de montaje en el mango inferior est_.n fuera del centre para fijador de la correa.
  • Page 33 Ileve su segadora a contacto con VELOCIDAD DEL MOTOR su centro de servicio Husqvarna o con un otro centro de servicio cualificado para repararla y/o La velocidad del motor ha sido ajustada en la f_.brica. No trate de aumentar la velocidad ajustarla.
  • Page 34 SOLUCION PROBLEMAS - Vea la seccibn apropiada en el manual amenos est_ dirigido a un centro de servico Husqvarna. CORRECCION PROBLEMA CAUSA No arranca Filtro de aire sucio. Limpie/cambie el filtro de aire. Sin combustible. Llene el estanque de combustible.
  • Page 35 Ciguefial del motor doblado. P6ngase en contacto con su centro de servicio Husqvarna o con un otro centro de servicio cualificado. Cordbn El freno del volante del motor Presione la barra de control arrancador est,.
  • Page 36 HUSQVARNA ROTARY LAWN MOWER - - MODEL NUMBER 91 7.375363...
  • Page 37 HUSQVARNA ROTARY LAWN MOWER - - MODEL NUMBER 917.375363 PART PART DESCRIPTION DESCRIPTION 189740 Upper Handle (Includes Foam Grip) 73800400 Nut, Hex, Nylock 183567 Engine Zone Control Cable 197556 Kit, Housing (Includes Key Numbers 14, 15 and 51) 850733X004 Bracket, Upstop...
  • Page 38 HUSQVARNA ROTARY LAWN MOWER - - MODEL NUMBER 91 7.375363 /_.\...
  • Page 39 HUSQVARNA ROTARY LAWN MOWER - - MODEL NUMBER 917.375363 PART PART DESCRIPTION DESCRIPTION 197194 Drive Control Assembly (Includes Cable) 195110 Kit, Wheel Adjuster, LH 195761 Cover, Drive Control, Top (Includes Knob and Bearing) 187353 Pulley 191636 Gear Case Assembly, Complete...
  • Page 40 BRIGGS & STRATTON 4-CYCLE ENGINE MODEL NUMBER 123K02-0498-E1 I 1019 LABEL KI'I] 11058 OWNER'S MANUAL I 51 _ 383_ 11330 REPAIR MANUAL I lO%; 1095 VALVE GASKET SET...
  • Page 41 BRIGGS & STRATTON 4-CYCLE ENGINE MODEL NUMBER 123K02-0498-E1 445 _ 276 _ 127_ 130 95 276 _ 276_ 977 CARBURETOR GASKET 443_ 633 _ 334 _ 276_ 365 _ 505@ 358 ENGINE GASKET 842_> 524 c_...
  • Page 42 BRIGGS & STRATTON 4-CYCLE ENGINE MODEL NUMBER 123K02-0498-E1 6081 592_ 689 4> 1036 EMISSIONS LABEL J 78 _ PART PART DESCRIPTION DESCRIPTION 697322 Cylinder Assembly 695759 Screw (Connecting Rod) 399269 Valve-Exhaust Kit-Bushing/Seal 262651 299819 Valve-Intake Seal-Oil (Magneto Side) 262652 493279 Sump-Engine 691270 Spring-Valve (Intake)
  • Page 43 BRIGGS & STRATTON 4-CYCLE ENGINE MODEL NUMBER 123K02-0498-E1 PART PART DESCRIPTION DESCRIPTION 694468 Plug-Welch 270344 G:I: SeaI-O Ring 696564 Valve-Th rottle (Intake Manifold) 398187 Float-Carburetor 692310 Switch-Stop 398188 Valve-Needle/Seat 691321 O5 Seal-Throttle Shaft 693981 _:1: Gasket-Float Bowl 66538 Boot-Spark Plug 691753 Bracket-Air Cleaner Primer 493823...
