ViewSonic VG2028wm Specification

VG2028wm
Multimedia performance for your business
Model Name
Model Name
LCD
INPUT
COMPATIBILITY
CONNECTOR
SPEAKER
POWER
CONTROLS
OPERATING CONDITIONS
DIMENSIONS (WxHxD)
WEIGHT
REGULATIONS
WALL MOUNT (mm)
For more product information, visit us at ap.viewsonic.com
VSI 2010/07/19 V4
>
>
>
>
>
>
>
Size
Optimum Resolution
Brightness (cd/m²)
Contrast Ratio (typical)
Dynamic Contrast Ratio
Viewing Angle
Response Time (ms)
Pixel Pitch (H×V)
Panel Surface
Light Source (Hours)
Color Support
Analogue
Sync
Frequency (Fh / Fv)
PC
Mac
Analogue
Digital
Audio
USB
Power
Speaker
Voltage
Consumption (W)
Save mode (W)
ECO mode
Basic
OnView / OSD
Temperature
Humidity (Non condensed)
Physical (w/ stand)
Net (w/ stand)
VESA ® Mount Complliant
ENHANCE PRODUCTIVITY AND ENTERTAINMENT
Multi-functional base design (360º swivel, height adjusment)
VESA compliant wall-mount interface and detachable base for
ergonomic flexibility with 3.1 height, tilt and 360° swivel adjustments.
USB hub
2-port USB hub provides easy connectivity for USB devices.
Multimedia enhanced
Stereo speakers provide clear and rich sound.
Widescreen aspect ratio with 1600 x 900 resolution
The widescreen aspect ratio allows you to view Full HD content in its
native format with no stretching or distortion.
®
OptiSync digital/analogue inputs expand your connectivity
Multi-mode input technology supports both digital (DVI) and
analogue (VGA) signals for ultimate compatibility and configuration
flexibility.
Eco-mode
Environmentally-friendly Eco-mode reduces power consumption and
extends backlight life.
Stylish slim-bezel design
An ultra-thin bezel lets you see more without taking up valuable
desktop real estate.
VG2028wm
VG2028wm
20" wide Color TFT Active Matrix LCD
1600 x 900
300 cd/m² (typical)
1000:1 static (typical)
100,000:1
170 o (H), 160 o (V) @ 10:1 contrast ratio
5ms (typical)
0.277mm (H) x 0.277mm (V)
Anti-Glare
Long life, 50,000 hrs. (typical)
16.7 M
RGB Analogue (75 ohms, 0.7/1.0 Vp-p)
H/V Separated
Fh: 24-82kHz, Fv: 50-75Hz
VGA up to 1600 x 900 non-interlaced
Power Mac™ up to 1600 x 900
1 x 15-pin mini D-sub
1 x DVI-D
1 x 3.5 mm audio in
2 x down stream, 1 x up stream
Built-in power adapter, 3-Pin plug
2 x 2-watt
AC 100–240V (Universal); 50/60Hz(Switch)
27 (typical)
≦1W
25W (Optimize)/ 18W (Conserve)
Power, Mute, [1], Up [ ], Down [ ], [2]
Auto Image Adjust, Contrast/Brightness, Audio adjust: Volume mute,
Color Adjust: sRGB, 9300K, 7500K, 6500K, 5000K, User Color [R, G,
B], Information, Manual Image Adjust: Horizontal size, H/V position,
fine tune, sharpness, dynamic contrast, aspect ratio, Eco mode, Setup
Menu: Language select, resolution notice, OSD position, OSD time out,
OSD background, Memory recall
41° F - 95° F (5°C–35° C)
20 - 80% (non-condensing)
481.2mm (W) x 393.4mm (H) x 230mm (D)
10.56 lb. (4.8 kg)
CB, TCO03, WEEE, ROHS, ERGO,CE, Ukraine GOST-R+Hygienic ,SASO, BSMI, PSB,
C-TICK, MIC (or KCC), Green Mark
VESA 100mm x 100mm
Model No. VS13390
