Page 1: Illustrated Parts List
ILLUSTRATED PARTS LIST MODEL NO. 96012003101 CUSTOMER CATALOG NO. DB24H42YT 199282 Rev. 1 06.01.05 TR... -
Page 2: Wheels And Tires
TRACTOR - - MODEL NUMBER DB24H42YT (96012003101) DECALS PART PART DESCRIPTION DESCRIPTION 187407 Refl ector, LH 172743 Decal Ins Strg Whl 186503 Decal Dash 193939 Decal Oper 176272 Decal Hood Rh 145004 Decal Battery 176273 Decal Hood LH 195676 Decal Side Panel Logo 172740 Decal Fender Logo 191652... - Page 3 TRACTOR - - MODEL NUMBER DB24H42YT (96012003101) SCHEMATIC BATTERY SOLENOID AMMETER FUSE STARTER (OPTIONAL) WHITE (DISENGAGED) WHITE L A2 BLACK CLUTCH / BRAKE (PEDAL UP) GRAY SEAT SWITCH (NOT OCCUPIED) BLACK BLACK GRAY BLACK REVERSE SWITCH SHORTING CONNECTOR NOT IN REVERSE BLACK BLACK ELECTRIC CLUTCH...
- Page 4 TRACTOR - - MODEL NUMBER DB24H42YT (96012003101) ELECTRICAL 193389ROS...
- Page 5 TRACTOR - - MODEL NUMBER DB24H42YT (96012003101) ELECTRICAL PART DESCRIPTION 144927 Battery 74760412 Bolt Hex Hd 1/4-20 unc x 3/4 7603J Tray Battery 145211 Bolt Battery Front 1/4-20 x 7.5 150109 Holddown Battery 145769 Nut Push Nylon 1/4 176138 Switch Interlock 175688 Harness Socket Light 4152J...
- Page 6 TRACTOR - - MODEL NUMBER DB24H42YT (96012003101) CHASSIS chassis-stealth.stlt_27...
- Page 7 TRACTOR - - MODEL NUMBER DB24H42YT (96012003101) CHASSIS PART DESCRIPTION 174619 Chassis 176554 Drawbar 193636X428 Dash 72140608 Bolt Carriage 3/8-16 x 1 167203 Panel Dash Lh 178298 Panel Dash Rh 17490608 Screw Thdrol 3/8-16 x 1/2 175260X428 Hood 162026 Plate Battery 73800600 Nut Lock Hex W/Ins 3/8-16 unc 175289X428 Grille...
- Page 8 TRACTOR - - MODEL NUMBER DB24H42YT (96012003101) DRIVE 19 24 drive-hydro.stlt_73...
- Page 9 TRACTOR - - MODEL NUMBER DB24H42YT (96012003101) DRIVE PART PART DESCRIPTION DESCRIPTION 174607 Pulley, Engine - - - - - - Transaxle Hydro Gear 314-0510 173937 Bolt Hex 7/16-20 x 4 x Gr. 5-1.5 Thr (Order Parts From Transaxle Manu- 10040700 Washer facturer)
-
Page 10: Steering Assembly
TRACTOR - - MODEL NUMBER DB24H42YT (96012003101) STEERING ASSEMBLY steering_stealth_prem_13... - Page 11 TRACTOR - - MODEL NUMBER DB24H42YT (96012003101) STEERING ASSEMBLY PART DESCRIPTION 186094X428 Wheel Steering 184706 Axle Asm Cast Iron LT 169840 Spindle Asm LH 169839 Spindle Asm RH 6266H Bearing Race Thrust Harden 121748X Washer 25/32 x 1-5/8 x 16 Ga. 12000029 Ring Klip #t5304-75 175121...
-
Page 12: Seat Assembly
TRACTOR - - MODEL NUMBER DB24H42YT (96012003101) SEAT ASSEMBLY seat_lt.knob_2 PART PART DESCRIPTION DESCRIPTION 121248X Bushing Snap Blk Nyl 50 Id 189022 Seat 140551 Bracket Pivot Seat 8 720 72050412 Bolt Rdhd Sqnk 1/4-20 x 1-1/2 121249X Spacer Split 28x 88 71110616 Bolt Fin Hex 3/8-16 unc x 1 123740... -
Page 13: Optional Equipment
TRACTOR - - MODEL NUMBER DB24H42YT (96012003101) ENGINE OPTIONAL EQUIPMENT Spark Arrester engine-bs.twin_43 PART PART DESCRIPTION DESCRIPTION 8543R Line, Fuel 175437X428 Control, Throttle/Choke 181654 Plug Drain Oil Easy 191611 Screw Hex Single Lead 10 x 3/4 139277 Stem Tank Fuel - - - - - - - Engine Briggs Model 445677 (Order Parts from Engine Mfg.) -
Page 14: Mower Deck
TRACTOR - - MODEL NUMBER DB24H42YT (96012003101) MOWER DECK 42_D.elec.t-path.adjwl.stlt_3... - Page 15 TRACTOR - - MODEL NUMBER DB24H42YT (96012003101) MOWER DECK PART PART DESCRIPTION DESCRIPTION 137729 Screw, Thdrol 1/4-20 x 5/8 T 182032 Mower Deck Assembly, 42" 178515 Washer, Hardened 72140506 Bolt 155046 Arm, Idler 138017 Bracket Asm Fr. Sway Bar 3/42 122052X Spacer, Retainer 165460...
-
Page 16: Mower Lift
TRACTOR - - MODEL NUMBER DB24H42YT (96012003101) MOWER LIFT 17 18 20 lift-rh.1pc.stlt_12 PART PART DESCRIPTION DESCRIPTION 164024 Spring Infi n. Height 197981 Plunger Asm. 169484 Retainer Clip 198070 Shaft Asm Lift RH w/Inf 164543 Rod Adjust Lift 188822 Pin Groove 2" 73350600 Nut Hex Jam 3/8-16 unc 12000002...
