Gigabyte 12QM-TVPCI01-1001R Installation Manual

TV Tuner Card
12QM-TVPCI01-1001R
1
Installation of a TV Tuner Card
Prior to installation, please check if the motherboard has one open PCI slot.
1-1 Take the TV card out of the anti-static
bag, and carefully, firmly insert the TV
card into the PCI slot.
1-2 Secure the TV card to the computer
chassis with screws, and then replace
the computer case.
1-3 Connect the FM antenna, digital TV
antenna and stereo sound cable
the TV card. Connect the USB receiver
for the remote control to a USB port
(Note 2)
on your computer.
1-4 Extend the FM antenna and digital TV antenna, and place them on a location
with better signal reception
The hardware installation is then completed!
Now you can connect the computer to an electrical outlet and power on the computer.
Follow the instructions in the next section for driver and software installation for the
TV card.
2
Installation of Driver and Softwares
When you place the supplied Installation CD into the CD-ROM drive of your computer,
the AUTORUN screen will appear. If the screen does not appear, you can run "D:
\TVCard.exe"(D stands for the CD-ROM drive) to display the screen. (You can run
"D:\Drv\Setup.exe" to start the Driver installation and run D:\PCinema\Setup.exe" to
start the PowerCinema installation.) Then follow the on-screen instructions to install
to
(Note 1)
the driver and software with ease.
(Note 1) The accessories may vary depending on different models.
(Note 2) Please place the receiver at a location where remote control signals are available.
(Note 3) Find a location in your house where can get the best reception. The digital TV signals are
transmitted via a ground-based transmitter. Please place the antenna near the window and
away from sheltering buildings as possible as you can for better signal reception.
.
(Note 3)
Click "Driver" to install TV card driver.
Click "Power Cinema 4.0" to install PowerCinema
4.0 for the TV card.
