Monogram.
™
ZIR36ND–GE Monogram 36" Built-In All-Refrigerator
Custom Door Panel Dimensions
Using Trim Kits ZKTR36LH or ZKTR36RH
3/4" thick panel with kit supplied handle
35 -1/16"
3/4" Thick
Custom Panel
Custom Grille Panel
35 1/4"
A
3/4" Thick Panel
Grille Panel height can vary to fill installation height.
Installation Height
83-1/2"
84"
84-1/2"
Important: Maintain 1-1/2" min. gap between top
of door and bottom of grille panel.
Specification Created 8/00
68-15/16"
Dimension A
7-1/2"
8-1/2"
8-3/4"
ZIR36N Refrigerator
ZIF36N Freezer
• The ZKTR36LH (or ZKTR36RH) trim kit provides for the installation of 3/4" thick
custom door and grille panels, using the supplied handle. Cut panel to size
and install.
Important: Maximum panel is 50 pounds
For answers to your Monogram,
GE Profile Performance Series,
GE Profile
™
or GE appliance questions, call
GE Answer Center
®
service, 800.626.2000.
Listed by
Underwriters
Laboratories
R
®
™
