11. Technical Specifications

Frequency response (1) +/- 3dB
Recommended Amplifier Power
Power Handling
Sensitivity (1)
2.83 volt @ 1m
Maximum SPL (3)
@ 1m
Impedance
Distortion
0.1 Full Power
100 Hz
250 Hz
0.01 Full Power
100 Hz
250 Hz
Driver Compliment
Crossover Point
Enclosure
Finish
Protective Grille
Connectors
Rigging/Fittings
Dimensions
Weight
NOTES:
Tannoy operate a policy of continuous research and development. The introduction of new materials or manufacturing
methods will always equal or exceed the published specifications which Tannoy reserve the right to alter without prior notice.
Please verify the latest specifications when dealing with critical applications.
2 x 18" High efficiency Bass Units. Type Number 4501
(1) Average over stated bandwidth. Measured at 1m on axis using , in an anechoic chamber.
(2) Long term power handling capacity as defined in EIA standard RS - 426A.
(3) Unweighted pink noise input, measured at 1m
28Hz -240 Hz
800 - 2000 watt / 4 ohm
Average(2) Programme Peak (10ms)
600 watt 1200 watt
101 dB
RMS Peak
129 dB 135 dB
Nominal 4 ohm
Minimum 3.9 ohm
2nd Harmonic
0.20%
0.14%
0.18%
0.12%
Active: Recommended points
70 - 240 Hz, 24dB/octave, Linkwitz - Riley
(dependant on application)
337.5 litre (11.914cu.ft.) vented, 18mm multi-ply birch plywood
Textured black\grey paint
Perforated steel, black with 50% free air flow
2 x Speakon NL4MPR IN/OUT
4 x Recessed carrying handles
Inserts for castors
576mm(H) x 1110mm(W) x 650mm(D)
22.7ins(H) x 43.7ins(W) x 25.6ins(D)
76 Kg (167.2 lbs)
2400 watt
3rd Harmonic
0.12%
0.10%
0.09%
0.10%
