Mounting the Switch on a Table or Shelf

You can mount the switch on a table or shelf. Locate the switch in a
position that allows access to the front panel RJ-45 ports, visibility of the
port LEDs, and access to the rear-panel modules and power cord. Make
sure that the mounting surface can safely support the switch and that
there is adequate space around the switch for ventilation and cooling.
1. The switch ships with four (4) rubber feet. Stick the self-adhesive
rubber foot pads on each of the four concave spaces located on the
bottom of the switch. The rubber foot pads cushion the switch against
shock/vibrations and provide space between each switch for
ventilation.
2. If you want to stack switches, repeat step 1 for each switch to be
stacked. Place the first switch on a firm flat surface where you want
to install the stack. Stack the other switches on top of this unit.
16 Installation VH-8TX1UM/VH-8TX1MF
