- Page 1 Matrix V-Series VSER-RPU-SYS Redundant Power Supply Hardware Installation Guide P/N 9033948...
- Page 3 ENTERASYS NETWORKS reserves the right to make changes in specifications and other information contained in this document and its web site without prior notice. The reader should in all cases consult ENTERASYS NETWORKS to determine whether any such changes have been made.
- Page 4 Notice Regulatory Compliance Information Federal Communications Commission (FCC) Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 5: Safety Compliance
• The unit must be connected to an earthed (grounded) outlet to comply with international safety standards. • Do not connect the unit to an A.C. outlet (power supply) without an earth (ground) connection. • The appliance coupler (the connector to the unit and not the wall plug) must have a configuration for mating with an EN 60320/IEC 320 appliance inlet. - Page 6 Notice Power Cord Set U.S.A. and Canada The cord set must be UL-approved and CSA certified. The minimum specifications for the flexible cord are: - No. 18 AWG - not longer than 2 meters, or 16 AWG. - Type SV or SJ - 3-conductor The cord set must have a rated current capacity of at least 10 A The attachment plug must be an earth-grounding type with NEMA 5-15P...
- Page 7 France et Pérou uniquement: Ce groupe ne peut pas être alimenté par un dispositif à impédance à la terre. Si vos alimentations sont du type impédance à la terre, ce groupe doit être alimenté par une tension de 230 V (2 P+T) par le biais d’un transformateur d’isolement à...
-
Page 8: Declaration Of Conformity
Application of Council Directive(s): Manufacturer’s Name: Manufacturer’s Address: European Representative Address: Conformance to Directive(s)/Product Standards: Equipment Type/Environment: Enterasys Networks, Inc. declares that the equipment packaged with this notice conforms to the above directives. Declaration of Conformity 89/336/EEC 73/23/EEC Enterasys Networks, Inc. -
Page 9: Table Of Contents
Contents Chapter 1: About the Redundant Power Supply Overview Features and Benefits Front and Rear Panels LEDs Chapter 2: Installing the Redundant Power Supply Installation Selecting a Site Equipment Checklist Package Contents GettingHelp Optional Rack-Mounting Equipment Mounting Rack Mounting Desktop or Shelf Mounting... - Page 10 Tables Table 1-1. Port Status LEDs Table A-1. Troubleshooting Chart viii...
- Page 11 Figures Figure 1-1. Front and Rear Panels Figure 1-2. LEDs Figure 2-1. Attaching the Brackets Figure 2-2. Installing the RPS in a Rack Figure 2-3. Attaching the Adhesive Feet Figure 2-4. Power Receptacle Figure 2-5. Connecting Several Switches to an RPS...
- Page 12 Figures...
-
Page 13: Chapter 1: About The Redundant Power Supply
About the Redundant Power Supply Overview Note: The VSER-RPU-SYS is compatible with V2H124-24 and V2H124-24T only. This VSER-RPU-SYS External Redundant Power Supply (RPS) can supply 600 Watts of backup power to four switching devices in the event of an AC loss or failure of an internal power supply. -
Page 14: Leds
On Green Flashing Green On Green Flashing Red Figure 1-2. LEDs VSER-RPU-SYS Table 1-1. Port Status LEDs Status Power is being supplied to the RPS, the unit is functioning normally, and the RPS port is connected to a switch. Power is being supplied to the RPS, the unit is functioning normally, but no switch is connected to the RPS port. -
Page 15: Chapter 2: Installing The Redundant Power Supply
Installing the Redundant Power Supply Installation Note: The VSER-RPU-SYS is compatible with V2H124-24 and V2H124-24T only. The RPS may be placed on a desktop or mounted in a rack. Caution: DO NOT place the RPS on the floor as the case is not waterproof. It is recommended that this RPS be installed in a network equipment rack. -
Page 16: Package Contents
A description of any action(s) already taken to resolve the problem (e.g., changing mode switches, rebooting the unit, etc.) • The serial and revision numbers of all involved Enterasys Networks products in the network • A description of your network environment (layout, cable type, etc.) •... -
Page 17: Optional Rack-Mounting Equipment
• The device history (i.e., have you returned the device before, is this a recurring problem, etc.) • Any previous Return Material Authorization (RMA) numbers Optional Rack-Mounting Equipment If you plan to rack-mount the RPS, be sure to have the following equipment available: •... -
Page 18: Figure 2-1. Attaching The Brackets
Installing the Redundant Power Supply To rack-mount devices: Attach the brackets to the device using the screws provided in the Rack Mounting Kit. Figure 2-1. Attaching the Brackets Mount the device in the rack, using four rack-mounting screws (not provided). -
Page 19: Desktop Or Shelf Mounting
Desktop or Shelf Mounting Attach the four adhesive feet to the bottom of the first RPS unit. Figure 2-3. Attaching the Adhesive Feet Set the device on a flat surface near an AC power source, making sure there are at least two inches of space on all sides for proper air flow. Connecting Switches to the RPS Caution: DO NOT connect the RPS to an AC power source until DC power cords have been connected to the supported switches. -
Page 20: Figure 2-5. Connecting Several Switches To An Rps
Installing the Redundant Power Supply Power up the RPS by connecting one end of the AC cord to the AC receptacle on the RPS, and the other end to a grounded power outlet. Check the LEDs on the RPS to ensure proper operation. The Fan LED and the RPS LED for connected switches should light up. -
Page 21: Appendix A: Troubleshooting
If the fan LED does not turn on when the power cord is plugged in, you may have a problem with the power outlet, power cord, or internal power supply. However, if the unit powers off after running for a while, check for loose power connections, power losses or surges at the power outlet, and verify that the fans on the unit are unobstructed and running prior to shutdown. - Page 22 Troubleshooting...
-
Page 23: Appendix B: Specifications
Appendix B: Specifications Physical Characteristics Ports 4 RPS DC power outlets LEDs Ports 1 to 4, and fan status LEDs. Weight 5 kg (27.6 lbs) Size 44.0 x 28.4 x 4.3 cm (17.34 x 11.19 x 1.69 in.) Temperature Operating: 0 to 40 °C (32 to 104°F) Storage: -40 to 70 Humidity Operating: 5% to 95%... -
Page 24: Compliances
Specifications Power Supply Internal, auto-ranging: 100 to 240 VAC, 50 to 60 Hz Output 12 VDC Current: 0 A (minimum), 13 A (maximum) Line regulation: +/- 1% Load regulation: +/- 10% Overshoot and undershoot: 5% Maximum Current 10 A @ 110 VAC... -
Page 25: Index
Index adhesive feet, attaching 2-5 air flow requirements 2-1 brackets, attaching 2-4 contents of package 2-2 cooling problems A-1 cord sets, international 2-6 desktop mounting 2-5 equipment checklist 2-2 front panel of RPS 1-1 grounding for racks 2-3 installation desktop or shelf mounting 2-5 power requirements 2-1 problems A-1 rack mounting 2-3... - Page 26 Index Index-2...
