- Page 1 EVS200A/AW User’s Manual Copyright © EverFocus Electronics Corp, Release: Nov. 2009 Rev.A...
- Page 2 - Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications made to this equipment, not expressly approved by EverFocus or parties authorized by EverFocus could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the...
- Page 3 EVS200A/AW EVS200A/AW complies with CE and FCC. About this document All the safety and operating instructions should be read and followed before the unit is operated. This manual should be retained for future reference. The information in this manual was current when published. The manufacturer reserves the right to revise and improve its products.
- Page 4 Sun Microsystems, Inc. in the United States and other countries. Support If the unit ever needs repair service, the customer should contact the nearest EverFocus Electronics Corp. Service Center for return authorization and shipping instruction. About AC Adaptor...
-
Page 5: Table Of Contents
EVS200A/AW TABLE OF CONTENTS 1. INTRODUCTION....................6 2. FEATURES ......................6 3. ACCESSING THE CAMERA MENU ..............7 4. SETTING........................14 4.1 S ......................14 YSTEM 4.1.1 Information ....................14 4.1.2 Log ......................15 4.2 U ......................16 ONFIG 4.3 N ......................18 ETWORK 4.3.1 Network.......................18 4.3.2 DDNS......................20 4.3.3 Bandwidth ....................21 4.3.4 SMTP/FTP ....................22 4.3.5 Network Alarm (reserved for PowerCon)...........24 4.3.6 Wireless (For EVS200AW only)..............24... -
Page 6: Introduction
EVS200A/AW 1. INTRODUCTION The EVS200A/EVS200AW is a high performance, two channel solution that integrates analog cameras into an IP-based video surveillance system. The unit supports NTSC/PAL sources at up to 30fps, per channel, over IP networks and provides bidirectional audio communication in parallel with video. The EVS200A/EVS200AW also features a Dual Streaming function allows it to generate 4 independently configurable H.264, MPEG4 or MJPEG video streams (2 per input). -
Page 7: Accessing The Camera Menu
EVS200A/AW 3. ACCESSING THE CAMERA MENU Step 1.Start an Internet Explorer browser. Step 2. Enter the IP address or host name of the camera in the Location/Address field of your Internet Explorer browser. (Please refer to EVS200A/AW Installation Guide for how to find the IP address) Step 3. - Page 8 EVS200A/AW 1. Press button to enter Nevio Express system. For more details, please refer to Nevio Express user manual. 2. Press button to display the "Live" page. Double click on the image to show a full screen display, double click again or press ESC to return normal display.
- Page 9 EVS200A/AW 6. View Size You can select View size to either reduce or enlarge the image to the appropriate view size. Select the view size for live images from: NTSC: 704*480/640*480/352*240/320*240/176*120 PAL: 704*576/640*480/352*288/320*240/176*144 7. Record The record button is used to record the current video stream. The location where the image file is saved can be specified in Setting ->...
- Page 10 EVS200A/AW 12. PTZ Control – Navigation Mode Select this to browse in direction user pointing at. 13. PTZ Control – Click-n-Go Mode Select this and system will center the pointing location for browsing. Before Click-n-Go mode After Click-n-Go mode EVS200A/AW provides 3 methods to control PTZ: 1.
- Page 11 EVS200A/AW ○ Control Panel : Zoom in : Zoom out : Focus far Focus near : Iris + : Iris – Arrow buttons: Click on an arrow button to navigate in that direction. : stop current action. : User can select PTZ speed from High, Standard, Low and Minimum.
- Page 12 EVS200A/AW Number button, Go button and Clear button: - Click desire number button and it will show in the gray text area at lower-left corner. - Click “Clear” button to clear the text area. - Click “Go” button to run a selected function. Clear button: Click this button to clear the digit selection indicator.
- Page 13 EVS200A/AW ○ PTZ Control Shortcuts Right click the mouse to get a PTZ Control Shortcuts panel. User can control the PTZ through a PC’s keyboard. The keys in red color correspond to the same keys of keyboard. 14. Manual Control – Trigger Event Press “Trigger Event”...
-
Page 14: Setting
EVS200A/AW 4. SETTING Click “Setting” button to enter the setting menu. There are 9 sections in setup menu: [System Info], [User Config], [Network], [Video], [Audio], [User], [Event], [System] and [EKB200]. 4.1 System Info System information and system log check of the setup menu can be performed on this page. -
Page 15: Log
EVS200A/AW 4.1.2 Log System Log: Date/Time: displaying date and time of the log. Log message: all information and event message, including login, user’s IP, reboot, firmware upgrade, load factory default, configuration reset and event detected. System will keep the newest 256 records. -
Page 16: User Config
EVS200A/AW Press button to export system log into “.txt” file and select the location where the exported log file will be saved to. 4.2 User Config Live view configuration is to be set by user. Each login user can make his/her own settings for the following items: Text Setting Check the box for text of Machine name, Date/Time or Frame Rate to be... - Page 17 EVS200A/AW Date/Time Format Used in Text Date Format: Select Date/Time Format from the following options: Time Format: 24 Hours or 12 Hours. Press Apply to apply the setting changes or Reset to reset without saving the change. Recording/Snapshot Export Setting Enable Event Recording to PC: Allow event video recorded to users' PC if any events have been set to record to PC.
-
Page 18: Network
EVS200A/AW the new language file (.evb) and then click the Upload button. Note: Upload a new language file will reboot system automatically. Please reconnect video encoder after reboot. Press Apply to apply the setting changes or Reset to reset without saving the change. - Page 19 EVS200A/AW • Primary DNS, Secondary DNS (when using DNS) IP Setting IP Type: DHCP: Configure the DHCP server not to assign the same IP addresses used for the other network cameras and PCs whose IP address is unique. Refer to the network administrator for the settings of the server. Default: DHCP.
-
Page 20: Ddns
EVS200A/AW Username: Enter User name of the account (used only for PPPoE). Password: Enter Password of the account (used only for PPPoE). Press Apply to apply the setting changes or Reset to reset without saving the change. Port Setting HTTP Port: Port number for HTTP/WEB communication. -
Page 21: Bandwidth
○ www.dyndns.com ○ www.no-ip.com Enable: Check the box to enable DDNS setting. Service ISP: If you choose EverFocus DDNS server, you can obtain a free account name from EverFocus ”www.everfocusddns.com”. Enter an IP Cam Account Name: .everfocusddns.com Press button to register or update DDNS account. -
Page 22: Smtp/Ftp
EVS200A/AW Bandwidth Setting Max. Bandwidth: Specify, Unlimited / 64 K/ 128 K/ 256 K / 512 K / 1M / 2M / 4M / 8M bps. the maximum bandwidth that the camera is allowed to use on the network. This is a useful function when connecting the camera to busy or heavily loaded networks. - Page 23 EVS200A/AW send e-mails SMTP Port: Enter the port number for SMTP. Default is 25. Authentication: Check the box, if the SMTP server requires Authentication (user/ password). User name: Input the login user ID if the SMTP server requires Authentication. Password: Input the password if the SMTP server requires authentication. Receiver Address: Input the e-mail address for receiving e-mail message when the EVENT is enabled and triggered.
-
Page 24: Network Alarm (Reserved For Powercon)
EVS200A/AW 4.3.5 Network Alarm (reserved for PowerCon) Set Network Alarm This function is reserved for PowerCon software, for the detail setting please refer to PowerCon network alarm protocol. 4.3.6 Wireless (For EVS200AW only) - Page 25 EVS200A/AW Wireless Setting Enable Wireless (Default: disable) SSID: Name of the wireless network the camera is configured for. The field accepts up to 32 alphanumeric characters. The name must be exactly the same as the one used in the wireless access point or the connection will not be established. Network Type: Infrastructure or Ad-Hoc (Default: Infrastructure) -“Infrastructure”...
-
Page 26: Video
EVS200A/AW Confirm Key: Double confirm network key. IP Status: Show IP status when wireless connection, including IP Type, IP Address, Subnet mask, Gateway, Primary DNS, Secondary DNS. Press Apply to apply the setting changes or Reset to reset without saving the change. 4.4 Video The settings relating video such as streaming, camera OSD can be configured on this page. - Page 27 EVS200A/AW Resolution: NTSC: 4CIF (704*480) / VGA (640*480) / CIF (352*240) PAL: 4CIF (704*576) / VGA (640*480) / CIF (352*288) Quality: there are 8 types of quality, please choose from Highest / Higher / High / Middle / Normal / Low / Lower / Lowest. Frame Rate: select from NTSC: 1 / 3 / 5 / 15 / 30 fps, PAL: 1/ 2.5/5/12.5/25 fps Note: The stream 1 for each channel allows D1, Half-D1, and CIF.
-
Page 28: Video - Camera
PTZ function: select PTZ function ON or OFF ID: This entry is used to assign the own ID code of channel 1 camera. Protocol: Select protocol from Everfocus, Pelco-D, Pelco-P, Samsung and Panasonic. (Default: Pelco-D) Press Apply to apply the setting changes or Reset to reset without saving the change. -
Page 29: Audio
EVS200A/AW Whenever the above three picture parameters are adjusted, the values will be set to the channel automatically. Press Apply to apply the setting changes or Reset to reset without saving the change. 4.5 Audio The EVS200A/AW video encoder can transmit audio to other clients using a built-in microphone or connecting to external microphone to play audio received from other clients via connected speakers. -
Page 30: User
EVS200A/AW Audio Input volume: Adjust the Audio Input Volume for the audio input devices connected to the camera if there are problems with the sound input being too low or high. Press Apply to apply the setting changes or Reset to reset without saving the change. - Page 31 EVS200A/AW • Guest- the lowest level of access, which only allows the user access to the Live View page. Note: Please select Active in Status section to activate user account. Press Apply to apply the setting changes or Reset to reset without saving the change.
-
Page 32: Event
EVS200A/AW 4.7 EVENT An event in the camera is when an Event Type is activated and causes certain actions to be performed. The event type is the set of conditions that specifies how and when which actions will be performed. This table describes how to setup action types and event type. - Page 33 EVS200A/AW Press button to add an event condition. To modify the event list, click on the event and it will be highlighted. Press button to modify the setting. To remove an event from event list, click on the event and it will be highlighted. Press button to remove the event.
- Page 34 EVS200A/AW 1. Click button in Event page. 2. Enter an event name for the event, e.g. Event 1 3. Select “Manual Trigger” as event type. 4. Select “Upload to FTP” as action type. 5. Check “Enable Pre-alarm Buffer” and “Enable Post-alarm Buffer”. For pre-and post alarm buffer setting, please refer to “4.7.3 Alarm”.
-
Page 35: Motion
EVS200A/AW 4.7.2 Motion Motion Detection First, select the channel for motion detection setting. User can define the motion area to be detected by left clicking the mouse to draw lines. Every click is an end point of the line. When the detection area is formed, double click the mouse to have all the lines connected. -
Page 36: Alarm
EVS200A/AW 4.7.3 Alarm Alarm Output Setting Contact Type: Normal Close, Normal Open Duration Time: Select duration time of alarm output from 5 sec, 10 sec, 20 sec, 30 sec, 60 sec, 2 min, 3 min and 5 min. Press Apply to apply the setting changes or Reset to reset without saving the change. -
Page 37: Time Mask
EVS200A/AW Re-trigger Filter Setting Re-trigger Filter: Set a re-trigger filter time, if another event is triggered during this time, this triggered event will be ignored. Press Apply to apply the setting changes or Reset to reset without saving the change. 4.7.4 Time Mask Time Mask Setting Time mask setting allows you to schedule event actions. -
Page 38: System
EVS200A/AW An example on how to set weekend as time mask: Click from time mask setting. Enter Mask name, e.g. Weekend. Check “Sun” & “Sat” boxes. Select “Start time” and “End time” or “Full day”. Press Apply to apply the setting changes or Reset to reset without saving the change. - Page 39 EVS200A/AW Press Apply to apply the setting changes or Reset to reset without saving the change. Set Time Zone Time Zone: Select a time zone according to the location where the camera is in use. Press Apply to apply the setting changes or Reset to reset without saving the change.
-
Page 40: Daylight Saving
EVS200A/AW Press Apply to apply the setting changes or Reset to reset without saving the change. 4.8.2 Daylight Saving Set Daylight Saving Tick Enable Daylight Saving checkbox to enable daylight saving. Set the start time to daylight saving time. Set the start week of daylight saving time: 1 / Last Set the start date of daylight saving time: Sunday / Monday / Tuesday / Wednesday / Thursday / Friday / Saturday... -
Page 41: Sd Card
EVS200A/AW May / June / July / August / September / October / November / December. Set the ending time change of daylight saving time: Choose the “From” time and “End” time when daylight saving ends. Press Apply to apply the setting changes or Reset to reset without saving the change. - Page 42 EVS200A/AW disconnected. Normal: Follow the event actions settings you have made in “Event” menu to record event video to SD card. Overwrite: Select ON for overwriting data when SD card memory is full. Select OFF for not overwriting SD card data. Press Apply to apply the setting changes or Reset to reset without saving the change.
-
Page 43: Serial Communication
EVS200A/AW 4.8.4 Serial Communication RS485 Setting Baud Rate: This field is to set the speed at which is used to transmit instruction or information through the RS485 port on the camera. There are six different speeds, 2400/4800/9600/19200/38400/57600. (Default: 9600) Data Bit: This field is the data bit at which you will be transferring. There are two settings for this option: 8 or 7. -
Page 44: Maintenance
EVS200A/AW 4.8.5 Maintenance Maintenance Server Reboot: The unit is rebooted without changing any of the settings. Use this method by pressing Reboot button if the unit is not behaving as expected. Restore: The unit is restarted and most current settings are reset to the factory default values by pressing Restore button. -
Page 45: Ekb200
EVS200A/AW Upgrade Firmware Upgrade the EVS200A/AW with the latest firmware. Press Browse button to search firmware file. Press Upgrade button to upgrade the firmware. Note: 1. Do not disconnect power to the unit during the upgrade. The unit reboots automatically after the upgrade has completed. (1-5 minutes.) 2. - Page 46 EVS200A/AW to Key No.12) can be set. User can choose action and set value for each Key No. If the command requires a value, such as GoTo Preset [x] or Tour [x], user needs to enter the number [x] in the field "Value". Otherwise, the value option will be disabled. After completing setting, press “Apply”...
- Page 47 EVS200A/AW Joystick IRIS- FOCUS NEAR FOCUS FAR IRIS+ ○ ○ EKB200 Panel There are 20 available Action options, including: Set Preset: When the action of a key is set “Set Preset”, use joystick to select a position and press this key on KEB200 to save the position as Preset Point. Goto Preset: When the action of a key is set “Goto Preset”, press this key on KEB200 and the system will go the Preset Point.
- Page 48 EVS200A/AW KEB200 to start autopan. 10. Stop Autopan: When the action of a key is set “Stop Autopan”, press this key on KEB200 to stop autopan. 11. OSD Menu On: When the action of a key is set “OSD Menu On”, press this key on KEB200 to display OSD Menu on the screen.
-
Page 49: Specifications
EVS200A/AW 5. SPECIFICATIONS VIDEO STREAMING Video Compression H.264/MPEG-4/M-JPEG Video Resolution 4CIF, VGA, CIF, QVGA, QCIF Video Quality 8 levels adjustable Frame Rate Up to 30fps 2 BNC composite, 1 V p-p / 75Ω Video Source NTSC/PAL auto-sense AUDIO Compression Method IMA ADPCM (Pulse Code Modulation) Operation Mode 2 way audio... - Page 50 EVS200A/AW ENVIRONMENTAL Operating Temp. 0°C ~40°C / 32°F~104°F Humidity (20%~80% Humidity)
- Page 51 2-6 Nakase.Mihama-ku. www.everfocus.com Chiba city 261-7118, Japan TEL: 81-43-212-8188 FAX: 81-43-297-0081 www.everfocus.co.jp Ihr EverFocus Produkt wurde entwickelt Your EverFocus product is designed und hergestellt mit qualitativ and manufactured with high quality hochwertigen Materialien und materials and components which can Komponenten, die recycelt und wieder be recycled and reused.
