Optoma TX7000 Brochure

Maximum Flexibility for
Customized Installations
1
2 3 5
6 7 8
9 10
13
12
14 15
21
17 18
19
Optoma's TX7000 provides performance and flexibility to
meet the most demanding large-venue installation
challenges. Powered with 4800 ANSI lumens and the
latest in image and color enhancement technologies, the
TX7000 ensures excellence in projection performance.
Standard, long and short throw lens options, optimized
with PureOptics ED-glass lens elements, create
consistently high picture quality at a wide range of
projection distances. Vertical and horizontal lens shift
further increases the extensive range of installation
options. With its wide array of inputs and management
options, the TX7000 is your ideal solution for large-venue
projection needs.
3D content can be viewed with active LCD shutter glasses when the projector is connected to a
computer with a compatible 3D graphics card. Please visit www.optoma.com for more information.
TX7000
1 Power LED Indicator
2 DVI-D
3 HDMI
4 USB
5 RJ-45
6 VGA 1-In
7 Audio-In (VGA 1)
8 VGA 2-In
9 Audio-In (VGA-2)Component
10 VGA-Out
11 Audio-Out
11
12 BNC (RGBHV/YPbPr)
13 Audio-In
14 Component
15 Audio-In
16
16 RS232
17 S-Video
18 Composite Video
20
19 Audio-In
20 +12V Triggers
21 Power
| Installation Projector
AV Mute
Laser
Display
Zoom-In
Zoom-Out
Left Mouse Button
Menu
Brightness
HDMI
DVI
Video
S-Video
TX7 000 FEATUR ES
4200 ANSI lumens of brightness project
crystal clear images that are easily viewable
by audiences seated in large venues such as
auditoriums and lecture halls
Flexible projector placement with extensive
vertical and horizontal lens shift
Three lens choices with easy-to-change
bayonet mounts create a wide range of
projection distances and image sizes
Remote monitoring and control capabilities
over a LAN network via integrated RJ45
connection – compatible with Crestron
RoomView™
Complete security features protect projector
settings and lock out unauthorized users
www.optoma.com
Freeze
Power
Re-Sync
Keystone
Page Up
Page Down
Volume
Mouse Directional
Control
Right Mouse Button
Enter
Four Directional Keys
Format
Source
YPbPr
VGA
BNC
