DP-101 Print Server Hardware Guide
A
4 P S
RODUCT PECIFICATIONS
Printer Connection
Printer Port: IEEE 1284 standard bidirectional parallel interface with 36-pin connector.
Bidirectional Communication: Hewlett-Packard PJL (Printer Job Language) standard for
bidirectional communication.
Network Connection
Network Standards: IEEE 802.3 10Base-T Ethernet .
Network Data Transfer Rate: 10Mbps (megabits per second) .
Network Connector: RJ-45 connector for 10Base-T twisted pair connection .
Network Protocols
Ethernet Frame Types: 802.2, 802.3, Ethernet II, SNAP (auto-switching)
Transport Protocols: IPX/SPX, TCP/IP NetBEUI, AppleTalk/EtherTalk
TCP/IP Protocols Supported: BOOTP, SNMP, Telnet, TFTP, FTP, lpd, RARP, DHCP
Management and Diagnostics
Standard: SNMP
MIBs: MIB-II (RFC 1213)
Diagnostic LED Indicators: Pw/Tx, Lk/Rx, LPT
Environmental and Physical
Power Supply: External power supply providing 7.5VDC/ 500mA
Dimensions: 92.8mm × 58mm × 25.3mm
Weight: approx. 65g
Operating Temperature: 0 to 50°C
Storage Temperature: -25 to 55°C
Humidity: 5% to 95% non-condensing
Emissions: FCC Class A, CE Class A, BSMI Class A, C-Tick Class A, VCCI Class A
Safety: UL (UL 1950), CSA (CSA950), TUV/GS (EN60950)
8

Product Specifications
