- Page 1 instruction book gebrauchsanweisung instrucciones de uso instruçõnes de uso freezer gefrierschrank congelatore congelatore EUF29400W, EUF29400X...
- Page 2 We were thinking o f y ou when we made this product...
- Page 3 Thank you for choosing a first class product from Electrolux, which hopefully will provide you with lots of pleasure in the future. The Electrolux ambition is to offer a wide variety of quality products that make your life more comfortable. You find some examples on the cover in this manual.
-
Page 4: Scrapping Old Cabinets
The following symbols are used in this manual: Important information concerning your personal safety and information on how to avoid damaging the appliance General information and tips Environmental information Scrapping old cabinets The symbol on the product or on its packaging indicates that this product may not be treated as household waste. -
Page 5: Safety Instructions
Safety instructions Your new freezer may have other functions compared to your previous one. Carefully read these instructions to learn how the appliance works and how to care for it. Keep the instruction booklet. It will come in handy if you later sell the cabinet or give it to somebody else. -
Page 6: Table Of Contents
..HINT and TIPS ....www.electrolux.com ... . -
Page 7: Use
BEFORE USE Before inserting the power plug into the outlet and switching on the cabinet for Position and clean the cabinet as the first time, leave it standing upright explained in the section "Installation". for about 4 hours. Otherwise the compressor may sustain damage. -
Page 8: Functions Menu
First switch on After plugging the plug into the power Select /Switch off /Switch on outlet, if the display is not illuminated, Temperature selection press key (A), appliance on. As soon as the appliance is turned on, The temperature may be regulated by pressing the key (B) to set the desired it is in alarm condition, the temperature flashes and you will hear a buzzer. -
Page 9: Ambient Temperature Function
seconds. You will hear the buzzer and Ambient Temperature Function the icon remains lighted. The ambient temperature function is In this condition the chosen tempera- activated by pressing key D (several tures are automatically set (+ 5°C and times if necessary) until the corres- - 18°C), in the best conditions for ponding icon appears storing food. -
Page 10: Chill Mode Function
We suggest setting the internal tem- This function stops automatically after perature of approximately -18°C, 52 hours. which guarantees proper freezing and It is possible to de-activate the function conservation of the frozen foods. at any time by pressing key D until the corresponding icon will flash and then Attention! key E. -
Page 11: Excessive Temperature Alarm
alarm. Important When normal conditions are restored (door closed): In the event of accidental defrosting, - the acoustic alarm will stop. for example due to a power failure, if the power has been off for longer that the value shown in the technical Cabinet interior characteristics chart under "rising Freezer drawers... -
Page 12: Hint And Tips
· Carefully follow the advice on freezing Removable shelves products in the section "Using the There are the removable shelves inside freezer". This will prevent wasting the freezer. Remove the shelf when energy. large food products need to be frozen. ·... -
Page 13: Maintenance And Cleaning
layer. · The cabinet has been designed for · All parts in the packaging can be easy dismantling and subsequent recycled. recycling. MAINTENANCE and CLEANING Removing the ventilation grille External Cleaning Use water/neutral soap emulsion for The ventilation grille can be removed, e.g. -
Page 14: To Change The Lamp
Before contacting your local Service Force Centre check the following point: Problem Possible cause / Remedy ” ” is displayed in the Please contact your local Electrolux Service temperature display. Force Centre Audible alarm + flashing red Switch off the audible alarm by pressing the warning lamp. - Page 15 It is too warm inside the Set a lower temperature. freezer. Make sure that the door is completely closed and that the insulating strip is complete and clean. If warm food products have been put inside the freezer, wait for a couple of hours and then check the temperature again.
- Page 16 Sound level in cabinet is too The refrigerating system will always produce high. some sounds. A pulsing sound is heard when coolant is pumped inside the cooling pipes. A ticking sound from the thermostat can be heard when the compressor switches on and off.
-
Page 17: Technical Specification
Technical specification Model EUF29400W / EUF29400X Net capacity Freezer l Energy consumption kWh/y Freezing capacity 24 hours Rising time h Dimension mm Height 1800 Width Depth INSTALLATION Electrical cord packaging over for recycling. For more information, contact your local city Do not remove the power cord by pulling on its lead, particulary when the office or the dealer. -
Page 18: Remove The Transport Supports
Installing the cabinet Remove the transport supports When two appliances are placed Remove the transport supports placed beside each other, the distances along the door sides. enclosed in the plastic wrapping Some models are fitted with a silencing should be glued between the pad under the cabinet. - Page 19 To obtain the best performance from the 50mm cabinet, ensure: · the cabinet is placed in a dry, cool place and is not exposed to direct sunlight. · the cabinet is not placed close to a source of heat, e.g. a cooker or dishwasher.
-
Page 20: Door Reversal
Door Reversal 1. Close the cabinet and remove the plug from the electrical socket. 2. Remove the ventilation grille. There is a part on the grille that can be removed. Remove and reposition it on the other side. 3. Put the cabinet on a wooden board when it is laid down. -
Page 21: Electrical Connection
7.Unscrew the two screws on the hinge 8. Remove the cover on the front Reassembly in reverse order on the opposite side. Raise the cabinet and replace the ventilation grille. 9. To transfer the handle. Unscrew the screws. Fit the handle onto the opposite side by turning it one half circle. -
Page 22: Guarantee/Customer Service
• Products of Electrolux manufacturer 12 months of the date of the purchase that are not marketed by Electrolux this Electrolux appliance or any part the- Service and Spare Parts reof is proved to be defective by reason In the event of your appliance requiring... -
Page 23: European Guarantee
Customer Care European Guarantee For general enquiries concerning your This appliance is guaranteed by Electrolux in Electrolux appliance, or for further infor- each of the countries listed at the back of this user manual, for the period specified in the mation on Electrolux products please appliance guarantee or otherwise by law. - Page 24 Svizzera Electrolux Ljubljana, d.o.o. Slovenija +38 61 24 25 731 Tržaška 132, 1000 Ljubljana Electrolux Slovakia s.r.o., Electrolux Domáce Slovensko +421 2 43 33 43 22 spotrebièe SK, Seberíniho 1, 821 03 Bratisla- Suomi +35 8 26 22 33 00 Konepajanranta 4, 28100 Pori Electrolux Service, S:t Göransgatan 143,...
- Page 25 818 40 02-00/7 01092006...
