Primary Harness (H1) Wiring Diagram; Primary Harness Wire Descriptions; P P E E R R I I P P H H E E R R A A L L P P L L U U G G -I I N N H H A A R R N N E E S S S S E E S; T T R R A A N N S S M M I I T T T T E E R R / / R R E E C C E E I I V V E E R R L L E E A A R R N N R R O O U U T T I I N N E - Directed Electronics PYTHON 480XP Installation Manual

Primary Harness (H1) Wire Connection Guide

Primary Harness (H1) Wiring Diagram

___
ORANGE
H1/1
___
WHITE
H1/2
___
WHITE/BLUE
H1/3
___
BLACK/WHITE
H1/4
___
GREEN
H1/5
___
BLUE
H1/6
___
VIOLET
H1/7
___
BLACK
H1/8
___
H1/9 OPEN
___
H1/10 BROWN
___
H1/11
RED
___
H1/12
RED/WHITE

Primary Harness Wire Descriptions

H1/1 ORANGE (-) Ground-When-Armed Output
This wire supplies a (-) 500 mA ground as long as the system is armed. This output ceases as soon
as the system is disarmed. The orange wire is pre-wired to control the 8618 starter kill relay.
NOTE: if using the H1/1 Orange wire to activate an add-on accessory such as window automation,
pager or voice module a 1Amp diode must be installed to ensure proper operation. Insert the diode
as shown in the following diagram.
