Emerson Research fYi iP105BK Owner's Manual

Portable stereo speaker system with am/fm digital tuner and digital alarm clock
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Portable Stereo Speaker System
with AM/FM Digital Tuner
and Digital Alarm Clock
OWNER' S MANUAL
iP105BK
®
Made for all iPod
models including iPod
Visit our web site at www.emersonradio.com
iP105_052207.p65
®
nano, iPod
30
R
®
®
shuffle and iPod
22/5/2007, 11:37
mini

Advertisement

Table of Contents
loading

Related Manuals for Emerson Research fYi iP105BK

Summary of Contents for Emerson Research fYi iP105BK

  • Page 1 Portable Stereo Speaker System with AM/FM Digital Tuner and Digital Alarm Clock OWNER’ S MANUAL iP105BK ® Made for all iPod models including iPod Visit our web site at www.emersonradio.com iP105_052207.p65 ® ® nano, iPod shuffle and iPod 22/5/2007, 11:37 ®...

  • Page 2: Important Safety Instructions

    TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. WARNING: TO REDUCE THE The lightning flash with arrow- head symbol, within an equi-...
  • Page 3 … … … .For Your iPod Thank you for purchasing this portable speaker system for your iPod Emerson Research. This compact system is perfect for those times when you want to share the music with your friends, or when using ear buds or headphones is not convenient.

  • Page 4: Fcc Information

    I M P O R TAN T N O T E S • Avoid installing this unit in places exposed to direct sunlight or close to heat radiating appliances such as electric heaters, on top of other stereo equipment that radiates too much heat, places lacking ventilation or dusty areas, places subject to constant vibration and/or humid or...

  • Page 5: Preparation For Use

    If you do dispose of the carton of the carton and packing materials please do so properly and recycle. Emerson cares about our environment.

  • Page 6: Installing The Batteries

    Installing The Batteries There are two battery compartments on the back cabinet. Remove the battery compartment covers by pressing down on the ‘ arrow’ marks and sliding the covers downward in the direction of the arrows as shown. Install 6 “C” batteries in the main compartment as shown. Place the battery ribbon into the compartment before inserting the batteries to make removing the batteries easier.

  • Page 7: Replacing The Batteries

    Replacing The Batteries When the sound of the system becomes weak or distorted during battery operation it is probably time to replace the 6 “C” batteries. The life expectancy of the batteries depends on a number of factors including the temperature and the volume level at which the system is operated.

  • Page 8: Protect Your Furniture

    Power Source This system is designed to operate on 120V AC 60Hz house current only. Connecting this system to any other power source may cause damage to the system and such damage is not covered by your warranty. AC Outlet AC Plug NOTE: The system has a polarized AC plug with one wide blade and one...
  • Page 9 L O C AT I O N O F C O N T R O L S AN D Front Panel 4 5 6 7 8 Back Panel iP105_052207.p65 I N D I C ATO R S 10 11 12 22/5/2007, 11:37...

  • Page 10: Multifunction Display

    1.) Speakers. 2.) Clear Protective Cover. 3.) Carrying Handle. 4.) POWER Button - Press to turn the unit ‘ On’ or ‘ Off’ . 5.) FUNCTION Button - Press repeatedly to switch among iPod, AUX, and RADIO modes. 6.) TIME SET/MEMORY Button - To set time in power ‘ Off’ mode. Saves radio stations in the memory in radio mode.

  • Page 11: Lcd Display

    LCD Display 1.) Radio Band and Clock AM Indicator. 2.) iPod Select Indicator. 3.) RADIO Select Indicator. 4.) Radio Band FM Indicator. 5.) XBASS Indicator. FM Stereo Indicator. (Buzzer, Radio, iPod) Alarm Indicators. 8.) MEMORY Indicator. 9.) Volume Level (00-30), Radio Channel (1-20) Display. 10.) Volume Indicator.

  • Page 12: Setting The Clock

    O P E R AT I N G I N S T R U C T I O N S • Regardless of whether you will be using the system on AC or battery power, make sure that you have installed the 2 “AAA” back–up batteries.
  • Page 13 1.) Press the TIME SET/MEMORY button once. “12:Hr” appears on the display and the “12” flashes. This indicates that the display is set for the 12-Hour format with AM/PM indicators. This is the factory default setting. You also have the option of displaying the time in 24-Hour format, also referred to as “Military Time”.
  • Page 14 4.) Press the TIME SET/MEMORY button again. The hour digit stop flashing and the minute digits begin to flash. Press either the move the display back or forward to the correct minute. 5.) When the correct time is showing on the display press the TIME SET/MEMORY button once more.
  • Page 15 Display Viewing Angle – IMPORTANT The display in this portable system is designed to be the clearest and most visible when you are looking down at the display from above. If you are looking at the display ‘ head-on’ , or looking up at the display from below, the numbers on the display may seem to fade or may become completely invisible.

  • Page 16: Listening To The Radio

    Listening To The Radio 1.) Press the POWER button to turn the power ‘ On’ . The display back lighting comes on and the display appears as: Press the BAND button to switch the radio between FM and AM bands if necessary. When listening to the FM band, raise the telescoping FM rod antenna and extend it to its full length.

  • Page 17: Last Station Memory

    4.) To increase the bass response, especially at lower volume levels, press the X-BASS button. The XBASS indicator appears in the display. NOTE: if you experience any distortion when listening to music with strong bass at higher volume levels, switch the Bass Boost circuit ‘...

  • Page 18: Antenna Information

    Antenna Information FM - Raise the telescoping FM rod antenna and adjust its direction until you find the position that provides the best reception. AM - The AM bar antenna is inside the cabinet. If AM reception is unsatisfactory try turning the entire unit slowly until you find the position that provides the best reception.

  • Page 19: Presetting Stations In The Tuner Memory

    Presetting Stations In The Tuner Memory The tuner in this system has 40 preset station memories that allow you to store up to 20 of your favorite AM and 20 of your favorite FM stations. 1.) Tune to the first station that you wish to memorize by either the Automatic or Manual method above.
  • Page 20 Recalling Stations In The Tuner Memory Turn the system ‘ On’ and select the Radio function as usual. Press the ALARM/PRESET UP button repeatedly to scroll through all of the station in the tuner memory. Changing A Station In The Tuner Memory Tune to the new station that you wish to memorize, press the TIME SET/MEMORY button and then press the ALARM/PRESET UP button until the display is showing the memory that you wish to change.
  • Page 21 iP105_050807.p65 9/5/2007, 15:21...

  • Page 22: Docking And Playing Your Ipod

    Docking And Playing Your iPod The docking station in this system was designed in accordance with Apple’ s Universal Well design. Any model of dockable iPod including the audio only models, iPod ® nano, and the iPod models with video capability. To properly support your iPod specifically designed for your model.
  • Page 23 2.) Place your iPod ® into the docking adapter. Make sure that your iPod inserted into the docking adapter and that the HOLD switch on your iPod set to the ‘ Off’ position. Close the splash resistant cover. If you are operating this system on AC power your iPod and show the ‘...

  • Page 24: Listening To An Ipod

    Listening To An iPod 1.) Connect the headphone jack from your iPod CD player to the AUX IN (Auxiliary Input) jack on the back panel of this unit. ® (2G iPod Shuffle) NOTE: The connection cable is not included. 2.) Press the POWER button of this system to turn the power ‘...
  • Page 25 Setting The Alarm Time And Alarm Mode (Buzzer/Radio/iPod) NOTE: We suggest that you set the Alarm time with the power ‘ On’ and the Function set to the AUX mode. This will keep the display backlighting ‘ On’ and make the settings easier. 1.) Depress and hold the ALARM/PRESET UP button for 3 seconds.
  • Page 26 5.) To change the alarm mode or to cancel the alarm, continue to press the ALARM/PRESET UP button. The alarm indicator changes from Buzzer to Radio to iPod mode. Press the ALARM/PRESET UP button once more and the alarm indicator disappears to confirm that the Alarm is ‘...

  • Page 27: Snooze Control

    Snooze Control When the alarm turns ‘ on’ in the morning you may press the SNOOZE button for a few minutes extra sleep. The unit turns ‘ Off’ and the Alarm indicators flash faster. The alarm will stop for 9 minutes and then turn on again.

  • Page 28: Care And Maintenance

    FOR CUSTOMER SERVICE,PLEASE WRITE TO: iP105_052207.p65 TO FIND THE LOCATION AND PHONE NUMBER OF YOUR NEAREST SERVICE CENTER PERMITTED TO PERFORM WARRANTY... 1-800-695-0098 PLEASE CALL: 1-800-898-9020 Emerson Radio Corp., Consumer Affairs Dept., 5101 Statesman Drive, Irving, TX 75063. 22/5/2007, 11:37...

  • Page 29: Limited Warranty

    For repair or replacement, pack your unit in a padded box, enclose your check or money order payable to Emerson Radio Corp. in the amount of $9.00 (not required by California residents) to cover shipping and handling costs, and enclose a copy of your proof of purchase.
  • Page 30 iP105-052207-01 Printed in China iP105_052207.p65 22/5/2007, 11:37...
