Datalogic website (www.scanning.datalogic.com) or provided on appropriate media. If you visit our website and would like to make comments or suggestions about this or other Datalogic publications, please let us know via the “Contact Datalogic” page. Disclaimer...
Introduction This manual contains instructions for changing interfaces and bar codes for customizing the scanner's operation. Since the QuickScan 6000/6000 Plus scanner contains software enhancements and characteristics that set it apart from other scanners, it is recommended that this guide be used as the sole source of programming labels and information (except for other QuickScan 6000/6000 Plus product-specific publications).
Changing Interfaces To change a scanner's interface… Hardware If necessary, replace the scanner's interface cable to match the new host terminal's connection requirements. To disconnect the cable from the scanner, insert a .050” hex driver or bent paper clip into the CABLE RE- LEASE hole, and press down to unlock the cable connector.
Page 7
OCIA • Datalogic OCIA • NCR 8-Bit OCIA • SNI OCIA • NCR 9-Bit OCIA RS-232 • Datalogic RS-232 • SNI RS-232 • IBM 4683/84, 4693/94 Port 5B • 4682/92 Port E • IBM 4683/84, 4693/94 Port 9A, 9B, 9C, 9E...
Customizing Your Scanner Operation When enabling a new interface, it may be necessary to modify the original factory settings to match your specific host system's communication and symbology requirements. Check with your system administrator to identify your host system's specific interface requirements to ensure that they match the new interface you've selected.
Programming Overview This section describes how to set the scanner's programmable features. These features can be configured using the bar code labels contained in this manual or by using commands sent from the host. Refer to Appendix A, Additional Information, for host programming details.
The Programming Session It is possible to program multiple features during a single programming session (a programming session is defined as the period of time between scanning the “set” label and scanning the “end” label). However, it is recommended that sessions be limited to one feature, as it can be difficult to discover where an error has been made, should you make a mistake in the programming sequence.
If You Make a Mistake... If, during a programming session, you find that you are unsure of the scanner's settings or wish to reset the scanner's configuration, use the Return to Factory Settings label on this page to return the scanner's configuration to the factory settings. Scanning this label will also reset any changes made during previous programming sessions.
Where To Go From Here Programming is easy and straightforward if you follow these steps: If you are changing interfaces, first connect the scanner to the new host using the new interface cable. Scan the interface enable bar code label Scan any feature labels that are unique to the interface you are currently programming.
IBM 4683/84 • 4693/94 Port 5B Interface Selection Scan this label to enable the IBM 468x Port 5B interface. IBM 4683/84 • 4693/94 Port 5B Settings Data Format: Send As Code 39 — converts bar code data (UPC/EAN, add-ons, Code 93, Codabar, MSI/Plessey and Code 128) into Code 39 format before sending the data to the host.
IBM 4683/84 • 4693/94 Port 9A, 9B, 9C, 9E I/F Selection Scan this label to enable the IBM 468x/9x Port 9x interface. IBM 4683/84 • 4693/94 Port 9A, 9B, 9C, 9E Settings Data Format: Send As Code 39 — converts bar code data (UPC/EAN, add-ons, Code 93, Codabar, MSI/Plessey and Code 128) into Code 39 format before sending the data to the host.
IBM 4682/92 Port E Interface Selection Scan this label to enable the IBM 468x/9x Port E interface. IBM 4682/92 Port E Settings Data Format: Send As Code 39 — converts bar code data (UPC/EAN, add-ons, Code 93, Codabar, MSI/Plessey and Code 128) into Code 39 format before sending the data to the host.
Datalogic OCIA Interface Selection Scan this label to enable the Datalogic OCIA interface. NCR OCIA Eight Bit (short format) Interface Selection Scan this label to enable the NCR OCIA (short format) interface. NCR OCIA Nine Bit (long format) Interface Selection Scan this label to enable the NCR OCIA Nine Bit (long format) interface.
OCIA Options Use these labels to change the settings as desired. The following brief descriptions explain each selection. Beep if Not on File — when enabled requires the scanner to beep when a label is scanned that is not on file. Host Commands —...
Wand Emulation Interface Selection Scan this label to enable the Wand Emulation interface. Wand Emulation Settings ---------------------------------------------- ----------- PACE ----------- PACE (660 µ ) -------------------- (330 µ ) -------------------- ----- RANSMIT IN ORMAL ORMAT C39 F -------- RANSMIT IN ORMAT C128 F ------ RANSMIT IN...
Page 19
--------------------------------- -------------------------------- ------------- RANSMIT OISE ------ RANSMIT OISE ----------------------------- NABLE ----------------------------- ISABLE ---------------------------------------------- Go to the sections titled Symbology Selection and General Features in the back of this programming guide if you want to change any other settings for this interface. Programming Guide...
RS-232 Interface Selection Scan this label to enable the standard RS-232 interface (Datalogic RS-232). SNI RS-232 Interface Selection Scan this label to enable the SNI RS-232 interface. RS-232 Communication Parameters This section contains the following RS-232 communication parameters in the order listed: •...
Page 21
Baud Rate Use the bar codes on this page to select the communications Baud Rate. Only one Baud Rate selection may be active at any one time. The last Baud Rate label you scan during a programming session will be the setting that is stored when you scan the END label.
Page 22
Data Format Settings The bar codes on this page can be used to select the data format configu- ration needed to communicate with your system. ---------------------------------------------- ------------------------------- -------------------------------- -------------------------------- ------------------------------- ------------------------------ PACE --------------------------------- -------------------------------- ------------------------ EVEN ------------------------- IGHT ---------------------------------------------- QuickScan 6000/6000 Plus...
Handshaking Review your system documentation to identify handshaking requirements, and use these labels to change the settings if required. The following brief descriptions explain each selection. Hardware Control CTS/RTS Flow Control — is hardware handshaking. The scanner activates the RTS (Ready to Send) line when it is ready to send data to the host.
Software Control — this is software handshaking that allows the host to control data transmission. If the host sends an X command to the scanner, the scanner will not send the bar code data until it receives an X command from the host. If the host sends the command during data transmission, the host will receive additional characters for no more than 2msec NOTE...
RS-232 ACK/NAK Options (QuickScan 6000 Plus ONLY) Several ACK/NAK parameters can be set for your QuickScan 6000 Plus scanner. Contact your Datalogic dealer if the specific ACK/NAK option you wish to set is not included in this section. Options for RS-232 ACK/NAK are: •...
Page 26
Intercharacter Delay Intercharacter Delay refers to the pause, if any, between each character before it is sent to the host. This time delay is used to control the flow of data from the scanner, but it should not be required for most applications. Use these labels to select the desired Intercharacter Delay.
This section contains the following PC Keyboard Wedge communication parameters in the order listed: Keyboard Wedge Communication Parameters • Interface Selection • Connect to Laptop • Caps lock Settings • Country modes • Intercharacter Delay Go to the sections titled Symbology Selection and General Features in the back of this programming guide if you want to change any other settings.
PC Keyboard Wedge Interface Selection—continued The scanner supports ten PC Keyboard Wedge interfaces. The table below defines the different interface selections. ---------------------------------------------- A------------------------------------ B------------------------------------ C ----------------------------------- D ----------------------------------- E------------------------------------ F ------------------------------------ G ----------------------------------- H ----------------------------------- I ------------------------------------- J ------------------------------------ ---------------------------------------------- Keyboard Wedge interfaces G through J are only supported by the QuickScan 6000 Plus scanner.
PC Keyboard Wedge – Connect to a Laptop/No Keyboard Attached If no keyboard is attached, the scanner must provide the acknowledge signal to the PC. In this case, enable the "Laptop/No External Keyboard" mode. If a keyboard is attached, enable "Keyboard Attached". Laptop (integrated keyboard) —...
Caps Lock (QuickScan 6000 Plus ONLY) Three caps lock settings are available for the QuickScan 6000 Plus scanner. These are: • Caps Lock Off — to send character data (to the host)in normal format. • Caps Lock On — to send character data (to the host) in reverse case: (a…z) = (A…Z) (A…Z) = (a…z)
Country Mode (QuickScan 6000 Plus ONLY) The following country/languages can be selected for the QuickScan 6000 Plus scanner when configured for I/F Type E only: • • France • Portugal • Japanese 106-Key • Belgium • Germany • Spain • Britain •...
Page 33
Country Mode (QuickScan 6000 Plus ONLY)—continued ------------------------------- PAIN ---------------------------- WEDEN ----------------------- WITZERLAND 106-K --------------- APANESE ---------------------------------------------- Programming Guide...
Intercharacter Delay Intercharacter Delay refers to the pause, if any, between each character before it is sent to the host. This time delay is used to control the flow of data from the scanner, but it should not be required for most applications. Use these labels to select the desired Intercharacter Delay.
Label Transmit Format Configuration Items (RS-232 and Keyboard Wedge Interfaces Only) If you need to send information in addition to label data, the scanner can be configured to transmit prefixes and/or suffixes as well as symbology specific identifier characters (Label I.D.). Prefix &...
Page 37
• Non-symbology specific characters (1-2) as a prefix + label data + non-symbology specific characters (1-2) as a suffix + label data + C • Non-symbology specific characters (1-2) as a prefix + symbol- ogy specific characters (0-2) + label data + non-symbology specific characters (1-2) as a suffix + PP + label data + C •...
Non-Symbology Specific Items Setting Non-Symbology Specific Prefix(es) These characters will be added to the standard label format when your host system has specific and unique requirements for information added to the barcode label data before it is sent to the host. Identify your specific system requirements before adding or modifying these settings, then...
Page 39
Setting Non-Symbology Specific Suffix(es) These characters will be added to the standard label format when your system has specific and unique requirements for information added to the barcode label data before it is sent to the host. Suffix characters follow the label data.
Page 40
Setting A Single Character Prefix or Suffix To set one ASCII character as a prefix or suffix, follow steps one through four on the previous two pages (select prefix or suffix), then... 1. Scan the two digit Hex Code for that character. (e.g.
Page 41
6 ------------------------------------ 7 ------------------------------------ 8 ------------------------------------ 9 ------------------------------------ A------------------------------------ B------------------------------------ C ----------------------------------- D ----------------------------------- E------------------------------------ F ------------------------------------ ------------ HARACTER ---------------------------------------------- Programming Guide...
ASCII Character Set The table on this page shows a set of ASCII characters and their correspond- ing Hex Values. The Hex Values in this table are needed for setting symbol- ogy specific label identifiers, as well as enabling custom prefix and suffix characters.
Symbology-Specific Label I.D. Setting Symbology-Specific Label Identifiers (Label I.D.) Symbology-specific label identifiers comprise one or two ASCII characters that can precede or follow barcode label data as it is transmitted to the host. The host uses these characters as a means of distinguishing be- tween symbologies.
Page 44
Setting Symbology Specific Label Identifiers (Label I.D.) (Continued) 4. Scan the label representing the symbology whose label identifier you wish to modify. In our example, we would scan the 'UPC-A' symbology label. 5. Identify and scan the digits that correspond to the Hex Values.
Page 47
How to Set Single Character Label I.D. If you only want a single character identifier, follow this modified proce- dure for setting label identifier. 1. Look at the ASCII chart shown on page 38 and identify the ASCII character and the corresponding Hex Code for the ASCII character you will use as the symbology specific identifier.
Page 48
Disabling Label I.D. for a Specific Symbology This procedure is the same as setting a single character symbology identifier, except you should scan two zeros and the One Character Only labels before scanning the END label. Symbology Specific Label Identifiers Characters Use the labels on this page to change or modify symbology identifiers.
Page 49
A------------------------------------ B------------------------------------ C ----------------------------------- D ----------------------------------- E------------------------------------ F ------------------------------------ ------------ HARACTER ---------------------------------------------- Programming Guide...
INTERFACE TYPE IBM Port 5B IBM Port 9B IBM Port E NCA OCIA (8 bit) NCA OCIA (9 bit) Datalogic OCIA SNI OCIA Wand Emulation RS-232 Keyboard Wedge QuickScan 6000 and QuickScan 6000 Plus QuickScan 6000 Plus The symbology can be enabled through configuration item;...
Symbology Options Overview Enable All Symbologies — allows the scanner to auto-discriminate between all the symbologies in this list. Use this selection only if you must constantly read a wide variety of symbologies. Turn to the following pages for enabling additional symbology specific options. Disable All Symbologies —...
IATA — is a special symbology subset of Standard 2 of 5. Enabling IATA selects this custom code as the active Standard 2 of 5 symbology (superced- ing any other Standard 2 of 5 features). NOTE Standard 2 of 5 must be enabled before IATA can be enabled. Enable Codabar —...
Symbology Selection The bar code programming labels on the following pages allow you to enable or disable individual symbologies. NOTE If you enable a symbology that has additional features that should be set, turn to the pages that support that symbology and its programmable features.
Page 54
5 ----- NABLE NTERLEAVED 5 ----- ISABLE NTERLEAVED 5-------- NABLE TANDARD 5 ------- ISABLE TANDARD IATA -------------------- NABLE IATA --------------------- ISABLE Standard 2 of 5 must first be enabled before IATA can be enabled; however, the scanner will not read Standard 2 of 5 labels when IATA is enabled.
Page 55
------------------ NABLE ODABAR ------------------ ISABLE ODABAR 93------------------ NABLE 93 ----------------- ISABLE 128 ---------------- NABLE -------------- ISABLE MSI/P ------------ NABLE LESSEY MSI/P ------------ ISABLE LESSEY ---------------------------------------------- Code 128 is always active for the purpose of reading programming bar code labels. Scanning the DISABLE ALL SYMBOLOGIES or the DISABLE CODE 128 labels disables Code 128 transmission to the host (disables decoding of all C128 non-programming labels).
UPC/EAN Options The information below provides a brief description of the programmable UPC/EAN features included on the following pages. Expand UPC-A to EAN-13 — adds a leading zero to a UPC-A label which 'expands' the label to the EAN-13 data format. Selecting this feature also changes the symbology ID to match those required for EAN-13.
Due to the structure of add-on codes, selecting the Optional setting makes it impossible to ensure that the scanner will always read the add-on portion of the label. Datalogic makes no guaran- tee, either written or implied, that scanners with optional add-on decoding enabled will perform with the speed and accuracy re- quired for any given application.
Price/Weight Check Digit The price/weight check digit selections allow you to specify whether the scanner should calculate an extra check digit based on a four or five-digit price/weight block and compare it with the price/weight check digit contained in the bar code. If the calculated check digit does not match the value of the check digit contained in the bar code, the label will be rejected as invalid.
Page 60
These settings affect UPC data format when RS-232 or OCIA is the active interface. Number System Digit (NSD) settings operate with RS-232 and Keyboard Wedge interfaces ONLY. ---------------------------------------------- ---------------- HECK IGIT -------- HECK IGIT ----------------------- --------------- --------------- HECK IGIT ------- HECK IGIT -----------------------...
Page 61
EAN Data Format Settings These settings affect EAN data format when RS-232, Keyboard Wedge or OCIA is the active interface. ---------------------------------------------- ---------------- HECK IGIT -------- HECK IGIT ---------------- HECK IGIT -------- HECK IGIT ---------------------------------------------- Programming Guide...
Code 39 Options The Code 39 symbology has the following programmable features: Check Digit — calculates the Check Digit to verify that the Check Digit contained in the bar code label is correct. If you enable this feature, your bar codes must contain a Check Digit.
Code 39 ( continued Follow these steps to set Code 39 Minimum Label Length: 1. Identify the minimum length setting you want to make. The selectable range is 00 to 48 characters. 2. Scan the SET label. 3. Scan the SET CODE 39 MINIMUM LABEL LENGTH bar code. Setting Lengths If you are setting a length less than ten, you must scan a zero first and then the length digit ( 04, 06, 08).
Code 128 Options AIM Symbology ID Prefix The Automatic Identification Manufacturers, Inc. of the United States (AIM USA) have standardized the reporting of data sources from bar code reading devices. Sending the AIM symbology prefix identifies the symbol- ogy to the host terminal, allowing it to specifically differentiate between UCC-128 (Code 128 with Function Character 1 in the first position) and standard Code 128 symbols.
Interleaved 2 of 5 The Interleaved 2 of 5 symbology has the following programmable features: Check Digit — calculates the Check Digit to verify that the Check Digit contained in the bar code label is correct. If you enable this feature, your bar codes must contain a Check Digit. You may also choose to transmit or not transmit the Check Digit independent of whether the Check Digit is calculated by the scanner.
• Set Second Fixed Length — use this label to instruct the scanner that the next two programming labels you scan will define the second fixed label length. Again, this setting can be any even number of digits between 02 and 50 digits.
Page 69
Setting Interleaved 2 of 5 Fixed and Minimum Label Lengths All interfaces that are shipped with the standard factory configuration are set to read variable length labels. If you switch from variable to fixed length labels (by disabling variable lengths on the previous page), the default fixed label lengths are 14 digits and 8 digits.
Standard 2 of 5 The Standard 2 of 5 symbology has the following programmable features: Check Digit — calculates the Check Digit to verify that the Check Digit contained in the bar code label is correct. If you enable this feature, your bar codes must contain a Check Digit. You may also choose to transmit or not transmit the Check Digit independent of whether the Check Digit is calculated by the scanner.
• Set Second Fixed Length — use this label to instruct the scanner that the next two programming labels you scan will define the second fixed label length. Again, this setting can be any number of digits between 01 and 50 digits.
Setting Standard 2 of 5 Fixed and Minimum Label Lengths All interfaces that are shipped with the standard factory configuration are set to read variable length labels. If you switch from variable to fixed length labels, the default fixed label lengths are 14 digits and 8 digits. Follow the steps below to change these defaults.
Codabar Options The Codabar symbology has the following programmable features: Check Digit — calculates the Check Digit to verify the label's contents have been read correctly. If you enable this feature, your bar codes must include a Check Digit. You may also choose to transmit or not transmit the Check Digit.
Codabar Check Digit & Variable Length These programming labels determine whether you compute and send the check digit contents and enables variable length. If you want to set the scanner to read only fixed length labels, follow the procedures on the following pages. ---------------------------------------------- -------------------- T COMPUTE...
Codabar Start/Stop Character These bar codes allow you to set the Start/Stop character format and trans- mission. Refer to your host user's manual to identify your system require- ments, then use these labels to select which characters are transmitted. ---------------------------------------------- ------------- ATCH NOT EQUIRED...
Codabar Fixed Length Most scanners shipped from the factory are set to read variable length labels for Codabar. If you switch from variable to fixed length labels, the factory set fixed label lengths are 14 and 08. Follow the steps below to change these defaults.
Page 80
5. Scan the SET SECOND FIXED LENGTH label. 6. Set the second fixed label length by scanning the correct digits from this page. The selectable range is from 03 to 50 digits. 7. Scan the END label to complete the procedure. 0 ------------------------------------ 1 ------------------------------------ 2 ------------------------------------...
MSI/Plessey Check Digit MSI/Plessey Check Digit options include: Check Digit Calculation — calculates the Check Digit to verify the labels contents have been read correctly. If you enable this feature, your bar codes must include a Check Digit. You may also choose to transmit or not transmit the Check Digit.
MSI/Plessey Fixed Length With the QuickScan 6000/6000 Plus scanner, you now have the option of requiring MSI/Plessey labels to have one or two fixed length(s). To set fixed length(s) for MSI/Plessey labels: 1. Identify the fixed length setting(s) you wish to make. Fixed lengths can be set from four to fifteen, including check character(s).
General Features The following section contains the general features that are common to all interfaces. These features allow modification of the scanner's behavior to accomodate user preferences. Good Read Beeper Settings These labels provide options for the scanner's audible 'beep' signal. Audible Signal —...
Read Verification QuickScan 6000/6000 Plus programming has been improved to allow selec- tion of read verification "minimum read" requirements by symbology type, as well as universally. This means that the scanner needn't waste valu- able time verifying high-confidence symbologies, while offering the security of multiple read verification on less reliable codes.
Page 87
Read Verification by Symbology To set the minimum read requirement for a desired symbology: 1. Scan the SET label. 2. Scan one symbology label below to select the symbology to be verified. 3. Scan the label on the following page representing the amount of times you wish a bar code label of that symbology type to be read before transmission to the host.
Page 88
5 ------ ERIFY NTERLEAVED 5 -------- ERIFY TANDARD ------------------- ERIFY ODABAR 93 ------------------ ERIFY 128 ---------------- ERIFY MSI/P ------------- ERIFY LESSEY ------------------------- ------------------------ EADS ---------------------- HREE EADS ----------------------- EADS ---------------------------------------------- The Standard 2 of 5 symbology is available for QuickScan 6000 Plus scanners ONLY. QuickScan 6000/6000 Plus...
Low Power Mode QuickScan 6000/6000 Plus incorporates two optional low power modes to optimize power usage and extend scanner life. NOTE These features are only available with RS-232, Wand Emulation and Keyboard Wedge host interfaces. WARNING DO NOT use Very Low Power Mode in conjunction with Stand Mode, as this feature is not compatible and may cause unexpected behavior.
Debug Mode When enabled, this mode will cause any product labels that are read to be discarded with no attempt made to transmit them to a host. Any host scanning control will also be disabled while this option is in effect. This mode may be enabled in conjunction with any of the defined host interfaces.
If you require more information about using your host system to change the scanner's programmable features or detailed instructions about creating multifunction labels, contact your local dealer or distributor or call (in the U.S. or Canada) Datalogic Technical Support at 1-800-547-2507.
Page 95
DEFAULT IBM 468x/9x IBM 468x/9x Record Your Port 5B Port 9x Default Set FEATURE OCIA (DLS) OCIA (SNI) General Features Audible Signal Enable Enable Enable Enable Power-Up Beep Enable Enable Enable Disable Beeper Volume High High High Beep Duration 100ms 100ms 100ms 100ms...
Page 96
DEFAULT Wand Keyboard Record Your Emulation Wedge Default Set FEATURE RS-232 SNI RS-232 General Features Audible Signal Enable Enable Enable Enable Power-Up Beep Enable Enable Enable Enable Beeper Volume High High High Beep Duration 100ms 100ms 100ms 100ms Beep/LED After Beep/LED After Beep/LED After Beep/LED After...
Page 97
DEFAULT IBM 468x/9x IBM 468x/9x Record Your Port 5B Port 9x Default Set FEATURE OCIA (DLS) OCIA (SNI) RS-232 I/F Settings RS-232 I/F SNI RS-232 I/F Baud Rate Parity Stop Bits Data Bits Hardware Control (RTS/CTS) Software Control Intercharacter Delay Keyboard Wedge I/F Settings KBD Wedge I/F Type...
Page 98
DEFAULT Wand Keyboard Record Your Emulation Wedge Default Set FEATURE RS-232 SNI RS-232 RS-232 I/F Settings RS-232 I/F Enable Std SNI RS-232 I/F Enable Baud Rate 9600 9600 Parity None Stop Bits Data Bits Hardware Control Use CTS/RTS (RTS/CTS) Disable Flow Control Disable Software Control...
Page 99
DEFAULT IBM 468x/9x IBM 468x/9x Record Your Port 5B Port 9x Default Set FEATURE OCIA (DLS) OCIA (SNI) UPC/EAN Options UPC-A to EAN-13 Expansion Don’ t Expand Don’ t Expand Don’ t Expand Don’ t Expand UPC-E to UPC-A Expansion Don’...
Page 100
DEFAULT Wand Keyboard Record Your Emulation Wedge Default Set FEATURE RS-232 SNI RS-232 UPC/EAN Options UPC-A to EAN-13 Expansion Don’ t Expand Don’ t Expand Expand Don’ t Expand UPC-E to UPC-A Expansion Don’ t Expand Don’ t Expand Don’ t Expand Don’...
Page 101
DEFAULT IBM 468x/9x IBM 468x/9x Record Your Port 5B Port 9x Default Set FEATURE OCIA (DLS) OCIA (SNI) Codabar Options Check Digit Compute Require Require Require Ignore Check Digit Transmit Transmit Transmit Don’ t Transmit Transmit Variable Length Labels Enable Enable Enable Enable...
Page 102
DEFAULT Wand Keyboard Record Your Emulation Wedge Default Set FEATURE RS-232 SNI RS-232 Codabar Options Check Digit Compute Ignore Require Ignore Require Check Digit Transmit Transmit Transmit Transmit Don’ t Transmit Variable Length Labels Enable Enable Enable Enable Gap Check Disable Disable Disable...
