Lightolier Power-Connect La Cable Specification

Page 1 of 2
FEATURES
• For feeding downlights or exit signs.
• Male (power-in) and female (power-out)
configuration.
• Adapter is 2 13/16" x 2 13/16" x 13/16" installed.
• Die cast housing with zinc plated steel cover plate.
• Fixture adapters can be wired for single or multi-level use.
• Thru wired for three circuits.
• Type 6M adapter wires are #18 AWG TFN solid copper conductors,
600 volt.
• Type 7M adapter wires are #12 AWG THHN stranded copper
conductors, 600 volt.
• Type 6M and 7M have 6 inch tap leads.
• 1/2" K.O. connector for mounting to fixture.
APPLICATION
The fixture adapter is the link between the wiring distribution and the fixture
ballast(s). It mounts directly to the fixture body in a standard 1/2" K.O. (7/8"
diameter). The adapter can be rotated for ease of cable orientation to prevent
a strain on the connection.
POWER-CONNECT™
DIMENSIONS
LA
Job Information
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Lightolier
Technical Information: (978) 657-7600 • Fax (978) 658-0595
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division)
A0902
3/4"
Type:
a Genlyte Thomas Company
OPTIONS/ACCESSORIES/Folio OA40-17
LA CABLE
LIGHTING ADAPTERS
2-5/16"
www.lightolier.com
