Summary of Contents for Curtis VR223
-
Page 2: Table Of Contents
Contents Function Description……………………………………………………………………………………2 Notice for Use……………………………………………………………………………………………2 System Requirements…………………………………………………………………………………4 Basic operation…………………………………………………………………………………………7 ArcSoft PhotoImpression, VideoImpression and MediaImpression………………………………12 Product Specifications…………………………………………………………………………………28 Standard accessories…………………………………………………………………………………29... -
Page 3: Function Description
Function Description: Welcome! Thank you for purchasing the CURTIS VR223 With this digital video camera, you can take 640 x 480 resolution (VGA format) videos and 300,000 pixels of still photos. With the playback function you can play back the taken video or photos with this digital video camera. - Page 4 5. When storing documents onto the memory or the memory card, make sure that the size of the documents does not exceed the capacity of the memory. Maintenance and care: 1. To clean the lens, blow away the dust on its surface, then use proper cloth or tissue for optical devices to clean the lens.
-
Page 5: System Requirements
System requirements: Below are the minimum requirements that your computer needs to operate files for the software included: Operation System Microsoft Windows Me, 2000,XP, Vista* Above Intel PIII667 or CPU of equal performance Memory Above 128 MB Sound card and display card DirectX8 or above CD-ROM 4×... - Page 6 Power Key USB Connector TV Out Port Microphone Resolution Switch Lens LED Light USB Switch Speaker Card Slot Battery Cover Strap Holder Tripod...
-
Page 7: Basic Operation
Shutter/Record Up(+) Key Mode Delete Key Left Key Right Key Down(-) key 2. Basic operation... - Page 8 2.1 Battery Installation Slide down the Battery Cover and insert two new AA alkaline batteries. Align with correct polarity of battery terminals. Close Battery Cover. 2.2 Use SD card Insert the SD memory card into the SD card slot. Push it down until the card stays latched.
- Page 9 In power-on state, when battery level is very low, the red icon on the bottom left of the screen will flash and the camera will turn off after one second. You must replace the batteries. Change mode After powering on, the camera will always enter video record mode, press mode key to change mode between video record and capture.
- Page 10 Take a Picture In capture mode, press the shutter key to take a photo. Play back videos and photos In playback mode, press left or right key ( ) to select a file. Press Shutter key to begin/stop play video, and press up key or down key to on a photo.
- Page 11 port of TV，red (or white) port of the other terminal should be connected to AUDIO IN port of TV. 2.10 Delete files Press the delete key once to display “Delete File?” Press the delete key again to carry out deletion. Press any other keys to cancel the deletion. 2.11 Connect to PC and t Slide the USB Switch UP to extend the USB connector...
- Page 12 from the CD included with this device. ▲ Open USB port ▲Connect camera to PC (1) Connect camera to PC (2) ▲...
-
Page 13: Arcsoft Photoimpression, Videoimpression And Mediaimpression
Application of Attached ArcSoft PhotoImpression, VideoImpression and MediaImpression: There are three software applications provided on the CD for image processing: PhotoImpression, VideoImpression, and MediaImpression. Introduction interface for software installation Put the CD into the CD-ROM of the computer, then the following menu will occur: If the CD driver does not automatically carry out or close such function, please click autorun.exe program under... - Page 14 PhotoImpression 6 Installation and Use: Install PhotoImpression6: Click “Install PhotoImpression” button, complete the installation as instructed.
- Page 15 After installation, please restart the computer. Run PhotoImpression6: Double click icon on the desktop, or open PhotoImpression 6 via “Start→ Programs”.
- Page 16 When PhotoImpression6 is opened, you’ll see the following window. Click the center of the window with the left key of the mouse to shut the window. After the window is off, you can open PhotoImpression.
- Page 17 After PhotoImpression is open, the After choosing and opening photos in the “Get “Get Photo” window will appear: Photo” window, the chosen photos will be displayed in the center area of the screen. Then you can edit the chosen photos.
- Page 18 For the detailed instructions of PhotoImpression, please refer to the Help menu in the program (as shown in the following figure).
- Page 20 VideoImpression 2 Installation and Use: Install VideoImpression 2: Click “Install VideoImpression” button and complete the installation as instructed.
- Page 21 After installation, please restart the computer. Run VideoImpression 2: Double click the icon on the Desktop or follow “Start → Programs” to open VideoImpression 2.
- Page 22 After starting VideoImpression2, choose to create new video short. Choose to find the desired video short.
- Page 23 Choose and insert the desired video short into VideoImpression2.
- Page 24 In VideoImpression, you can edit the video short. For other detailed operation, press F1 Help menu (as indicated below) to understand more functions of this software.
- Page 25 MediaImpression Installation and Use: Install MediaImpression: Click “Install MediaImpression” button and complete the installation as instructed.
- Page 26 Run MediaImpression: Double click the icon on the Desktop or follow “Start → Programs” to open MediaImpression.
- Page 27 Click on the media files that you would like to organize.
- Page 28 ArcSoft MediaImpression® enables users to easily, creatively, and productively manage their multimedia with simple workflow and powerful tools. Organize your media easily and create simple projects with editing tools. There are endless ways to present and share; worry-free media file backup & restore. For other detailed operation, press the F1 Help menu to understand more functions of this software.
-
Page 29: Product Specifications
Product specifications: Image sensor 300,000pixels Function mode Record, playback, mobile disk, deletion Lens F2.4 f=3.6mm Focus range 120cm~infinity Digital focusing 4× Shutter Electronic LCD display 2.0 inch TFT Display Resolution VGA 640×480, QVGA 320×240 White balance Automatic Exposure Automatic File format Video out TV out Storage media... -
Page 30: Standard Accessories
Standard accessories: Installation CD User manual TV cable...
