Lightolier Lytespan 9179 Specification

Page 1 of 2
4
5
3
3 /
4
Ordering Information
Catalog No. Finishes
9179WH
Matte White
9179BK
Matte Black
9179AL Matte Aluminum
Features
1. Lamp Bracket: Stamped steel with insulated end knob made of high
temperature silicone rubber which allows for aiming adjustments while
fixture is on.
2. Socket: Bi-pin base ceramic socket wired with No. 18 stranded Teflon
leads with fiberglass outer sleeve.
3. Transformer: Electronic low voltage transformer with integral radio
frequency interference filter and anti-crossover circuit for increased
reliability; housed in extruded aluminum.
4. Track Attachment Fitting: Molded polycarbonate, rotates into track and
locks on with push tab; integral polarity key guard.
5. Push Tab: Locks and detaches unit from track.
6. Brass Contact: Extends up for connection to second circuit when used
with Advent ® Lytespan track.
7. Tension Pivot Mounts: Steel. Allows for 180° horizontal rotation and
180° vertical rotation.
8. Lamp Guard: Tempered glass; can be substituted with 2" filter.
9. Spring: Steel springs hold lamp in place.
10. Housing: Aluminum with vent holes.
3
1
5 /
2
7
Track Mountings
All Lytespan
Track Systems
Lytespan
1
2
10
1
2 /
4
9
8
Lamps
MR16
50W Max.
Electrical/Dimming
Dimming controls: Use only dimmers specifically designed for use with elec-
tronic transformers, like Lightolier Sunrise™ and Neptune Momentum QE™
series. Low voltage fixtures may produce audible sound when used with dim-
mers, which may be objectionable in acoustically critical areas.
Labels
UL
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2006 Genlyte Group LLC • B0706
Track Lighting
®
MiniForms™ Apollo MR16
6
7
2 /
8
Type:
www.lightolier.com
9179
