Hunter 25517 Parts Manual

PARTS GUIDE
PARTS GUIDE
Using the Parts Guide below, check to make sure all parts are included in the box.
PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE.
Before installing your fan, record the following information for your records and warranty assistance.
Blade Set
Blade Iron Set
#10 x 3 Wood Screw
#8 x 1 1/2 Wood Screw
#8-32 x 3/4 Phillips Head
Screw and #8 Lockwasher
for Flush Mounting
#6-32 x 3/8Ó
Sems Screws
Blade Armature Screw
Blade Assembly Screw
If parts are missing or damaged call 1-888-830-1326.
Fan Parts
(Not Drawn to Scale)
Hanger Pipe
Assembly
Motor / Housing Assembly
Hardware
Flat Washer
Wire Nut
Canopy Screw
Rubber Blade Grommets
- •
Canopy Assembly
•
Switch /
Housing
Assembly
(Drawn to Scale)
- •
Washer,
Installer Choice
for Flush Mounting
Mounting Isolators
Model Name
Catalog No.
Serial No.
Date Purchased
Where Purchased
Missing / Broken Parts:
Call 1-888-830-1326
Fan does not work:
1. Reference the Trouble Shooting guide in
your Instruction Manual.
2. Call your Local Service Center.
3. Call Technical Support at 901-248-2222.
For additional information on:
Hunter Products Trouble Shooting
Dealer Location Service Center Locator
Call 1-800-448-6837
www.hunterfan.com
R
