Compaq Netelligent 5226A Manual

Compaq Netelligent 5226A

Ethernet Switch

Compaq introduces the Netelligent 5226A
Ethernet Switch with 24 10Base-T ports, two
10/100Base-TX uplink ports, and two modular
uplink ports for additional 10/100Base-TX or
100Base-FX ports. The 10/100Base-TX uplink
ports, both fixed and modular, are auto-sensing.
In addition to full SNMP management support, the
Netelligent 5226A supports VLAN and RMON
(groups 1, 2, 3, and 9). Each Netelligent 5226A
switch also includes Compaq Netelligent
Management Software (CNMS), so the user can
immediately configure the switch and get detailed
performance activity information.
Each port on the Netelligent 5226A is
configurable for full or half duplex operation.
An optional dual redundant power supply provides
reliability in the event of power loss in one of the
power supplies.
These enterprise-class features are now available
at a price that is affordable for medium and large
workgroup networks! The Netelligent 5226A
switch offers aggressive pricing, high port density,
and maximum network reliability. Combined with
the Netelligent 5708 100Base-TX and 100Base-
FX switches, Ethernet and Fast Ethernet hubs, and
10/100Base-TX controllers, the Netelligent 5226A
rounds out the complete desktop to backbone
networking solution from Compaq.
THE COMPAQ
ADVANTAGE
À
High port density for workgroup and desktop
switching applications.
À
Up to four Fast Ethernet connections.
À
Provides SNMP, VLAN, RMON, VT-100 (via
Telnet or serial interface) management, and
IEEE 802.1d Spanning Tree functionality.
À
Compaq Netelligent Management Software
and Compaq Insight Manager are included.
À
Compaq can provide the end-to-end
solution. From the lightweight laptop
computer to the multi-terabyte, fault-tolerant
server and all the high-speed connections in
between: client and central site modems,
LAN infrastructure, and remote access
M
ODELS
servers.
À
Compaq products are backed by customer
Netelligent 5226A
Ethernet Switch
support that is among the most
comprehensive in the industry.
*)
À
(International)
Compaq leverages a heritage of industry-
Netelligent
standard computing leadership to deliver the
10/100Base-TX
Uplink Module very best in networking and
communications.
*)
À
Warranty *).
Netelligent
100Base-FX Uplink
Module
*)
Redundant Power
Supply Module
*)
Compaq Netelligent 5226A
Ethernet Switch

NEW PRODUCT!

February 1998
