AC ADAPTOR
• Use a standard 9V
the use of a VTech® 9V AC/DC adaptor.
• Make sure the unit is turned OFF.
• Plug the power jack into the 9V DC socket at the back of the unit.
• Plug the AC adaptor into a wall socket.
NOTE: The use of an adaptor will override the batteries. When the toy is not
going to be in use for an extended period of time, unplug the adaptor.

Standard Guidelines for Adaptor Toys

• The toy is not intended for use by children under 3 years old.
• Only use the recommended adaptor with the toy.
• The transformer is not a toy.
• Never clean a plugged-in toy with liquid.
• Never use more than one adaptor.
• Do not leave the toy plugged-in for extended periods of time.
CONNECTING TO A TV
NOTE: Before you connect the V.Smile™ TV Learning System to a TV,
check to make sure that the unit is working. Once you have turned
the unit ON, the power indicator light (ON Button) should glow.
If the ON Button does not glow, check to see that the adaptor is
connected correctly, or that the batteries are installed correctly. If
the batteries are not installed correctly, the V.Smile™ TV Learning
System will not function and damage to the unit could result. Make
sure that your TV and the unit are turned OFF before you begin
making connections.
Connect the V.Smile™ TV Learning System to your TV or monitor by
plugging the colored cables on the unit into the matching color video and
audio input jacks on your TV set.
300mA
For TVs with stereo audio inputs:
- Connect the yellow plug on the V.Smile™ cable to
the yellow video input terminal on your TV.
- Connect the white and red plugs on the V.Smile™
cable to the white and red audio input terminals on
your TV.
AC/DC adaptor. We recommend
