Lightolier Lytecaster 1078 Specification

Page 1 of 2
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
Reflector Trim Frame-In Kit — See Individual Frame-In Kit Specification Sheets
Frame-In Kit
1078 Opal
1001LED
1001LEDEM
1000LEDREM
L56LED
Frame-In Kit
1000P1
1002P1
1003R
1000IC
1000AICM
* Lightolier recommends the use of triple tube lamps.
Features
1. Reflector: Hydroformed aluminum, .040" thick (18 ga.); non-yellowing,
scratch resistant Perma White finish, 88% reflectance; white trim flange.
2. Diffuser: Translucent white, polycarbonate Lexan
with twist-lock action, no tool required.
3. Frame-In Kit: (1002P1 standard frame shown). Other frames listed above and
shown on the right. See Frame-In Kit specification sheets for more details.
Labels
UL (Suitable for Wet Locations—Covered Ceiling), I.B.E.W.
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2011 Philips Group • A1111
Lytecaster
1078/1002P1 Series
Standard Incandescent
LED
Installation Type Lamping Height
Non-IC LED 6 3/4"
Non-IC EM LED 6 3/4"
Non-IC Remodeler LED 6 3/4"
Non-IC Retrofit LED 6 3/4"
Incandescent
Ceiling Type Lamping Height
Non-IC 60W A19 6 3/4"
Non-IC 6 3/4"
Non-IC Remodeler 6 3/4"
IC 40W A19 7 5/16"
AirSeal IC
®
7 5/16"
. Installs and removes
®
Recessed Downlighting
®
5" Aperture Lexan
6 3/4"
Fluorescent
Frame-In Kit Ceiling Type
1001F13U Series UniFrame Non-IC
™
1001F18U Series
UniFrame ™ Non-IC
1001F26U Series
UniFrame ™ Non-IC
1004F13 Series
IC
1004F18 Series IC
1004F26* Series
IC
1001F 13ICU/N
Performance IC
1001F18ICU/N Performance IC
1001F26ICU/N Performance IC
1001FDICMX1/N Performance IC
Advance Mark 10
Dimming 120v
1001FDICMX2/N Performance IC
Advance Mark 10
Dimming 277v
1910XFH1 Conversion Kit
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Dish Diffuser Reflector Trim
®
1078/1003R
0
™
Non-IC Remodeler
Lamping Height
(1) Quad/Triple 13W (GX24q-1) 5 7/8"
(1) Quad /Triple 18W (GX24q-2) 5 7/8"
(1) Triple 26W (GX24q-3) 5 7/8"
(1) Quad/Triple 13W (GX24q-1) 7 1/2"
(1) Quad/Triple 18W (GX24q-2) 7 1/2"
(1) Quad/Triple 26W (GX24q-2) 7 1/2"
(1) Quad/Triple 13W (GX24q-1) 7 1/4"
(1) Quad/Triple 18W (GX24q-2) 7 1/4"
(1) Triple 26W (GX24q-3) 7 1/4"
(1) Triple 26W (GX24q-3) 7 1/4"
(1) Triple 26W (GX24q-3) 7 1/4"
(1) Quad/Triple 13W (GX23q-2) 6 3/4 "
Type:
1078
