Lightolier Lytespan 8292F3E Specification

Page  of 2
Ordering Information
Catalog No. Finishes
Matte White
8292F3EWH
Matte Black
8292F3EBK
Metallic Aluminum
8292F3EAL
Features
1. Ballast Housing: 0.09" extruded aluminum housing with die cast endcaps.
2. Ballast: High power factor electronic metal halide ballast.
3. Reflector Housing: .095" thick extruded aluminum body with die cast end
caps.
4. Vertical Pivot: 0 - 90° vertical adjustment.
5. Horizontal Pivot: Die cast track adapter with positive rotation stop provides
385° horizontal rotation.
6. Sockets: 5 Kv pulse rated sockets with nickel plated contacts; leads
enclosed in silicone coated fiberglass sleeving.
7. Contact Holder: High temperature thermoplastic. Secures luminaire
mechanically and makes electrical contact with track.
8. Brass Contact: Extends for connection to second circuit in Advent
Lytespan track.
®
9. Flood Reflector: Symmetrical aluminum reflector for illumination on vertical
surface.
10. Safety Interlock Switch: Disconnects power when safety lens is removed.
11. Safety Lens: Tempered /8" UV filtering glass. Meets or exceeds safety
requirements for metal halide lamps.
12. Indicator Guide: Aiming indicator assures consistent and precise multiple
unit alignment.
13. Locking Lever: Nickel plated steel. For mechanical/electrical connection to
track.
Electrical
Electronic Ballast
Input Voltage: 20V, 60Hz
Power Factor: >95%
Input Power: 78W
Input Current: .67 amp
Lytespan
PowerArc™ Double Ended Metal Halide 30° Vertical Flood
Track Mountings
All Lytespan Track Systems, Multipoint, and
®
Monopoint. DO NOT USE with any other mounting
accessories or stem mounted Radius
®
Electrical (Continued)
Harmonic Distortion: <0%
DO NOT USE ON A DIMMING CIRCUIT

Options and Accessories

Accepts PowerArc Accessory Holder (8293AC), Vertical Blade Louver (8293LV),
Spread Lens (8293BE), UV Filter (8293UV), and Visor (8293VS).
NOTE: 8293UV or 8293BE must be combined with 8293AC.
Finish
All painted finishes are baked enamel.
Labels
®
UL, cUL
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
63 Airport Road, Fall River, MA 02720 • (508) 679-83 • Fax (508) 674-470
We reserve the right to change details of design, materials and finish.
© 2006 Genlyte Group LLC • C0807
Track Lighting
®
12
Lamps
70W CDM or CMH T-6
Double Ended Metal Halide (M-98)
Track.
Type:
a Genlyte company
8292F3E
www.lightolier.com
