Liquid Crystal Projector USER'S MANUAL Thank you for purchasing this liquid crystal projector. Please read the accompanying manual “SAFETY INSTRUCTIONS” and this “USER'S MANUAL” thoroughly to ensure correct usage through understanding. After reading, store this instruction manual in a safe place for future reference. NOTE: •...
FEATURES This liquid crystal projector is used to project various computer signals as well as NTSC / PAL / SECAM video signals onto a screen. Little space is required for installation and large images can easily be realized. • Outstanding brightness The UHB lamp and high-efficiency optical system assure a high level of brightness.
B B E E F F O O R R E E U U S S E E ( ( c c o o n n t t i i n n u u e e d d ) ) Loading the Battery CAUTION Danger of explosion if battery is incorrectly replaced.
INSTALLATION Installation of the Projector and Screen Refer to the drawing and table below for determining of the screen size and projection distance. a: Distance from the LCD projector to the screen. The projection distances shown in the table below are for full size (800 x 600 dots).
I I N N S S T T A A L L L L A A T T I I O O N N ( ( c c o o n n t t i i n n u u e e d d ) ) Cabling RGB signal input: Connect the RGB IN 1 or 2 terminal of the projector to the RGB signal output of the computer by the enclosed...
I I N N S S T T A A L L L L A A T T I I O O N N ( ( c c o o n n t t i i n n u u e e d d ) ) Power Connection Use the correct one of the enclosed power cords depending on the power outlet to be used.
OPERATIONS Switching the Power Supply ON/OFF Switching Power ON 1. Check that the power cord is connected correctly. 2. Set the power switch to [ | ]. The standby mode is selected, and the Power indicator is turned to orange. 3.
O O P P E E R R A A T T I I O O N N S S ( ( c c o o n n t t i i n n u u e e d d ) ) Basic Operation The Basic operations shown in Table 2 is performed from the projector control panel or the supplied remote control transmitter.
Page 12
O O P P E E R R A A T T I I O O N N S S ( ( c c o o n n t t i i n n u u e e d d ) ) Table 2.
MAINTENANCE Lamp HIGH VOLTAGE HIGH TEMPERATURE HIGH PRESSURE Contact your dealer before replacing the lamp. (Option lamp: DT00331) Before replacing the lamp, switch power OFF, remove the power cord from the power outlet, and wait approximately 45 minutes until the lamp has cooled. The lamp may explode if handled at high temperatures.
M M A A I I N N T T E E N N A A N N C C E E ( ( c c o o n n t t i i n n u u e e d d ) ) Air Filter Maintenance The air filter should be cleaned as described below at intervals of approximately 100 hours.
TROUBLESHOOTING OSD Message The messages as described below may appear on the screen at power ON. Take the appropriate measures when such a message appears. Table 8. OSD Messages Message Contents The message shown at left appears after the lamp has been used for more than 1700 hours.
T T R R O O U U B B L L E E S S H H O O O O T T I I N N G G ( ( c c o o n n t t i i n n u u e e d d ) ) Indicators Message The POWER indicator, LAMP indicator, and TEMP indicator are lit and blank as follows.
T T R R O O U U B B L L E E S S H H O O O O T T I I N N G G ( ( c c o o n n t t i i n n u u e e d d ) ) Symptom Before requesting repair, check in accordance with the following chart.
WARRANTY AND AFTER-SERVICE If a problem occurs with the equipment, first refer to the P.20 “TROUBLESHOOTING” section and run through the suggested checks. If this does not resolve the problem contact your dealer or service company. If repairs are possible, and desirable, they will be charged. ENGLISH-24 ENGLISH-24...
TECHNICAL Dimension Diagram 94.6 Unit : mm 76.5 RGB Signal Pin Assignment Signal Signal Video input Red Video input Green RGB IN 1: SDA(DDC) Video input Blue RGB IN 2: - RGB OUT: - Ground H. sync./ Composite D-sub 15-pin shrink jack sync.
TECHNICAL Example of computer signal Resolution Display fH (kHz) fV (Hz) Rating Signal mode H × V mode 720 × 400 37.9 85.0 VESA TEXT Zoom in 640 × 480 31.5 59.9 VESA VGA (60Hz) Zoom in 640 × 480 35.0 66.7 Mac13"mode...
Page 28
T T E E C C H H N N I I C C A A L L ( ( c c o o n n t t i i n n u u e e d d ) ) Initial set signals The following signals are used for the initial settings.
Page 29
T T E E C C H H N N I I C C A A L L ( ( c c o o n n t t i i n n u u e e d d ) ) Connection to the Mouse Control 1.
Page 30
T T E E C C H H N N I I C C A A L L ( ( c c o o n n t t i i n n u u e e d d ) ) ADB Mouse Projector Computer...
T T E E C C H H N N I I C C A A L L ( ( c c o o n n t t i i n n u u e e d d ) ) RS-232C communication (1) Turn off the projector and computer power supplies and connect with the RS-232C cable.
Page 32
T T E E C C H H N N I I C C A A L L ( ( c c o o n n t t i i n n u u e e d d ) ) Requesting projector status (Get command) (1) Send the request code Header + Command data (‘02H’+‘00H’+ type (2 bytes) +‘00H’+‘00H’) from the computer to the projector.
T T E E C C H H N N I I C C A A L L ( ( c c o o n n t t i i n n u u e e d d ) ) Command data chart Command data Names...
Page 34
T T E E C C H H N N I I C C A A L L ( ( c c o o n n t t i i n n u u e e d d ) ) Command data chart Command data Names...
Page 35
T T E E C C H H N N I I C C A A L L ( ( c c o o n n t t i i n n u u e e d d ) ) Command data chart Command data Names...
Page 36
T T E E C C H H N N I I C C A A L L ( ( c c o o n n t t i i n n u u e e d d ) ) Command data chart Command data Names...
Page 37
REGULATORY NOTICES FCC Statement Warning WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
