- Page 1 Issued 2/2003 Hydraulic Brake Dayton • Quadraulic • Lucas • DCM Catalog PB-02101 Strength • Power • Speed • Agility M E R I T O R P A R T S . R I G H T F R O M T H E S T A R T .
-
Page 2: Table Of Contents
4 x 70mm Quadraulic Steel Piston M10 x 1.5 Inlet Port ………………… 10 4 x 70mm Quadraulic Steel Piston 7/16-24 Inlet Port…………………… 12 Meritor Hydraulic Disc Brake 2.18" Twin Piston………………………… 14 Meritor Hydraulic Disc Brake 2.50" Twin Piston………………………… 16 Meritor Hydraulic Disc Brake 2.88" Twin Piston………………………… 18 DCM Brake……………………………………………………………………... -
Page 3: Quadraulic Disc Brake Applications
QUADRAULIC DISC BRAKE APPLICATIONS BLUE BIRD BUS MODEL AXLE BRAKE BRAKE BRAKE FMSI SHOE FMSI LINING DISC AXLE TYPE MFG. SIZE FD965 10.7k ArvinMeritor D769 7636 KITD769AM FF966/FF943 12k ArvinMeritor D769 7636 KITD769AM S-15 Wide Track 15k ArvinMeritor D769 7636 KITD769AM RS-19 L-Spindle 19k ArvinMeritor... - Page 4 QUADRAULIC DISC BRAKE APPLICATIONS BLUE BIRD BUS CALIPER ROTOR CALIPER CALIPER CALIPER CALIPER CALIPER HWD. KIT BORE SIZE LEFT RIGHT REPAIR KIT PISTON R4011729 23-123557-002 70mm 60450469 60450468 R4011730 60050334 R4011729 70mm 60450469 60450468 R4011730 60050334 R4011729 23-123557-002 70mm 60450469 60450468 R4011730 60050334...
-
Page 5: Quadraulic Disc Brake
QUADRAULIC DISC BRAKE CALIPER KITS/PISTON/ DESCRIPTION BILL OF MATERIAL PART NO. PAD NO. 4 x 64mm QUADRAULIC DISC BRAKE 60450474 L/H 64 mm Phenolic Piston Caliper 7/16"-24 NS - 2B inlet port 60450474001 L/H 64 mm Phenolic Piston Caliper 7/16"-24 NS - 2B inlet port / incl. disc pads 60450473 R/H 64 mm Phenolic Piston Caliper 7/16"-24 NS - 2B inlet port... - Page 6 QUADRAULIC DISC BRAKE CALIPER KITS/PISTON/ DESCRIPTION BILL OF MATERIAL PART NO. PAD NO. 4 x 70mm QUADRAULIC DISC BRAKE (cont.) 60050320 R/H 70 mm Steel Piston Caliper M10 x 1.5 inlet port 60450454 R/H 70 mm Steel Piston Caliper M10 x 1.5 inlet port / incl. disc pads R4011121 Hardware Kit 1) 69160483 anti-rattle spring...
-
Page 7: X 64Mm Quadraulic Phenolic Piston
QUADRAULIC DISC BRAKE... - Page 8 QUADRAULIC DISC BRAKE DESCRIPTION PART NO. HARDWARE KIT Services One Wheel R4011729 Includes: 69160483 (Anti-Rattle Spring) 69310804 (Bolt Anti-Rattle) 69330709 (Lining Spacer) 69310814 (Lining Spacer Bolt) BOOT AND SEAL KIT R4011731 69340647 (Boot) (64mm) 69170343 (Seal) CALIPER PISTON R4011511 69260551 (Piston) (64mm) 69330719...
-
Page 9: X 70Mm Quadraulic Phenolic Piston
QUADRAULIC DISC BRAKE... - Page 10 QUADRAULIC DISC BRAKE DESCRIPTION PART NO. HARDWARE KIT Services One Wheel R4011729 Includes: 69160483 (Anti-Rattle Spring) 69310804 (Bolt Anti-Rattle) 69330709 (Lining Spacer) 69310814 (Lining Spacer Bolt) BOOT AND SEAL KIT R4011730 69340646 (Boot) (70mm) 69170337 (Seal) CALIPER PISTON 60050334 69260548 (Piston) (70mm) 69330717...
-
Page 11: X 70Mm Quadraulic Steel Piston M10 X 1.5 Inlet Port
QUADRAULIC DISC BRAKE... - Page 12 QUADRAULIC DISC BRAKE DESCRIPTION PART NO. HARDWARE KIT Services One Wheel R4011121 Includes: 69160483 (Anti-Rattle Spring) 69310804 (Bolt Anti-Rattle) 69330709 (Lining Spacer) 69310803 (Lining Spacer Bolt) BOOT AND SEAL KIT R4011120 69340642 (Boot) Boot & Seal Kit 69170337 (Seal) 69330714 (Boot Shield) 60050315 69340642...
-
Page 13: X 70Mm Quadraulic Steel Piston 7/16-24 Inlet Port
QUADRAULIC DISC BRAKE... - Page 14 QUADRAULIC DISC BRAKE DESCRIPTION PART NO. HARDWARE KIT Services One Wheel R4011121 Includes: 69160483 (Anti-Rattle Spring) 69310804 (Bolt Anti-Rattle) 69330709 (Lining Spacer) 69310803 (Lining Spacer Bolt) BOOT AND SEAL KIT R4011120 69340642 (Boot) Boot & Seal Kit 69170337 (Seal) 69330714 (Boot Shield) 60050315 69340642...
-
Page 15: Meritor Hydraulic Disc Brake 2.18" Twin Piston
MERITOR HYDRAULIC DISC BRAKE... - Page 16 MERITOR HYDRAULIC DISC BRAKE REPLACES PART NO. HARDWARE KIT Services One Wheel 60050135 Bendix H5533 Dayton 69160324 Z Spring 69160383 S Spring 69420654 Retainer Use R404208 Guide Bolt with this configuration (1976-1985). 1976-1985 GUIDE BOLT R404208 Bendix H5025 Use with Support Key and Spring Configuration (1976-1985).
-
Page 17: Meritor Hydraulic Disc Brake 2.50" Twin Piston
MERITOR HYDRAULIC DISC BRAKE... - Page 18 MERITOR HYDRAULIC DISC BRAKE REPLACES PART NO. HARDWARE KIT Services One Wheel 60050153 Dayton 69420654 Retainer 69160383 Spring Ford E4HZ-28487A E4HZ-28552A 15501147 BOOT AND SEAL KIT 60050266 Dayton 6050151 Ford E4HZ-2207A 15510025 GUIDE BOLT 69310693 Carlson H5037 For Use With 60050153 Kit...
-
Page 19: Meritor Hydraulic Disc Brake 2.88" Twin Piston
MERITOR HYDRAULIC DISC BRAKE... - Page 20 The Retainer Hole Dia. = 7/16" end user may not know which caliper key is needed, A = 3-5/8" therefore, Meritor now supplies both keys in the new kits that service one axle. BOOT AND SEAL KIT 60050146...
-
Page 21: Dcm Brake
DCM (DUPLEX CAM MECHANICAL) BRAKE... -
Page 22: Dcm Brake Shoes
12" x 4" RV-876 Use on DCM-1203 3/16" brakes. A-3722-F-422 12" x 5" RV-876 Use on DCM-1205 3/16" parking brakes. LINED BRAKE SHOES FOR DCM BRAKES MERITOR PART RIVET LINING NUMBER SIZE HOLES NUMBER REMARKS A2-3722-G-501 10" x 3" M202 Use on DCM1003 brakes. - Page 23 DCM BRAKE COMPONENTS PART COIL NUMBER LENGTH O.D. COMMENTS WA-39 9/16" 19/32" Return spring for 10" and 12" DCM brakes. PART NUMBER COMMENTS 2710-U-151 1"-32 spline camshaft for DCM brakes. BOLT PART PILOT CIRCLE HOLE APPLICATION NUMBER DIAMETER DIAMETER DIAMETER HOLES SIZE INFORMATION...
- Page 24 DCM BRAKE COMPONENTS PART NUMBER LENGTH APPLICATION INFORMATION A-3787-Q-17 9-1/8" Mechanical brake strut for 10" x 2" & 3" DCM brakes. A-3787-N-14 10-3/4" Mechanical brake strut for 12" DCM brakes. PART HOLE CENTER TO APPLICATION NUMBER HOLE CENTER INFORMATION 372-B-210 5-1/4", 5-7/8", 6-1/2"...
-
Page 25: Durapark Brake Assembly
DURAPARK BRAKE ASSEMBLY ® 15" x 5", 6", & 7"... - Page 26 BRAKE ASSEMBLY SERVICE KITS BRAKE POSITION SPRING KIT SP7896S SP7897S (1) Green or Yellow Spring SP7896 SP7897 (1) Orange or White Spring (green/orange) (yellow/white) BRIDGE PIPE KIT (1) Bridge Pipe Assembly SP7861S SP7862S (1) Retaining Clip SP7861 SP7862 (1) Screw PLUG KIT (2) M.O.
-
Page 27: Durapark Park Cylinder
DURAPARK PARK CYLINDER ® 15" x 5", 6", & 7"... - Page 28 PARK CYLINDER SERVICE KITS BORE SIZE AND BRAKE POSITION 1.75" LH 1.75" RH 1.625" LH 1.625" RH MINOR OVERHAUL KITS SEAL KIT (2) Dust Boots (1) Retaining Ring (2) Hydraulic Seals SP7872S SP7893S (1) Gasket SP7872 SP7893 (1) O-Ring (1) Grease Pack DUST BOOT KIT (2) Dust Boots SP7889S...
-
Page 29: Durapark Adjuster Cylinder
DURAPARK ADJUSTER CYLINDER ® 15" x 5", 6", & 7"... - Page 30 ADJUSTER CYLINDER SERVICE KITS BORE SIZE AND BRAKE POSITION 1.75" LH 1.75" RH 1.625" LH 1.625" RH MINOR OVERHAUL KITS SEAL KIT (2) Piston Seals (2) Dust Boots SP7871S SP7866S (1) Gasket SP7871 SP7866 (1) Grease Pack DUST BOOT KIT SP7868S (2) Dust Boots (1) Grease Pack...
-
Page 31: Durapark Alphabetical Parts Listing
