Epson Endeavor VL Specifications

power (speed) light
hard disk access light
I
AC inlet for
monitor -
AC outlet -
voltage
switch

Computer Specifications

CPU and Memory

32-bit CPU Intel 486SX, DX, or DX2 processor
I
Ail systems can be upgraded with a faster
microprocessor, including SX2, DX4, and Pentium
OverDrive processor when available; DX4 processors
require an adapter board to regulate voltage
System speed
High and low speeds available; high speed is the speed
of the microprocesso r, low speed is simulated 8 MHz;
speed selection through keyboard command or SETUP;
0 watt state memory access at high speed
Memory 4MB RAM standard soldered on the system board;
expandable to 40MB (maximum) using 4MB or 16MB
SIMMs; SIMMs must be 32- or 36-bit, 72-pin fast-page
mode type with 70ns (or faster) access speed
ROM 128KB system BIOS, video BIOS, and SETUP code
located in EPROM on main system board
Supports shadowing of system and video BIOS ROM into
Shadow RAM
RAM
8KB of internal cache (built into the microprocessor);
Cache
sockets for 64,128, or 256KB of SRAM external cache
(optional)
Math On DX and DX2 systems, math coprocessor built into the
coprocessor microprocessor
Clock/ calendar Real-time clock, calendar, and CMOS RAM socketed on
main system board with built-in battery backup
Serial
AC
keyboard
inlet
Controllers
Video
Diskette
power
Hard disk
Interfaces
monitor
cable
video
slots are
2 and 3)
parallel
port

Mass Storage

Keyboard
Design
Layout
Interface
Connector
Cable length 51 inches (1300 mm); coiled
Weight
Dimensions
3/94
EPSON Endeavor VL
External VESA local bus video cam supports high resolution
displays (preinstailed on systems sold in the United States);
see the video card manual for more information
Controller on main system board supports up to two diskette
drives or one diskette drive and one tape drive or other
storage device
Local bus IDE interface on main system board supports up to
two IDE hard disk drives with built-in controllers.
Detachable; two-position height; NumLock and speed settings
adjustable through SETUP
101 or 102 sculpted keys; country-dependent main typewriter
keyboard; numeric/cursor control keypad; four-key cursor
control keypad; 12 function keys
PS/2-compatibie
6-pin, mini-DIN, male
3 lb (1.36kg)
17.5 inches (446 mm) wide
6.9 inches (175 mm) deep
1.5 inches (37.6 mm) high, without legs
2 inches (51 mm) high, with legs
EPSON Endeavor VL-1
