- Page 1 CP2896TA / CP2996TA BEDIENUNGSANLEITUNG USER MANUAL ISTRUZIONI PER L'USO GEBRUIKSAANWIJZING KULLANMA KILAVUZU...
-
Page 2: Table Of Contents
Before installation Your TV set is designed to give you the highest performance combined with real ease of use - it's easy to set up, easy to use, and easy to combine with other 10 cm devices. This booklet will guide you through the set-up procedure, acquaint you with the many features, provide tips on how to use the set, and tell you how to connect external devices to it. -
Page 3: Installation, Remote Control Unit
Installation Connections Connecting the aerial cable Connect the aerial cable to the aerial connector on the rear panel of the TV set. Use a high quality outdoor aerial to obtain the best programme reception. Connecting a video recorder to the TV set If you are connecting a video recorder as well, connect the aerial cable plug into the video recorder aerial input. -
Page 4: First Time Installation
Installation First time installation The Automatic Programming System (APSi) will automatically search for and store TV programme channels. After the search, the TV set will sort the programme channels into a factory preset order. First check that the aerial cable is properly connected. _________________________________________________________________________ Press the mains switch on the front panel. -
Page 5: Daily Use
Daily use Switching on or off To switch on Press the mains switch on the front of the TV set. To switch on from the stand-by mode, hold the TV button down until the TV switches on or enter a number to select a programme directly. To switch off To put on stand-by to stand-by... -
Page 6: Sound Controls
Daily use Sound controls Volume Use the -/+ buttons or the cursor buttons (left and right). Sound Audio STEREO Sound mute button ( V) Sound channel SOUND A Press once to turn off the sound. Tone PREFERRED Press a second time to turn on all speakers. Separation If the audio out connectors (not in all models, see the section "External Store... -
Page 7: Teletext 2
Additional features Teletext In addition to actual programmes, many TV channels offer a teletext service. Teletext contents vary from one channel to another, and a service typically covers news, weather reports, sport etc. Functions on the remote control unit Cursor up/down To step through the teletext pages left/right To step through the sub-pages *) 0..9... -
Page 8: Additional Features
Additional features Sub-pages TOP teletext (available in Germany) Some teletext pages consist of several sub-pages. The The TOP system provides menu-prompted guidance to sub-pages are denoted for example by 123/02, which enable you to select text pages quickly and easily. means the second sub-page of the page 123. -
Page 9: Timers And Locks
Additional features Switching the TV set to stand-by with a timer Press the MENU button (located under the lid). _________________________________________________________________________ Select the option "Timers" and confirm with the OK button. _________________________________________________________________________ Select the required timer function and follow instructions on the screen. Timers Sleep timer 1h 45min... -
Page 10: Sound, Picture, And Display Set-Up
Sound and picture controls Sound set-up Storing new sound settings Press the green button to select the Sound menu. ________________________________________________________________________ Sound Select the required option with the cursor buttons (up or down). Audio STEREO Sound channel SOUND A • Audio - Standard setting is STEREO. If there is noise, or the Tone PREFERRED transmission is weak, select MONO to improve sound quality. - Page 11 Sound and picture controls Picture set-up Storing new preferred settings Stored picture adjustments affect all programme channels. Press the yellow button twice. _________________________________________________________________________ Preferred settings Adjust the required setting with the cursor buttons. _________________________________________________________________________ Brightness Contrast Colour If you want to store the changes, press the OK button. Go back Store »...
-
Page 12: Tuning In Programme Channels
Tuning in programme channels Displaying the Tuning menu All tuning options are selected from the Tuning menu. Press the MENU button (under the lid). _________________________________________________________________________ Select the option "Tuning" by pressing the cursor buttons (up or down). _________________________________________________________________________ Confirm the selection by pressing the OK button. _________________________________________________________________________ Select the required alternative with the cursor buttons, then follow instructions on the screen. -
Page 13: External Devices
Tuning in programme channels Editing the programme list The option "Sort programs" allows you to edit the programme list to suit your own viewing preferences. You can also store a broadcast identifier for each programme number to make the identification of an individual Sort programs 1 TV 1 programme channel easier, e.g. - Page 14 External devices Setting up external devices If you are connecting a VHS video recorder to the Scart E2 connector, the VCR is ready for use after connecting the cables. If you are connecting a decoder, see also instructions in the section "Connecting a decoder".
-
Page 15: Connecting A Decoder
External devices Recording a programme through the TV set Recording a programme through the TV set You can record a satellite programme from an external satellite receiver or copy a self made camera recording while watching it. Connect the Video camera video recorder to be used for recording to the blue Scart E2 connector. - Page 16 TV set remote control hand unit. Code Akai Programming the remote control unit Finlux, Hitachi After inserting the batteries, the text "VCR mode not programmed" (or Nokia, Luxor, Salora, Sanyo "SAT mode not programmed") appears on the screen when you press Nokia, Finlux, Luxor, Salora, the VCR (or SAT) button.
-
Page 17: Technical Data
Before you call a serviceman Problem Solution After a power failure, thunderstorm, etc. a malfunction Switch off the receiver by using the mains switch, wait may occur. Example: The receiver does not respond to for about 10 seconds and switch the receiver on again. the remote control commands. - Page 18 Fax: +46 (0) 8 562 711 13 Tel: +39 02 38073415 Servizio Clienti Email: csgswe@hitachi-eu.com Fax: +39 02 48786381/2 Email: customerservice.italy@hitachi-eu.com HITACHI EUROPE S.A.S HITACHI EUROPE LTD (Norway) AB Lyon Office STRANDVEIEN 18 B.P. 45, 69671 BRON CEDEX 1366 Lysaker FRANCE...
