GARAGE DOOR OPENER
Model 248739
For Residential Use Only
Owner's Manual
■ Please read this manual and the enclosed safety materials carefully!
■ Fasten the manual near the garage door after installation.
■ The door WILL NOT CLOSE unless The Protector System
■ Periodic checks of the opener are required to ensure safe operation.
■ The model number label is located on the left side panel of your opener.
®
Elmhurst, Illinois 60126-1196
®
is connected and properly aligned.
The Chamberlain Group, Inc.
845 Larch Avenue
www.chamberlain.com
