Fusion ACTIVE TUBE CS-AT1100 Installation Manual

ACTIVE TUBE
CS-AT1100
SPECIFICATIONS
Peak Power (Watts)
Rated Power (Watts)
Frequency Response
Low Pass Filter (Variable)
Tuning
Woofer Size
Fuse
Dimensions (mm)
DISCLAIMER
Always ensure the Active Tube is securely attached, to avoid movement. FUSION accepts no responsibility for damage or injury in relation
to inappropriate securing of this product.
CONTROL DESCRIPTIONS
LEVEL
This allows the adjustment of the amplifier level of the subwoofer.
Turn clockwise to increase the level. If the sound becomes distorted
reduce the level.
LOW PASS FILTER (LPF)
This allows the adjustment of the highest frequency the Active
Tube will produce. This should be adjusted to blend with your main
speakers. Typically, this will be set to around 100Hz (approximately
the central position of the control knob).
REMOTE LEVEL CONTROLLER
When connected, this allows further control over the level from a
remote location, using the supplied lead.
INSTALLATION
Make sure the Active Tube is firmly fixed in your vehicle. Check
before drilling or cutting holes. DO NOT work near gas tanks, fuel
lines, hydraulic lines or electrical wiring.
DO NOT mount the Active Tube in such a way as to pinch or damage
the wires.
Make sure everything is firmly connected, before attaching the
+12V wire. Ensure the +12V wire is fused as close as possible to the
battery. Always use a fuse with the recommended rating.
CS-AT1100
360
120
36Hz - 250Hz
40Hz - 250Hz
Bass Reflex
10"
20A
559(l) x 306(w) x 306(h)
22-1/32 x 12-1/16 x 12-1/16"
WIRING
• Connect the ground wire to the vehicle first (clean dirt and paint
to bare metal).
• Connect the remote on (blue wire).
• Connect the RCA cables if applicable, OR
• Connect the speaker level wire by splicing into the headunits
speaker wires. See Note 1 on reverse.
• Connect the remote level controller with the supplied lead.
• Connect the 12 volt (red wire) to the positive battery terminal.
• Check all connections.
