Frigidaire FRT21P5A Factory Parts Catalog
Top mount refrigerator
Hide thumbs
Also See for FRT21P5A:
- Factory parts catalog (13 pages) ,
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
Download this manual
See also:
Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRT21P5AB8
FRT21P5A
FRT21P5AB9
FRT21P5A
FRT21P5AQ8
FRT21P5A
FRT21P5AQ9
FRT21P5A
FRT21P5AW8
FRT21P5A
FRT21P5AW9
FRT21P5A
MARKET
North America
WIRING DIAGRAM - # 240379012
OWNER'S GUIDE - # 240400110
SERVICE DATA SHEET - # 240379012
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
black
R134a
black
R134a
bisque
R134a
bisque
R134a
white
R134a
white
Publication No.
5995398541
031107
-EN/SERVICE /DCS
357
FACTORY
PARTS CATALO
VOLTS
115
115
115
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21P5A
©2003 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT21P5A
Summary of Contents for Frigidaire FRT21P5A
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21P5AB8 FRT21P5A R134a black FRT21P5AB9 FRT21P5A R134a black FRT21P5AQ8 FRT21P5A R134a bisque FRT21P5AQ9 FRT21P5A R134a bisque FRT21P5AW8 FRT21P5A R134a white FRT21P5AW9 FRT21P5A R134a white MARKET North America WIRING DIAGRAM - # 240379012 OWNER’S GUIDE - # 240400110 SERVICE DATA SHEET - # 240379012 TOP MOUNT...
- Page 2 Publication No. FRT21P5A 5995398541 DOOR N05DAACKA1 11/03...
- Page 3 FRT21P5A Publication No. 5995398541 DOOR A = FRT21P5A (FRT21P5AB8) B = FRT21P5A (FRT21P5AB9) C = FRT21P5A (FRT21P5AQ8) D = FRT21P5A (FRT21P5AQ9) E = FRT21P5A (FRT21P5AW8) F = FRT21P5A (FRT21P5AW9) POS. NO PART NO DESCRIPTION 240514611 A B - - - - Gasket,seal ,black ,frzr door ,magnetic 240514607 - - C D E F...
- Page 4 Publication No. FRT21P5A 5995398541 CABINET 11/03...
- Page 5 FRT21P5A Publication No. 5995398541 CABINET A = FRT21P5A (FRT21P5AB8) B = FRT21P5A (FRT21P5AB9) C = FRT21P5A (FRT21P5AQ8) D = FRT21P5A (FRT21P5AQ9) E = FRT21P5A (FRT21P5AW8) F = FRT21P5A (FRT21P5AW9) POS. NO PART NO DESCRIPTION 240355402 A B C D E F Cover-fan 240367001 A B C D E F...
- Page 6 Publication No. FRT21P5A 5995398541 SHELVES N05SAAAEE13 11/03...
- Page 7 FRT21P5A Publication No. 5995398541 SHELVES A = FRT21P5A (FRT21P5AB8) B = FRT21P5A (FRT21P5AB9) C = FRT21P5A (FRT21P5AQ8) D = FRT21P5A (FRT21P5AQ9) E = FRT21P5A (FRT21P5AW8) F = FRT21P5A (FRT21P5AW9) POS. NO PART NO DESCRIPTION 215667501 A B C D E F Tray,ice cube ,plastic 240358003 A B C D E F...
- Page 8 Publication No. FRT21P5A 5995398541 SYSTEM 11/03...
- Page 9 FRT21P5A Publication No. 5995398541 SYSTEM A = FRT21P5A (FRT21P5AB8) B = FRT21P5A (FRT21P5AB9) C = FRT21P5A (FRT21P5AQ8) D = FRT21P5A (FRT21P5AQ9) E = FRT21P5A (FRT21P5AW8) F = FRT21P5A (FRT21P5AW9) POS. NO PART NO DESCRIPTION 240444401 A B C D E F Condenser,dynamic 218944001 A B C D E F...
-
Page 10: Wiring Schematic
Publication No. FRT21P5A 5995398541 WIRING SCHEMATIC 11/03... -
Page 11: Wiring Diagram
FRT21P5A Publication No. 5995398541 WIRING DIAGRAM # = Fast-moving Parts 11/03 * = Non-Illustrated Parts...
